Page 1 Safety Light Curtain F3SG-□RA/□RE Series User's Manual Cat. No. Z352-E1-10 http://www.ia.omron.com/f3sg-r...
Page 2 Original instructions Introduction Thank you for purchasing the F3SG-RA/RE Series Safety Light Curtain (hereinafter referred to as the "F3SG-R"). This is the instruction Manual describing the use of F3SG-R. Always heed the following points when using the F3SG-R: Be sure to have F3SG-R be handled by a "Responsible Person" who is well aware of and familiar with the machine to be installed. The term "Responsible Person"...
Page 3 Legislation and Standards 1. The F3SG-R does not receive type approval provided by Article 44-2 of the Industrial Safety and Health Act of Japan. When using the F3SG-R in Japan as a "safety system for pressing or shearing machines" prescribed in Article 42 of that law, the machine control system must receive type approval. 2.
Page 4 6. Other Standards The F3SG-R is designed according to the standards listed below. To make sure that the final system complies with the following standards and regulations, you are asked to design and use it in accordance with all other related standards, laws, and regulations. If you have any questions, consult with specialized organizations such as the body responsible for prescribing and/or enforcing machinery safety regulations in the location where the equipment is to be used.
Page 5: Terms And Conditions Agreement
Terms and Conditions Agreement Warranties. (a) Exclusive Warranty. Omron's exclusive warranty is that the Products will be free from defects in materials and workmanship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron).
Page 6 Programmable Products. Omron Companies shall not be responsible for the user's programming of a programmable Product, or any consequence thereof. Performance Data. Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty.
Page 7: Safety Precautions
Safety Precautions Indications and Meanings for Safe Use The precautions listed in this document indicated by alert symbols and statements must be followed for the safe use of the F3SG-R. Failure to follow all precautions and alerts may result in an unsafe use or operation.Thoroughly read this manual and understand the installation procedures, operation check procedures, and maintenance procedures before using F3SG-R.
Page 8 For machines Do not use this sensor for machines that cannot be stopped by electrical control. For example, do not use it for a pressing machine that uses full-rotation clutch. Otherwise, the machine may not stop before a person reaches the hazardous part, resulting in serious injury. To use F3SG-R in PSDI mode (initiation of cycle operations by a presence sensing device), you must configure an appropriate circuit between F3SG-R and the machine.For details about PSDI, refer to OSHA1910.217, IEC61496-1, and other relevant standards and regulations.
Page 9 Detection capability gets larger when fixed/floating blanking or reduced resolution function is used. When these functions are used, the safety distance calculation must be based on the increased detection capability for these functions. Otherwise the machine may not stop before a person reaches to the hazardous part, resulting in serious injury.
Page 10 Make sure to connect an override cancel switch to the Reset line when using the override function. Otherwise the override state may not be released by the override cancel switch, resulting in serious injury. When muting error occurs with workpiece blocking the F3SG-R, there are two methods to forcibly remove the workpiece.
Page 11 For wiring When using the PNP output, connect the load between the output and 0 V line. When using the NPN output, connect the load between the output and +24 VDC line. Connecting the load between the output and a different power supply line from the above will result in a dangerous condition because the operation mode of safety output is reversed to "Dark-ON".
Page 12 Settings Some settings of functions or the setting recovery function configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person go to undetected, resulting in serious injury.
Page 13: Precautions For Safe Use
Precautions for Safe Use Make sure to observe the following precautions that are necessary for ensuring safe use of the product. Do not install, use, or store the F3SG-R in the following types of environments: - Areas exposed to intense interference light, such as direct sunlight - Areas with high humidity where condensation is likely to occur - Areas where oil mist or corrosive gases are present - Areas exposed to vibration or shock levels higher than in the specification provisions...
Page 14: Precautions For Correct Use
Precautions for Correct Use Observe the precautions described below to prevent operation failure, malfunctions, or undesirable effects on product performance.  Storage conditions and installation environment • Do not install, use, or store the F3SG-R for a long time at a temperature or humidity out of the specified range.
Page 15: Visual Aids
Visual Aids The following symbols appear in this document to help you locate different types of information. Indicates important information or advice on a function or operation of the product. Indicates page numbers or chapter title of related information. F3SG-RA/RE xiii User’s Manual...
Page 16 F3SG-RA/RE User’s Manual...
Page 17: Table Of Contents
Table of Contents Legislation and Standards Terms and Conditions Agreement Safety Precautions Precautions for Safe Use Precautions for Correct Use Visual Aids xiii Chapter1 Overview and Specifications 1-1. What is Included 1-2. System Components 1-2-1. Basic Components 1-2-2. Model Overview 1-3.
Page 18 2-5. PNP/NPN Selection 2-5-1. Overview 2-5-2. Factory Default Setting 2-5-3. Setting with DIP Switch 2-5-4. Setting with Configuration Tool 2-6. Self-Test 2-6-1. Overview 2-6-1-1. Self-Test details 2-6-1-2. Waveform of safety outputs 2-7. External Test 2-7-1. Overview 2-7-2. Factory Default Setting 2-7-3.
Page 19 2-13-2.Override at Normal Operation 2-13-3.Override upon Startup 2-13-4.Setting with DIP Switch 2-13-5.Setting with Configuration Tool 2-14. Fixed Blanking 2-14-1.Overview 2-14-2.Factory Default Setting 2-14-3.Setting with DIP Switch 2-14-4.Setting with Configuration Tool 2-15. Floating Blanking 2-15-1.Overview 2-15-2.Factory Default Setting 2-15-3.Setting with DIP Switch 2-15-4.Setting with Configuration Tool 2-16.
Page 20 2-22-1.Overview 2-22-2.Factory Default Setting 2-22-3.Setting with DIP Switch 2-22-4.Setting with Configuration Tool 2-23. Light Level Monitoring 2-23-1.Incident Light Level Information 2-23-1-1. Overview 2-23-1-2. Setting with Configuration Tool 2-23-2.Ambient Light Level Information 2-23-2-1. Overview 2-23-2-2. Setting with Configuration Tool 2-24. Maintenance Information 2-24-1.Overview 2-24-2.Error Log 2-24-3.Warning Log...
Page 21 4-1-3. Distance from Reflective Surfaces 4-1-3-1. F3SG-4R (Type 4 ESPE) 4-1-3-2. F3SG-2R (Type 2 ESPE) 4-1-4. Mutual Interference Prevention 4-2. Cascade Connection 4-2-1. Overview 4-2-2. Connection Procedure 4-3. Dimensions 4-3-1. Mounted with Standard Fixed Brackets (F39-LGF) 4-3-1-1. F3SG-RA Series 4-3-1-2. F3SG-RE Series 4-3-1-3.
Page 22 4-5-4. Cable Connections(F3SG-RE Series) 4-5-4-1. Recommended Cable 4-5-4-2. Extending Cable Length with Commercially Available Cable 4-5-4-3. Adapter Cable (C) 4-5-4-4. Simple wiring connector System 4-5-5. Functional Earth Connection Chapter5 Input/Output Circuit and Applications 5-1. Input/Output Circuit 5-1-1. Entire Circuit Diagram 5-1-1-1.
Page 23 5-3-1. Short Mode 5-3-2. Long Mode 5-3-3. Standalone F3SG-RE with Y-Joint Plug/Socket Connector 5-4. Connectable Safety Control Units Chapter6 Checklists 6-1. Pre-Operation Checklists 6-1-1. Checklists 6-1-1-1. Installation Condition Check 6-1-1-2. Wiring Check Before Power Is Turned ON 6-1-1-3. Operation Check While the Machine Is Stopped 6-1-1-4.
Page 24 F3SG-RA/RE xxii User’s Manual...
Page 25: Chapter1 Overview And Specifications
Chapter 1 Overview and Specifications 1-1. What is Included 1-2. System Components 1-2-1. Basic Components 1-2-2. Model Overview 1-3. List of Features 1-3-1. Model Overview 1-3-2. Versions 1-3-3. List of Features 1-4. LED Indicators 1-4-1. LED Indicator Status 1-5. Ratings/Specifications 1-6.
Page 26: What Is Included
Overview and Specifications 1-1. What is Included Before use, confirm that the items below are included with the product. If you find that an item is missing, please contact your local branch office or distributor. Product Quantity F3SG-RA main unit Emitter x 1, Receiver x 1 F3SG-RE...
Page 27: System Components
Overview and Specifications 1-2. System Components This section describes the system components and part names of the F3SG-R system.  F3SG-RA Series  F3SG-RE Series Beam center-line mark Beam center-line mark Beam Beam Emitter Emitter Indicator Indicator Receiver Receiver DIP Switch (Emitter) Power Cable DIP Switch (Receiver) (Gray)
Page 28: Basic Components
Overview and Specifications 1-2-1. Basic Components Component Model name Description Emitter, receiver F3SG-RA-- Select a model name based on the required protective height and ESPE type. The model name can be understood as follows: F3SG- RA 1: ESPE type (4: Type 4, 2: Type 2) 2: Protective height (mm) 3: Object resolution (mm) 4: L: Emitter, D: Receiver, blank: Emitter and receiver.
Page 29: Model Overview
Overview and Specifications 1-2-2. Model Overview The F3SG-R safety light curtain family is available in two ESPE types, Type 4 and Type 2 according to EN 61496-1, identified as follows: F3SG-4RA : Type 4 ESPE F3SG-2RA : Type 2 ESPE (These are also referred to as the "F3SG-RA".) The F3SG-RA is multi-functional and designed for various applications.
Page 30: List Of Features
Overview and Specifications 1-3. List of Features 1-3-1. Model Overview The F3SG-R safety light curtain family has two types, F3SG-RA and F3SG-RE.  F3SG-RA Series The model name is represented as F3SG-RA-. The F3SG-RA series is an advance model, allowing you to configure the safety light curtain to fit your application.
Page 31: List Of Features
Overview and Specifications  Settings of Auxiliary Output and Lamp when F3SG-RA in cascade connection When F3SG-RA are in cascade connection, the F3SG-RA operates according to the settings of the primary sensor. The operations of Auxiliary Output and Lamp functions are as follows. Primary Secondary Auxiliary Output and Lamp operations*...
Page 32 Overview and Specifications  Functions by F3SG-RA software versions F3SG-RA Software Version Function Version 1.0 Version 1.1 and up Floating Blanking Temporarily Disable Monitoring function is only Temporarily Disable Monitoring function is available when the F3SG-RA is in one available when the F3SG-RA is in either one segment system.
Page 33 Overview and Specifications F3SG-RE Factory Default Setting Function Wiring Up to January 2016 From February 2016 +24 V Long Mode Long Mode Operating mode of Operating Open Long Mode Long Mode Rangs Select Input Short Mode Short Mode Refer to 1-3-2. Versions to check versions of your F3SG-R. F3SG-RA/RE User’s Manual...
Page 34: Led Indicators
Overview and Specifications 1-4. LED Indicators  F3SG-RA Series <Emitter> <Receiver> 1. Top-beam-state indicator (Blue) 2. PNP/NPN mode indicator (Green) 3. Response time indicator (Green) 4. Sequence error indicator (Yellow) 5. Blanking indicator (Green) 6. Configuration indicator (Green) 1. Test indicator (Green) 7.
Page 35: Led Indicator Status
Overview and Specifications 1-4-1. LED Indicator Status Shown below are indication statuses of F3SG-R LED indicators of factory default. Emitter F3SG-RA F3SG-RE Location Name of Indicator Color Illuminated Blinking Series Series External Test is being Test TEST Green performed Lockout state due to DIP Long range mode is Switch setting error or Operating range...
Page 36 Overview and Specifications F3SG-RA F3SG-RE Location Name of Indicator Color Illuminated Blinking Series Series Synchronization between Lockout state due to emitter and receiver is Communication error, or Communication Green maintained error due to abnormal power supply or noise The bottom beam is Muting/Override state , or Bottom-beam- Blue...
Page 37: Ratings/Specifications
Overview and Specifications 1-5. Ratings/Specifications The  in the model names indicate the protective heights in millimeters. F3SG-4RA-14 F3SG-4RA-30 F3SG-4RE14 F3SG-4RE30 F3SG-2RA-14 F3SG-2RA-30 F3SG-2RE14 F3SG-2RE30 Type of ESPE Type 4 F3SG-4RA-14/-30 F3SG-4RE14/30 (IEC 61496-1) Type 2 F3SG-2RA-14/-30 F3SG-2RE14/30 Performance Object Resolution Opaque objects (Detection Capability) 14-mm dia.
Page 38 Overview and Specifications F3SG-4RA-14 F3SG-4RA-30 F3SG-4RE14 F3SG-4RE30 F3SG-2RA-14 F3SG-2RA-30 F3SG-2RE14 F3SG-2RE30 Operating Range Select Input: ON voltage: Vs-3 V to Vs (short circuit current: Long: 9 V to Vs (short circuit current: approx. 2.5 approx. 6.5 mA)* mA)* OFF voltage: 0 V to 1/2 Vs, or open (short circuit RESET current: approx.
Page 39 Overview and Specifications F3SG-4RA-14 F3SG-4RA-30 F3SG-4RE14 F3SG-4RE30 F3SG-2RA-14 F3SG-2RA-30 F3SG-2RE14 F3SG-2RE30 Ambient Operating 35% to 85% (non-condensing) Humidity Storage 35% to 95% Incandescent lamp: 3,000 Ix max. on receiver surface Ambient Illuminance Sunlight: 10,000 Ix max. on receiver surface Degree of Protection IP65 and IP67 (IEC 60529) Vibration Resistance...
Page 40 Overview and Specifications F3SG-4RA-14 F3SG-4RA-30 F3SG-4RE14 F3SG-4RE30 F3SG-2RA-14 F3SG-2RA-30 F3SG-2RE14 F3SG-2RE30 Included Accessories Safety Precautions, Quick Installation Manual, Standard Fixed Bracket*1, Troubleshooting Guide Sticker, Warning Zone Label *2 *1. The quantity of Standard Fixed Brackets included varies depending on the protective height. [F3SG-RA-14]/F3SG-RE14] - Protective height of 0160 to 1200: 2 sets - Protective height of 1280 to 2080: 3 sets...
Page 41: List Of Models
Overview and Specifications 1-6. List of Models 1-6-1. List of Models/Response Time/Current Consumption/Weight F3SG-RA-14 Current Response Time[ms] Consumption Weight[kg] Number Protective [mA] Model Height OFF (Not [mm] Beams ON→OFF Gross (Synchronized) synchronized) Emitter Receiver →ON *2 →ON *2 F3SG-4RA0160-14 F3SG-2RA0160-14 F3SG-4RA0240-14 F3SG-2RA0240-14 F3SG-4RA0320-14...
Page 42 Overview and Specifications Current Response Time[ms] Consumption Weight[kg] Number Protective [mA] Model Height[m OFF (Not Beams ON→OFF Gross (Synchronized) synchronized) Emitter Receiver →ON *2 →ON *2 F3SG-4RA0830-30 F3SG-2RA0830-30 F3SG-4RA0910-30 F3SG-2RA0910-30 F3SG-4RA0990-30 F3SG-2RA0990-30 F3SG-4RA1070-30 F3SG-2RA1070-30 1070 F3SG-4RA1150-30 F3SG-2RA1150-30 1150 F3SG-4RA1230-30 F3SG-2RA1230-30 1230 F3SG-4RA1310-30 F3SG-2RA1310-30...
Page 43 Overview and Specifications Current Response Time[ms] Consumption Weight[kg] Number Protective [mA] Model Height OFF (Not [mm] Beams Gross ON→OFF (Synchronized) synchronized) Emitter Receiver →ON *1 →ON *1 F3SG-RE136014 1360 F3SG-RE144014 1440 F3SG-RE152014 1520 F3SG-RE160014 1600 F3SG-RE168014 1680 F3SG-RE176014 1760 F3SG-RE184014 1840 F3SG-RE192014 1920...
Page 44: Calculation Of Response Time Of Cascaded Segments
Overview and Specifications The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s. 1-6-2. Calculation of Response Time of Cascaded Segments The F3SG-RA can be used in cascade connection. In case of a cascade connection, a response time is determined by the total number of beams. If the total number of beams of all F3SG-RA in a cascade connection is 140 or less, its response time is 12 ms (Code A)/13 ms (Code B).
Page 45: Chapter2 System Operation And Functions
Chapter 2 System Operation and Functions 2-1. Combination of Functions 2-2. Operating States 2-3. Optical Synchronization 2-4. Scan Code Selection 2-5. PNP/NPN Selection 2-6. Self-Test 2-7. External Test 2-8. Lockout Reset 2-9. Interlock 2-10. External Device Monitoring (EDM) 2-11. Auxiliary Output 2-12.
Page 46: Combination Of Functions
System Operation and Functions 2-1. Combination of Functions Possible combinations of the F3SG-RA functions are shown in the table below. The combinations in the table are available under certain conditions. The other functions can be combined without any limitations. The functions listed in the table below are not available for the F3SG-RE. Refer to 2-18.
Page 47 System Operation and Functions  Considerations for enabling and disabling Muting function Setting parameters of the following functions can be saved according to the state where the Muting function is enabled and disabled, respectively. After changing the Muting function from Enable to Disable or from Disable to Enable, check the settings of these functions again.
Page 48: Operating States
System Operation and Functions 2-2. Operating States The operating condition of a F3SG-R system is described in terms of states. The following operating states exist for a F3SG-R system. 2-2-1. Machine Run State The two receiver safety outputs are in the ON state, the green ON/OFF indicator is illuminated. The protected machine is allowed to operate.
Page 49: Setting State
System Operation and Functions 2-2-6. Setting State The two receiver safety outputs are in the OFF state. The blue Top-beam-state indicator, green Configuration indicator, red Lockout indicator, green Stable-state indicator and green ON/OFF indicator of the receiver are blinking. The Setting state does not allow the protected machine to operate. The user can change settings of the functions, monitor the operating states or view maintenance information with the Configuration Tool (SD Manager 2) under this state.
Page 50: Optical Synchronization
System Operation and Functions 2-3. Optical Synchronization F3SG-RA Series F3SG-RE Series 2-3-1. Overview Synchronization is required between an emitter and a receiver for normal operation of F3SG-R. F3SG-R uses a specific beam for Synchronization. The beam is hereinafter called synchronization beam.
Page 51: Scan Code Selection
System Operation and Functions 2-4. Scan Code Selection F3SG-RA Series F3SG-RE Series 2-4-1. Overview The F3SG-RA has two scan codes (Code A and Code B). These scan codes have different internal processing time. The use of different scan codes allows for placement of systems in close proximity and in line with each other and minimize mutual interference.
Page 52 System Operation and Functions 2-5. PNP/NPN Selection F3SG-RA Series F3SG-RE Series 2-5-1. Overview The F3SG-RA offers PNP/NPN selection for the user to select the polarity of the inputs and outputs of the receiver between PNP and NPN. When the system is set to the NPN type, the “NPN” indicator is illuminated. The PNP/NPN Selection function is not available for the F3SG-RE.
Page 53 System Operation and Functions 2-6. Self-Test F3SG-RA Series F3SG-RE Series 2-6-1. Overview The F3SG-R performs the Self-Test when power is turned ON (within 2 seconds) to check for errors. Also, it regularly performs the Self-Test (within a response time) while operating. This function cannot be cancelled.
Page 54 System Operation and Functions 2-6-1-2. Waveform of safety outputs When the safety outputs are in the ON state, they are cyclically turned OFF as shown below to test the output circuit. When this OFF signal is fed back, the output circuit is diagnosed as normal. If the output signal does not include an OFF pulse signal due to short-circuit, etc, the receiver diagnoses a failure in the output circuit or wiring, and it enters the Lockout state.
Page 55 System Operation and Functions 2-7. External Test F3SG-RA Series F3SG-RE Series 2-7-1. Overview This function stops the emission using an external signal. It can be used to verify that a safety system should properly stop (safety output turns OFF) when F3SG-RA is blocked. To stop the emission, apply the following voltage to the emitter's TEST input line according to the DIP switch settings of the emitter.
Page 56 System Operation and Functions  Timing chart TEST Toff x 4 or less Toff × 8 + 100 ms or less OSSD Toff: Response time ON to OFF 2-7-2. Factory Default Setting The factory default setting is 24 V Active. 2-7-3.
Page 57 System Operation and Functions 2-8. Lockout Reset F3SG-RA Series F3SG-RE Series 2-8-1. Overview When the cause of the Lockout state is removed, you can release the Lockout state of the F3SG-RA by using either of the following methods. • Cycle the power back ON •...
Page 58 System Operation and Functions 2-9. Interlock Install the reset switch in a location that provides a clear view of the entire hazardous zone and where it cannot be activated from within the hazardous zone. Install the pre-reset switch always in the hazardous zone and where it cannot be activated from outside the hazardous zone.
Page 59 System Operation and Functions function ensures safety for an operator working in the hazardous zone by adding another reset switch (pre-reset switch) in the hazardous zone. If the Pre-Reset function is enabled, an operator can work in the hazardous zone and press the pre- reset switch installed in the hazardous zone, pass the light curtain, and press the reset switch to restart the machine.
Page 60 System Operation and Functions • Manual Reset mode PNP output NPN output F39-JG†A-D F39-JG†A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch S1: Lockout/Interlock Reset Switch The table below shows the relation between the ON/OFF states and external lines. External Connection Input Vs-3 V to Vs...
Page 61 System Operation and Functions  Basic wiring diagram • Pre-Reset mode PNP output NPN output F39-JG†A-D F39-JG†A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch S1: Lockout/Interlock Reset Switch S2: Pre-reset Switch S2: Pre-reset Switch The table below shows the relation between the ON/OFF states and external lines.
Page 62 System Operation and Functions 2-9-3. Setting with DIP Switch The user can select the mode from Auto Reset, Manual Reset or Pre-Reset by the DIP Switch. When configured to Manual Reset mode, the Start Interlock and Restart Interlock are enabled. When configured to Pre-Reset mode, the function is activated with the following conditions: •...
Page 63 System Operation and Functions Pre-Reset function Function Factory Default Setting Available Parameters Pre-Reset Disable Enable*1*2/Disable Maximum number of times F3SG-R can be blocked *3 infinite 1 to 9 times in 1-time increments, or infinate Maximum permissible time from input of PRE-RESET 1 to 60 s in 1-s increments signal to input of RESET signal *1.
Page 64 System Operation and Functions 2-10. External Device Monitoring (EDM) F3SG-RA Series F3SG-RE Series 2-10-1. Overview This function monitors if external relays (or contactors) operate normally to detect malfunctions, such as welding, in the external relays. When the NC contact of the external relays is open before the safety outputs switch from OFF to ON, the safety outputs remain in the OFF state.
Page 65 System Operation and Functions • In Manual Reset mode PNP output NPN output F39-JG†A-D F39-JG†A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch KM1, KM2: External device Also used as EDM line ...
Page 66 System Operation and Functions 2-10-4. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 67 System Operation and Functions 2-11. Auxiliary Output Do not use the auxiliary output for safety applications. Failure to do so may result in serious injury when the F3SG-RA fails. F3SG-RA Series F3SG-RE Series 2-11-1. Overview The auxiliary output is used to monitor the status of F3SG-RA. This output can be connected to a device such as an indication lamp, programmable controller, etc.
Page 68 System Operation and Functions 2-11-2. Factory Default Setting The factory default setting is inverted signal of the safety output. Unblocked Beam state Blocked Toff OSSD Auxiliary output Ton: Response time OFF to ON Toff: Response time ON to OFF 2-11-3. Setting with DIP Switch The factory default setting is inverted signal of the safety output.
Page 69 System Operation and Functions 2-11-4. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 70 System Operation and Functions Information (Output operation mode) assigned to auxiliary output Description Information Name (Auxiliary output is turned ON under the following condition) Safety output information When Safety output is in the ON state Interlock information Under Interlock state Lockout information Under error/ Lockout state Excess power-on time...
Page 71 System Operation and Functions 2-12. Muting F3SG-RA Series F3SG-RE Series 2-12-1. Overview Muting function temporarily disables safety function of the F3SG-RA, keeping safety output ON even if beams are blocked. This makes it possible to install safety light curtains for AGV passage, enabling both safety and productivity.
Page 72 System Operation and Functions All muting lamps that indicate state of muting function must be installed where workers can see them from all the operating positions. Use 2 independent input devices for muting input. A muting state may occur due to a single failure of the muting sensor.
Page 73 System Operation and Functions <LED indicator statuses of F3SG-RA: Receiver> Top-beam-state indicator Blinks during muting/override. Bottom-beam-state indicator Sequence error indicator Blinks during a muting sequence error. Configuration indicator If the Dynamic Muting function is enabled, the indicator flashes while measuring the workpiece height.
Page 74 System Operation and Functions • Safety outputs of the F3SG-RA are turned ON. • Muting input A and B are turned OFF.  End conditions If either of the following conditions is satisfied, the muting state is released. • Muting input A or B turns OFF for the maximum allowable muting signal interruption of T3 (at least 0.1 s: configurable) or longer.
Page 75 System Operation and Functions  Basic wiring diagram PNP output NPN output F39-JG†A-D F39-JG†A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1, S2: Muting sensor S1, S2: Muting sensor  Installation requirements for muting sensors •...
Page 76 System Operation and Functions  Installation example 1 of standard muting mode (Using two muting sensors) This is an example of two retro-reflective type photoelectric sensors used as muting sensors installed in a cross pattern. Use two sensors when the length L of the workpieces are not constant or are insufficient. Before a workpiece passes through Hazardous zone F3SG-RA...
Page 77 System Operation and Functions Muting state is maintained Hazardous zone Mirror F3SG-RA Workpiece Mirror The F3SG-RA is blocked but the safety function is disabled due to the muting state, and safety outputs 1 and 2 are turned ON. The muting state is released Hazardous zone Mirror F3SG-RA...
Page 78 System Operation and Functions This distance must prevent the muting state from being enabled by a person passing through the muting sensors. Also, install the F3SG-R and muting sensors so that each workpiece passes through all muting sensors before the next workpiece arrives at the first muting sensor (PNP mode). <Wiring diagram (PNP setting)>...
Page 79 System Operation and Functions  Installation example 2 of standard muting mode (Using four muting sensors) This installation example uses four through-beam type photoelectric sensors as muting sensors. The use of four muting sensors is useful when the length of the workpieces is constant or longer, and the entrance and exit have enough space.
Page 80 System Operation and Functions The muting sensor is blocked and the safety function of the F3SG-RA is disabled Hazardous zone F3SG-RA A2 Workpiece Muting sensors A1 and B1 are turned OFF but A2 and B2 are ON, so the muting state is still maintained.
Page 81 System Operation and Functions To enable the muting state, D3 and d2 must satisfy formulas (3) and (4), respectively. This distance must prevent the muting state from being enabled by a person passing through the muting sensors. Also, install the F3SG-RA and muting sensors so that each workpiece passes through all muting sensors before the next workpiece arrives at the first muting sensor.
Page 82 System Operation and Functions <Timing chart> T3 (0.1 s) max. Muting sensor A1 T1min to T1max T3 (0.1 s) max. Muting sensor B1 T3 (0.1 s) max. Muting sensor B2 T3 (0.1 s) max. Muting sensor A2 T2 max. 80 ms max. Enabled Muting state Disabled...
Page 83 System Operation and Functions (2) Interference to a muting sensor from F3SG-RA • Take distance (D) from a sensor causing the interference • Displace beams for each other to prevent interference (change installation height or place them crosswise) • Install a physical barrier •...
Page 84 System Operation and Functions  End conditions If any of the following condition is satisfied, the muting state is released. • When a workpiece passes a muting sensor A or B and the exit-only muting delay time (4 s) passes. •...
Page 85 System Operation and Functions  Basic wiring diagram PNP output NPN output F39-JG†A-D F39-JG†A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1, S2: Muting sensor S1, S2: Muting sensor  Installation Example of Exit-Only Muting Mode This is an installation example of exit-only muting mode.
Page 86 System Operation and Functions The muting sensor is blocked and the safety function of the F3SG-RA is disabled Hazardous zone A1 B1 F3SG-RA Workpiece When muting sensors A1 and B1 are turned ON in this order, and the muting state is enabled. In this state, the safety function of F3SG-RA is disabled.
Page 87 System Operation and Functions The workpiece passed F3SG-RA’s detection zone Hazardous zone A1 B1 F3SG-RA Workpiece A workpiece has passed F3SG-RA’s detection zone. When the muting end wait time: T4 (1 s: configurable) passes after the F3SG-RA is unblocked, the muting state is released. <Installation Distance>...
Page 88 System Operation and Functions Also, muting sensors and F3SG-RA must be installed so that muting state caused by a workpiece should be ended before the next workpiece arrives at the first muting sensor. Hazardous zone Hazardous zone A1 B1 F3SG-RA A1 B1 F3SG-RA Workpiece...
Page 89 System Operation and Functions 2-12-4. Position Detection Muting Mode Muting state is enabled when muting input A turns ON from the OFF state and muting input B turns OFF from the ON state within the muting input time limit value T1max, measured by a limit switch, etc. Muting inputs must be heterogeneous redundant inputs such as the combination of NO contact and NC contact types.
Page 90 System Operation and Functions  Timing chart T3 (0.1 s) max. Muting input A (Limit switch1) T3 (0.1 s) max. T1max Muting input B (Limit switch2) T2 max. 80 ms max. Enabled Muting state Disabled T2 max. Unblocked Beam state Blocked OSSD T1max: Muting input time limit value (maximum)
Page 91 System Operation and Functions  Installation Example of Position Detection Muting Mode Shown below is an installation example of position detection muting mode. This is an application that places a workpiece on a machine’s turntable surrounded by guard fence. When hazardous part of the machine is on the opposite side of a human body, safety function of F3SG-RA can be disabled so that an operator should be able to place a workpiece on the turntable.
Page 92 System Operation and Functions Guard fence F3SG-RA During muting Limit switch1 Limit switch 2 (NO Contact) (NC Contact) 24 V ON: To muting input A Input time difference between muting inputs A and B must be T1max or less (initial setting is 4 s) ON ->...
Page 93 System Operation and Functions 2-12-5. Dynamic Muting The Dynamic Muting function can configure a new muting zone while the muting state is enabled, based on a result measuring a workpiece height for a certain period of time. This materializes safer muting function with a limited muting zone adjusted according to a workpiece height.
Page 94 System Operation and Functions  Dynamic Muting Allowable Beam The dynamic muting allowable beam allows the muting zone measured by the Zone Measurement to be expanded by the number of additional beam(s) specified as allowable beam.  Timing chart Muting Input A Muting Input B Enabled Muting State...
Page 95 System Operation and Functions Refer to 2-24-6. Muting Statistics Information for more information. Standard Muting Mode Function Factory Default Setting Available Parameters Muting zone Bottom beam All beams any beam in 1-beam increments Top beam : Muting input time limit value (minimum) 0.1 s 0.1 to 3.9 s in 0.1-s increments : Muting input time limit value (maximum)
Page 96 System Operation and Functions 2-13. Override F3SG-RA Series F3SG-RE Series 2-13-1. Overview The override function turns the safety outputs ON when the muting start condition is not satisfied. If a workpiece stops while passing through the F3SG-RA, as shown below, causing a muting error, the normal state cannot be recovered unless the workpiece is removed from the muting sensors and the detection field of the F3SG-RA.
Page 97 System Operation and Functions When muting error occurs with workpiece blocking the F3SG-RA, there are 2 methods to forcibly remove the workpiece. 1) Manual operation (with additional safety measure); or 2) Override function (Override at Normal Operation / Override upon Start up) Only one of the methods, either 1) or 2) must be used.
Page 98 System Operation and Functions  Under exit-only muting mode 1. Muting sequence error occurred 2. The F3SG-RA is blocked and the output is OFF. 3. Under the state of 1 and 2, a special sequence is entered to the reset input three (3) times. The signal must be entered within a range from 0.1 s to the override input time limit T1 (1 s) (can be changed).
Page 99 System Operation and Functions  Timing chart Under standard muting mode Muting input A Muting input B 1 s max. RESET T1 T1 T1 T1 T1 T1 T2 max. 1 s max. Enabled Override state Disabled Unblocked Beam state Blocked OSSD T1: Override input time limit T2: Override time limit...
Page 100 System Operation and Functions  Factory default setting Variable Variable name Value Description Override input time limit Maximum input time of override input. Override time limit 600 s The duration time of the Override function. The Override state is cancelled if it continues for longer than this time limit. ...
Page 101 System Operation and Functions • External Device Monitoring not used and in Manual Reset mode PNP output NPN output F39-JG†A-D F39-JG†A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch, Override Switch or Override Cancel Switch S3, S4: Muting sensor *1.
Page 102 System Operation and Functions  Timing chart 2 to 5 s Power 1 s max. RESET T1 T1 T1 T1 T1 T1 1 s max. T2 max. Enabled OVERRIDE state Disabled Unblocked Beam state Blocked OSSD T1: Override input time limit T2: Override time limit Note.
Page 103 System Operation and Functions 2-14. Fixed Blanking Install protective structure for all zones of disabled zone so that a worker should not be able to approach hazardous zone of a machine without passing through zones disabled by the fixed blanking function. Otherwise it may result in serious injury.
Page 104 System Operation and Functions  Fixed blanking monitoring function For safety reasons, F3SG-RA transitions to lockout state* if part of a fixed blanking zone is unblocked. (Factory default setting.) In this case, power cycle or reset input enables the fixed blanking function again with the same setting as previous one.
Page 105 System Operation and Functions Refer to 3-3-1. Setting Fixed Blanking by Teach-in for more information on Teach-in with the DIP Switch. For detection capability on the border between the blanking zone and normal detection zone when allowable beam is configured, see next table. Detection capability on the border between the blanking zone and normal detection zone when allowable beam is specified.
Page 106 System Operation and Functions  Limitation for combination with other functions You can use this function in combination with muting, floating blanking, and warning zone functions at the same time with the setting tool for F3SG-R. Refer to 2-1. Combination of Functions for more information on the use in conjunction with other functions. Settings for respective zone have limitations.
Page 107 System Operation and Functions 2-15. Floating Blanking Detection capability gets larger when the floating blanking function is used. When this function is used, the safety distance calculation must be based on the increased detection capability for this function. Otherwise the machine may not stop before a person reaches to the hazardous part, resulting in serious injury.
Page 108 System Operation and Functions It is possible to configure the blanking monitoring function to be disabled when an interrupting object is smaller or removed. In case configured as Blanking Disable, if an interrupting object gets smaller than the setting value, the floating blanking function is canceled.
Page 109 System Operation and Functions Case: PNP Setting 24 V Limit Switch 1 (NO) MUTE A MUTE B Limit Switch 2 (NC) Case: NPN Setting Limit Switch 1 (NO) MUTE A MUTE B Limit Switch 2 (NC) The muting is not enabled when the Temporalily Disable Monitoring by External Wiring is enabled. ...
Page 110 System Operation and Functions 2 or fewer are blocked More than one zone is blocked 30-mm dia. 14-mm dia. max. 30-mm dia. Lockout Safety output OFF Fig. 3 Fig. 4  Detection capability Detection capability for F3SG-RA differs based on the number of floating beams as shown below. Number of blocked beams to turn safety Model Number of beams configured...
Page 111 System Operation and Functions 2-15-4. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 112 System Operation and Functions 2-16. Reduced Resolution F3SG-RA Series F3SG-RE Series 2-16-1. Overview The reduced resolution function prevents the safety output to turn off by an object moving in a detection zone. With this function, an object with a size of 1 to 3 beams can be ignored by changing a detection capability size.
Page 113 System Operation and Functions Detection capability gets larger when the reduced resolution function is used. When this function is used, the safety distance calculation must be based on the increased detection capability for this function. Otherwise, the machine may not stop before a person reaches the hazardous part, resulting in serious injury.
Page 114 System Operation and Functions The user can make changes to the settings by the Configuration Tool. Function Name Factory Default Setting Available Parameters Reduced Resolution Disable Enable*/Disable Number of beams 1 to 3 beams in 1-beam increments *It is not possible to configure the Reduced Resolution function together with the Muting function. To enable settings of the Reduced Resolution function, disable the Muting function.
Page 115 System Operation and Functions 2-17. Warning Zone F3SG-RA Series F3SG-RE Series 2-17-1. Overview Part of the detection zone can be set as a warning zone. Example: • When a person enters, indicator or buzzer should notify warning without stopping a machine. The Warning Zone is not available for the F3SG-RE.
Page 116 System Operation and Functions You can specify beams you want to configure for warning zone. (Fig. 4& 5) Configuration cannot be executed for cases shown below. • All beams are configured as a warning zone (Fig. 7). • A warning zone is specified without including any of end beams (Fig. 8) When it is configured for the F3SG-RA in cascade connection to have the detection zone, it is possible for the other F3SG-RA's to have the warning zone for the all beams.
Page 117 System Operation and Functions Warning Zone Warning Zone Detection Zone Detection Zone Upper 6 beams Lower 4 beams Upper Lower Upper Lower Fig. 4 Fig. 5 All beams are warning zone Upper Lower Upper Fig. 7 Detection Zone Warning Zone Detection Zone Channel 2 All beams are...
Page 118 System Operation and Functions 2-17-2. Factory Default Setting The factory default setting is Warning Zone Disable. 2-17-3. Setting with DIP Switch The user cannot make any changes to this function by the DIP Switch. 2-17-4. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings.
Page 119 System Operation and Functions 2-18. Setting Zone Adjacency Conditions If any two functions of muting, fixed blanking or warning zone functions of the F3SG-RA are used at the same time, the setting zones have limitations. This section describes the limitations for following points: 1.
Page 120 System Operation and Functions Warning zone Muting zone Muting zone Fixed blanking zone Figure 1 Figure 2 Even if a muting zone and a fixed blanking zone are configured as overlapped, fixed blanking monitoring function is effective. F3SG-RA/RE User’s Manual...
Page 121 System Operation and Functions 2-19. Operating Range Selection F3SG-RA Series F3SG-RE Series 2-19-1. Overview The Operating Range Selection function can change the operating range by changing emission light intensity. The following two modes in the table below are available for operating range. Operating Range Mode Detection Capability...
Page 122 System Operation and Functions 2-19-4. Setting by Wiring For the F3SG-RE, the user can select the mode of Operating Range Selection by wiring. <Basic wiring diagram> Short Mode Long Mode XS5F-D421- 80-F XS5F-D421- 80-F +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC...
Page 123 System Operation and Functions 2-20. Response Time Adjustment F3SG-RA Series F3SG-RE Series 2-20-1. Overview The Response Time Adjustment function allows the user to select the longer response time in order to reduce the chance the safety outputs are turned OFF by an accidental block of the F3SG-R due to an environmental factor.
Page 124 System Operation and Functions 2-21. Lamp F3SG-RA Series F3SG-RE Series 2-21-1. Overview A lamp (F39-LP and F39-BTLP, sold separately) can be connected to a receiver and turned ON based on the operation of F3SG-RA. The lamp can indicate red, orange, and green colors, to which three different states can be assigned.
Page 125 System Operation and Functions The user can make changes to the settings by the Configuration Tool. Factory Default Setting Lamp output Function Muting function *1 Available Parameters Enabled Disabled Output operation mode Safety output information Safety output information *2 (Priority 1) Inverted signal output Enable Enable...
Page 126 System Operation and Functions Description Information Name (Lamp turns ON or blinks under the following condition) Light level diagnosis When the F3SG-R is unblocked and light intensity is within a range from 100% to 170% of ON- information threshold for 10 s or longer Warning Zone Information When warning zone is blocked Blanking bream unblocked...
Page 127 System Operation and Functions 2-22. Designated Beam Output F3SG-RA Series F3SG-RE Series 2-22-1. Overview This function allows information on unblocked/blocked states of a given beam to be output. Example: • To turn a Lamp ON when a specified beam of F3SG-RA is blocked •...
Page 128 System Operation and Functions 2-22-3. Setting with DIP Switch The user cannot make any changes to this function by the DIP Switch. 2-22-4. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings.
Page 129 System Operation and Functions 2-23. Light Level Monitoring F3SG-RA Series F3SG-RE Series 2-23-1. Incident Light Level Information 2-23-1-1. Overview The user can use the Configuration Tool to read incident light level of the F3SG-RA and view on a PC screen. This function allows beam adjustment while checking incident light level. The Light Level Monitoring is not available for the F3SG-RE.
Page 130 System Operation and Functions 2-24. Maintenance Information Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 131 System Operation and Functions 2-11. Auxiliary Output 2-21. Lamp The user can make changes to the settings by the Configuration Tool. Function Factory Default Setting Available Parameters Power-on time threshold 30,000 h 30,000 to 1,000,000 h in 1-h increments/Disable 2-24-5. Load Switching Frequency The user can view the number of switching operations of the load connected to F3SG-RA.
Page 132 System Operation and Functions 2-25. Operating Status Monitoring F3SG-RA Series F3SG-RE Series 2-25-1. Overview I/O information and the state of F3SG-RA can be read out with the Configuration Tool. This function is only for F3SG-RA Configuration Tool. Make sure the Position 8 of the DIP Switch is set to Configuration Tool Enabled to activate the settings by the Configuration Tool.
Page 133 System Operation and Functions 2-26. Setting Recovery The Setting Recovery function configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 134 System Operation and Functions F3SG-RA/RE User’s Manual...
Page 135 Chapter 3 Setting with DIP Switch 3-1. List of Features Configurable by DIP Switch 3-2. DIP Switch 3-2-1. DIP Switch on Receiver 3-2-2. DIP Switch on Emitter 3-2-3. Push Switch 3-3. Setting by Teach-in 3-3-1. Setting Fixed Blanking by Teach-in 3-3-2.
Page 136 Setting with DIP Switch 3-1. List of Features Configurable by DIP Switch For the F3SG-RA, the following functions are configurable by the DIP Switch. Feature page Scan Code Selection p.27 PNP/NPN Selection p.28 External Test p.31 Interlock p.34 External Device Monitoring (EDM) p.40 Fixed Blanking p.79...
Page 137 Setting with DIP Switch 3-2. DIP Switch Make sure to test the operation of the F3SG-R after setting with DIP Switch to verify that the F3SG-R operates as intended. Make sure to stop the machine until the test is complete. Unintended settings may cause a person to go undetected, resulting in serious injury or death.
Page 138 Setting with DIP Switch 3-2-1. DIP Switch on Receiver The following functional settings are available by DIP Switches on the receiver. A receiver has two DIP Switches, both of which must be configured based on the table below. For functional details, see respective chapter in the Functional Details column.
Page 139 Setting with DIP Switch according to the settings of the DIP Switch. When the Position 8 is switched back to ON, the F3SG-RA operates according to the settings stored in the internal memory. Note that Scan Code and PNP/NPN Selection are not affected by the Position 8 but by the DIP Switch setting.
Page 140 Setting with DIP Switch 3-3. Setting by Teach-in 3-3-1. Setting Fixed Blanking by Teach-in  Overview You can teach-in the fixed blanking setting by interrupting the target area of the fixed blanking. The teach-in task is performed using the Push Switch. After completion of teach-in, check that the configuration have been properly done.
Page 141 Setting with DIP Switch (4) Teach-In and Check Processes When it is ensured that the F3SG-RA is in the Teach-in Mode, press the Push Switch (for within 1 s) to activate the scanning of the blocked area and automatically configure the setting related to the Fixed Blanking.
Page 142 Setting with DIP Switch Teach-in setting is valid Teach-in setting is invalid LED Indicator Status LED Indicator Status Blink Blink (5) Restart Press and hold the reset switch (for 1 s or longer) or power cycle the F3SG-RA to enable and activate the setting.
Page 143 Setting with DIP Switch 3-3-2. Setting Floating Blanking by Teach-in  Overview You can teach-in the floating blanking setting by interrupting with an object to monitor by floating blanking. The teach-in task is performed using the Push Switch. After completion of teach-in, check that the configuration have been properly done. ...
Page 144 Setting with DIP Switch (3) Transition to Teach-in Mode Press and hold the Push Switch (for 3 s or longer) to make the F3SG-RA transition to Teach-in Mode. Upon transition the scan is started for the blocked location. Move the blocking object in parallel with the F3SG-RA.
Page 145 Setting with DIP Switch *1 The number of blanked beams is configured with the maximum number of blocked beams in the teach-in process (steps (3) to (4)). Allowable beams are is configured with (Maximum blocked beams - Minimum blocked beams) in the teach-in process.
Page 146 Setting with DIP Switch Blanked Beams Floating Blanking 4 beams Disabled Blanked Beams Blanked Beams 5 beams 5 beams F3SG-RA/RE User’s Manual...
Page 147 Chapter 4 Wiring/Installation 4-1. Installation Considerations 4-1-1. Detection Zone and Approach 4-1-2. Safety Distance 4-1-3. Distance from Reflective Surfaces 4-1-4. Mutual Interference Prevention 4-2. Cascade Connection 4-2-1. Overview 4-2-2. Connection Procedure 4-3. Dimensions 4-3-1. Mounted with Standard Fixed Brackets (F39-LGF) 4-3-1-1.
Page 148 Wiring/Installation 4-4-3-1. Mounting with Standard Fixed Brackets (F39-LGF)159 4-4-3-2. Mounting with Standard Adjustable Brackets (F39-LGA) 160 4-4-3-3. Mounting with Top/Bottom Adjustable Brackets (F39- LGTB) 4-4-4. Beam Alignment Procedure 4-5. Wiring 4-5-1. Wiring Precautions 4-5-2. Power Supply Unit 4-5-3. Cable Connections(F3SG-RA Series) 4-5-3-1.
Page 149: Installation Considerations
Wiring/Installation 4-1. Installation Considerations 4-1-1. Detection Zone and Approach Install a protective structure so that the hazardous part of a machine can only be reached by passing through the sensor's detection zone. If access to the hazardous part by reaching over the detection zone of a vertically mounted F3SG-R cannot be excluded, the height of the detection zone and the safety distance shall be determined in consideration of such a risk.
Page 150 Wiring/Installation 4-1-2. Safety Distance The safety distance is the distance that must be set between the F3SG-R and a machine's hazardous part to stop the hazardous part before a person or object reaches it. The safety distance varies according to the standards of each country and the individual specifications of each machine. Always refer to the relevant standards.
Page 151 Wiring/Installation •Tm = Machine's response time (s) •Ts = Response time of the F3SG-R from ON to OFF (s) [Calculation example] When Tm = 0.05 s and Ts = 0.008 s: S = 1,600mm/s x (0.05 s + 0.008 s) + 850mm = 942.8 mm Possible Circumventing by Reaching Over the Detection Zone If access to the hazardous zone by reaching over the detection zone of vertically mounted F3SG-R...
Page 152 Wiring/Installation Height of upper edge of detection zone, b Height of hazardou 1000 1100 1200 1300 1400 1600 1800 2000 2200 2400 2600 s zone, a Additional distance to hazardous zone, Cro 2600 2500 2400 2200 2000 1800 1100 1100 1600 1150 1150...
Page 153: Safety Distance
Wiring/Installation Refer to Detection Zone Orthogonal to Direction of Approach under 4-1-2-1. Safety Distance Formulas according to ISO 13855/EN ISO 13855. Detection Zone Parallel to Direction of Approach Use K = 1,600 mm/s and C = (1200 - 0.4 x H) in formula (1) for calculation.
Page 154 Wiring/Installation 4-1-2-2. Safety Distance Formulas according to ANSI B11.19 If a person approaches the detection zone of the F3SG-R orthogonally, calculate the safety distance as shown below. S = K x (Ts + Tc + Tr + Tbm) + Dpf •...
Page 155: Distance From Reflective Surfaces
Wiring/Installation 4-1-3. Distance from Reflective Surfaces Install the sensor system so that it is not affected by reflective surfaces. Failure to do so may hinder detection, resulting in serious injury. Install the sensor system at distance D or further from highly reflective surfaces such as metallic walls, floors, ceilings, or workpieces, as shown below.
Page 156: Mutual Interference Prevention
Wiring/Installation 4-1-4. Mutual Interference Prevention Do not use the sensor system with mirrors in a retro-reflective configuration. Doing so may hinder detection. It is possible to use mirrors to alter the detection zone to a 90- degree angle. When using more than 1 set of F3SG-R in adjacent areas, the emitter of one F3SG-R may interfere with the receiver of the other, causing the safety functions to stop working properly.
Page 157 Wiring/Installation Refer to 2-4. Scan Code Selection for more information on the scan code feature. Refer to 3-2. DIP Switch for more information on setting the scan code by the DIP Switch. F3SG-RA/RE User’s Manual...
Page 158: Cascade Connection
Wiring/Installation 4-2. Cascade Connection F3SG-RA Series F3SG-RE Series The F3SG-RE cannot be used in cascade connection. 4-2-1. Overview Up to 3 sets of F3SG-RA can be series-connected. Cascade connection allows them to be used as a a safety light curtain, requiring only 1 set to be wired to a controller and preventing mutual interference. If any 1 set of series-connected F3SG-RA is blocked, both of the safety outputs turn OFF.
Page 159 Wiring/Installation The cascaded segments operate according to the DIP Switch settings of the primary sensor. The DIP Switch settings of the primary sensor do not affect the operation. Properly connect an emitter to another emitter, and a receiver to another receiver, as shown below. Do not series-connect an emitter and receiver.
Page 160: Connection Procedure
Wiring/Installation 4-2-2. Connection Procedure Remove the caps from the primary sensor. Loosen the screw (M2.5 cross-shaped) to remove the cap. Connect the the the primary sensor and the secondary sensor with the F39-JGR2W Cascading Cable (sold separately). If the length of the Cascading Cable is insufficient, connect the F39-JGB- Double-Ended Cable (sold separately) between the Cascading Cable and the power cable of the secondary sensor, as required.
Page 161: Dimensions
Wiring/Installation 4-3. Dimensions 4-3-1. Mounted with Standard Fixed Brackets (F39-LGF) 4-3-1-1. F3SG-RA Series  Backside Mounting 2-M5 or M6 Standard Fixed Bracket (F39-LGF) Standard Fixed Bracket (F39-LGF) 2-M5 or M6 24.85 24.85 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RA-30 Series F3SG-RA-14 Series Dimension A...
Page 162 Wiring/Installation  Side Mounting 2-M5 or M6 Standard Fixed Bracket (F39-LGF) Standard Fixed Bracket (F39-LGF) 2-M5 or M6 42.35 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RA-30 Series F3SG-RA-14 Series Dimension A C1+18 Dimension A C2+48 4-digit number of the type name 4-digit number of the type name Dimension C1...
Page 163 Wiring/Installation 4-3-1-2. F3SG-RE Series  Backside Mounting 2-M5 or M6 Standard Fixed Bracket (F39-LGF) Standard Fixed Bracket (F39-LGF) 2-M5 or M6 24.85 24.85 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RE30 Series F3SG-RE14 Series Dimension A Dimension A C2+30 4-digit number of the type name...
Page 164 Wiring/Installation  Side Mounting 2-M5 or M6 Standard Fixed Bracket (F39-LGF) Standard Fixed Bracket (F39-LGF) 2-M5 or M6 42.35 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RE30 Series F3SG-RE14 Series Dimension A Dimension A C2+30 4-digit number of the type name 4-digit number of the type name Dimension C1 Dimension C2...
Page 165 Wiring/Installation 4-3-1-3. Standard Fixed Bracket (25.8) (23.1) [ Unit : mm ] Material: Zinc alloy F3SG-RA/RE User’s Manual...
Page 166: Mounted With Standard Adjustable Brackets (F39-Lga)142
Wiring/Installation 4-3-2. Mounted with Standard Adjustable Brackets (F39-LGA) 4-3-2-1. F3SG-RA Series  Backside Mounting 48.6 2-M5 or M6 Standard Adjustable Bracket (F39-LGA) Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 24.85 24.85 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RA-30 Series F3SG-RA-14 Series Dimension A...
Page 167 Wiring/Installation  Side Mounting 48.6 2-M5 or M6 Standard Adjustable Bracket (F39-LGA) Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 42.35 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RA-30 Series F3SG-RA-14 Series Dimension A C1+18 Dimension A C2+48 4-digit number of the type name 4-digit number of the type name...
Page 168 Wiring/Installation 4-3-2-2. F3SG-RE Series  Backside Mounting 48.6 2-M5 or M6 Standard Adjustable Bracket (F39-LGA) Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 24.85 24.85 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RE30 Series F3SG-RE14 Series Dimension A Dimension A C2+30 4-digit number of the type name...
Page 169 Wiring/Installation  Side Mounting 48.6 2-M5 or M6 Standard Adjustable Bracket (F39-LGA) Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 42.35 < Screw: M5 or M6 > [ Unit : mm ] F3SG-RE30 Series F3SG-RE14 Series Dimension A Dimension A C2+30 4-digit number of the type name 4-digit number of the type name Dimension C1...
Page 170: Standard Adjustable Bracket
Wiring/Installation 4-3-2-3. Standard Adjustable Bracket 45.1 34.5 31.8 [ Unit : mm ] Material: Zinc alloy, Fluorochemical lubricant oil F3SG-RA/RE User’s Manual...
Page 171: Mounted With Top/Bottom Adjustable Brackets (F39-Lgtb)
Wiring/Installation 4-3-3. Mounted with Top/Bottom Adjustable Brackets (F39-LGTB) and Standard Adjustable Brackets (F39-LGA) 4-3-3-1. F3SG-RA Series  F3SG-RA Series Except F3SG-4RA0190-30 and F3SG-4RA0160-14 [Backside Mounting] 2-M4 (hexagon socket bolt hole size: S3) Top/Bottom Adjustable Bracket 26.5 (F39-LGTB) 48.6 23.2 2-M5 or M6 2-M8 Backside: 2-M5 (hexagon socket...
Page 172 Wiring/Installation [Side Mounting] 2-M4 (hexagon socket bolt hole size: S3) 50.35 26.5 23.2 Top/Bottom 51.65 Adjustable Bracket 2-M5 or M6 2-M8 (F39-LGTB) Backside: 2-M5 (hexagon socket bolt hole size: S3) 40.8 M3 (hexagon socket bolt hole size: S2.5) Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 2-M5 or M6...
Page 173 Wiring/Installation  F3SG-4RA0190-30 and F3SG-4RA0160-14 [Backside Mounting] 2-M4 (hexagon socket bolt hole size: S3) Top/Bottom Adjustable Bracket 26.5 (F39-LGTB) 48.6 23.2 2-M5 or M6 2-M8 Backside: 2-M5 13.6 (hexagon socket bolt hole size: S3) 40.8 Top/Bottom Adjustable Bracket (F39-LGTB) <Screw for Top/Bottom Adjustable <Screw for Top/Bottom Adjustable Bracket: M5 or M6>...
Page 174 Wiring/Installation [Side Mounting] 2-M4 (hexagon socket bolt hole size: S3) 44.6 26.5 Top/Bottom 23.2 51.65 Adjustable Bracket 2-M5 or M6 2-M8 (F39-LGTB) Backside: 2-M5 (hexagon socket bolt hole size: S3) 40.8 Top/Bottom Adjustable Bracket (F39-LGTB) <Screw for Top/Bottom Adjustable <Screw for Top/Bottom Adjustable Bracket: M5 or M6>...
Page 175 Wiring/Installation  Connected with Optional Accessories • Connected with Cascading Cable (F39-JGR2W) (Enlarged view of connected area) Cascading Cable (F39-JGR2W) Top/Bottom Adjustable Bracket (F39-LGTB) Cascading Cable (F39-JGR2W) Top/Bottom Adjustable Bracket (F39-LGTB) [ Unit : mm ] • Connected with Bluetooth Communication Unit (F39-BT) (Enlarged view of connected area) ®...
Page 176 Wiring/Installation • Connected with Lamp (F39-LP) or Lamp and Bluetooth Communication Unit (F39-BTLP) ® (Enlarged view of connected area) Receiver Lamp(F39-LP)/ Lamp and Bluetooth ® Communication Unit (F39-BTLP) Top/Bottom Adjustable Bracket (F39-LGTB) Lamp(F39-LP)/ Lamp and Bluetooth Communication ® Unit (F39-BTLP) Top/Bottom Adjustable Bracket (F39-LGTB)
Page 177 Wiring/Installation 4-3-3-2. F3SG-RE Series  F3SG-RE Series Except F3SG-4RE019030 and F3SG-4RE016014 [Backside Mounting] 2-S3 Top/Bottom Adjustable Bracket 26.5 (F39-LGTB) 48.6 23.2 2-M8 2-M5 or M6 Backside : 2-S3 40.8 13.6 Standard S2.5 Adjustable Bracket (F39-LGA) 2-M5 or M6 2-M5 or M6 24.85 24.85 24.85...
Page 178 Wiring/Installation [Side Mounting] 2-S3 50.35 Top/Bottom Adjustable Bracket 26.5 (F39-LGTB) 23.2 51.65 2-M8 2-M5 or M6 Backside : 2-S3 40.8 Standard Adjustable Bracket (F39-LGA) 2-M5 or M6 2-M5 or M6 S2.5 42.35 Top/Bottom Adjustable Bracket (F39-LGTB) <Screw for Top/Bottom Adjustable <Screw for Top/Bottom Bracket: M5 or M6>...
Page 179 Wiring/Installation  F3SG-4RE019030 and F3SG-4RE016014 [Backside Mounting] 2-S3 Top/Bottom Adjustable Bracket 26.5 (F39-LGTB) 48.6 23.2 2-M8 2-M5 or M6 13.6 Backside : 2-S3 40.8 Top/Bottom Adjustable Bracket (F39-LGTB) <Screw for Top/Bottom Adjustable <Screw for Top/Bottom Bracket: M5 or M6> Adjustable Bracket: M8> [ Unit : mm ] F3SG-4RE019030 F3SG-4RE016014...
Page 180 Wiring/Installation [Side Mounting] 2-S3 44.6 Top/Bottom Adjustable Bracket 26.5 (F39-LGTB) 23.2 51.65 2-M8 2-M5 or M6 40.8 Backside : 2-S3 Top/Bottom Adjustable Bracket (F39-LGTB) <Screw for Top/Bottom Adjustable <Screw for Top/Bottom Bracket: M5 or M6> Adjustable Bracket: M8> [ Unit : mm ] F3SG-4RE019030 F3SG-4RE016014 Dimension C1...
Page 181 Wiring/Installation 4-3-3-3. Top/Bottom Adjustable Bracket (F39-LGTB) Top/Bottom Bracket (1) 2-M5 (Screw (2)) Top/Bottom Bracket (2) Top/Bottom Bracket (3) 23.2 48.25 26.5 2-M4 (Screw (1)) [ Unit : mm ] Material: Stainless steel 40.8 4-3-3-4. Top/Bottom Adjustable Bracket (F39-LGTB-1) Note: F39-LGTB-1 does not come with Top/ Top/Bottom Bottom Bracket (3) and Screw (1).
Page 182 Wiring/Installation 4-4. Mounting 4-4-1. Mounting Method You can mount the F3SG-R with Standard Fixed Brackets and Standard Adjustable Brackets. Any of these mounting methods allows the user to use the same bracket for the backside mounting and side mounting. 4-4-2. Number of Brackets Required The numbers of brackets required according to the protective heights of the sensor are as follows: •...
Page 183 Wiring/Installation 4-4-3. Mounting Procedure  Before mounting (in case of F3SG-RA) When it is required to configure functions with DIP Switch, do so before installing the F3SG-RA in your site, according to the procedure described in 3-2. DIP Switch. The mounting procedure is the same between F3SG-RA and F3SG-RE series. 4-4-3-1.
Page 184 Wiring/Installation Securely tighten the screws to fix the Standard Fixed Bracket to the mounting position of the wall surface. (Fig. 4) <Backside mounting> <Side mounting> Fix the Standard Fix the Standard Fixed Bracket to the Fixed Bracket to the wall surface with screws wall surface with screws Fig.
Page 185 Wiring/Installation Adjust the Standard Adjustable Bracket to the mounting position of the wall surface. Securely tighten the Screw (2) to fix the Standard Adjustable Bracket to the housing of the F3SG-R. The recommended torque to tighten the Screw (2) is 2.0 N•m. (Fig. 3) <Backside mounting>...
Page 186 Wiring/Installation Power the F3SG-R on to perform beam alignment. Move the emitter and receiver from side to side (Fig. 5) to align them to a center position where the Stable-state indicator (STB, green) of the receiver is illuminated while checking the state of the top and bottom beams with the Top-beam-state indicator (TOP, blue) and Bottom-beam-state indicator (BTM, blue) of the receiver.
Page 187 Wiring/Installation 4-4-3-3. Mounting with Top/Bottom Adjustable Brackets (F39-LGTB) Loosen the Screw (1) (hexagon socket head cap screw (M4×10)) of Top/Bottom Bracket (3) and change the angle of the Top/Bottom Bracket (3) according to its mounting direction. Then loosen the Screw (2) (low head hexagon socket head cap screw (M5×10)) of Top/Bottom Bracket (2). (Fig. 1) Screw (2) Adjust the angle (Low head hexagon socket head...
Page 188 Wiring/Installation Securely tighten screws to fix the Top/Bottom Adjustable Bracket to the mounting position of the wall surface. (Fig. 3) <Backside mounting> <Side mounting> Fix the Top/Bottom Adjustable Bracket to the wall surface with screws Fix the Top/Bottom Adjustable Bracket to the wall surface with screws Fig.
Page 189 Wiring/Installation Securely tighten the Screw (1) to fix the Top/Bottom Adjustable Bracket to the housing of the F3SG-R. The recommended torque to tighten the Screw (1) is 3.0 N•m. (Fig. 6) <Backside mounting > <Side mounting> Screw (1) Screw (1) Securely Securely tighten these...
Page 190 Wiring/Installation 4-4-4. Beam Alignment Procedure The Standard Adjustable Bracket and Top/Bottom Adjustable Bracket allow beam alignment after fixing the bracket to a wall surface. The Standard Fixed Bracket does not allow beam alignment. Verify the following points: - The optical surfaces of the emitter and receiver are clean. - There is no interrupting object in the detection zone of the F3SG-R.
Page 191 Wiring/Installation 4-5. Wiring 4-5-1. Wiring Precautions Double or reinforced insulation from hazardous voltage must be applied to all input and output lines. Failure to do so may result in electric shock. When using PNP output, connect the load between the output and 0 V line. When using NPN output, connect the load between the output and +24 VDC line.
Page 192 Wiring/Installation 4-5-2. Power Supply Unit For the F3SG-R to comply with IEC 61496-1 and UL 508, the DC power supply unit must satisfy all of the following conditions: ± • Must be within the rated power voltage (24 V DC 20%) •...
Page 193 Wiring/Installation 4-5-3. Cable Connections(F3SG-RA Series) Extension of the cable must be within a specified length. If it isn't, safety function may not work properly, resulting in danger. Perform wiring according to the following procedure. Connect an emitter cable (F39-JG-L, gray, sold separately) to the emitter-side power cable (gray). Connect a receiver cable (F39-JG-D, black, sold separately) to the receiver-side power cable (black).
Page 194 Wiring/Installation Emitter cable (Gray) Receiver cable (Black) L (m) F39-JG3A-L F39-JG3A-D F39-JG7A-L F39-JG7A-D F39-JG10A-L F39-JG10A-D F39-JG15A-L F39-JG15A-D F39-JG20A-L F39-JG20A-D 4-5-3-2. Double-Ended Cable  Double-Ended Cable for Emitter: Cable for extension (F39-JGB-L, sold separately) (Unit: mm) 44.7 40.7 M12 IP67 connector M12 IP67 connector Insulated vinyl round cable dia.
Page 195 Wiring/Installation  Double-Ended Cable for Receiver: Cable for extension (F39-JGB-D, sold separately) (Unit: mm) 44.7 40.7 M12 IP67 connector M12 IP67 connector Insulated vinyl round cable dia. 6.6, 8-wire (4-pair) (Cross section of conductor: 0.38 mm /insulator diameter: dia. 1.2 mm) <Internal wiring diagram>...
Page 196 Wiring/Installation 4-5-3-3. Cascading Cable  Cascading Cable for Emitter (F39-JGR2W-L, sold separately) (Unit: mm) 23.4 40.7 M12 IP67 Connector M2.5 screw Connector Insulated vinyl round cable dia. 6 mm, 5-wire (Cross section of conductor: 0.15 mm /Insulator diameter: dia. 1 mm) ...
Page 197 Wiring/Installation 4-5-3-4. Extending Cable Length with Commercially Available Cable When you need to use a cable that is not specified by OMRON, use a cable that satisfies the following specifications. 1. Emitter: 5-wire Receiver: 8-wire 2. 0.3 mm or larger, conductor resistance 0.058 ohms/m max. 3.
Page 198 Wiring/Installation  Emitter Adapter Cable (A) (F39-JGR3M-A55-L, sold separately) (Unit: mm) 44.7 40.7 M12 IP67 connector, 5-wire Insulated vinyl round cable dia. 6-mm M12 IP67 connector, 5-wire <Internal wiring diagram> Connected to connector of MS4800 Connected to Power Cable or transmitter cable Emitter Adapter Cable (A) Double-Ended Cable of F3SG-RA emitter...
Page 199 Wiring/Installation 4-5-3-6. Adapter Cable (B) This Adapter Cable converts the wiring for F3SJ-A/-B Series Safety Light Curtain to that for F3SG-RA Series. <Wiring conversion> Adapter Cable Model Converted from Converted to F39-JGR3M-B58-L F3SJ-A/-B series emitter F3SG-RA series emitter F39-JGR3M-B88-D F3SJ-A/-B series receiver F3SG-RA series receiver Note that the Adaptor Cable restricts the following functions related to wiring.
Page 200 Wiring/Installation  Emitter Adapter Cable (B) (F39-JGR3M-B58-L, sold separately) (Unit: mm) 44.7 40.7 M12 IP67 connector, 8-wire Insulated vinyl round cable dia. 6-mm M12 IP67 connector, 5-wire <Internal wiring diagram> Connected to connector of F3SJ-A/B Connected to Power Cable or emitter cable Double-Ended Cable of F3SG-RA emitter Emitter Adapter Cable (B)
Page 201 Wiring/Installation 4-5-3-7. Simple wiring connector System with Y-Joint Plug/Socket Connector Reduced wiring can be achieved by using a Y-Joint Plug/Socket Connector (F39-GCNY2, sold separately). When using the Simple wiring connector system, the External Test cannot be used. Make sure the Position 4 of the emitter's DIP Switch is set to 24 V Active. ...
Page 202 Wiring/Installation 4-5-3-8. Simple wiring connector System with 4-Joint Plug/Socket Connector Reduced wiring can be achieved by connecting the F3SG-RA (PNP output) and a Smart Muting Actuator (F3W-MA, sold separately) with a 4-Joint Plug/Socket Connector (F39-GCN4-, sold separately). The cable connection of the connector is as follows. Plug/Socket Description Connect an F3W-MA to this socket.
Page 203 Wiring/Installation  4-Joint Plug/Socket Connector for Emitter (F39-GCN4-L, gray, sold separately) 58.3 (Unit: mm) 13.6 M12 IP67 connector, 5-wire M12 IP67 connector, 5-wire M12 x 1 M12 IP67 connector, 5-wire M12 x 1 M12 IP67 connector, 5-wire Material: PBT (Main body) <Internal wiring diagram>...
Page 204 Wiring/Installation  4-Joint Plug/Socket Connector for Receiver (F39-GCN4-D, black, sold separately) 58.3 (Unit: mm) 13.6 M12 IP67 connector, 8-wire M12 IP67 connector, 8-wire M12 x 1 M12 x 1 M12 IP67 connector, 8-wire M12 IP67 connector, 8-wire Material: PBT (Main body) <Internal wiring diagram>...
Page 205 Wiring/Installation 4-5-4. Cable Connections(F3SG-RE Series) Extension of the cable must be within a specified length. If it isn't, safety function may not work properly, resulting in danger. There are no dedicated cables for the F3SG-RE series. You can use the cables that satisfy the following requirements: 1.
Page 206 Wiring/Installation If the length of the Connector Connected to Cable, Socket on One Cable End (XS5F-D421-80-F) is insufficient, use 1 or more Connectors Connected to Cable, Socket and Plug on Cable Ends (XS5W- D421-81-F) to extend the length, as required. The total cable extension length of the power cable must be 100 m max.
Page 207 Wiring/Installation  Emitter Adapter Cable (C) (F39-JGR3M-C48-L, sold separately) (Unit: mm) 44.7 40.7 M12 IP67 connector, 8-wire Insulated vinyl round cable dia. 6-mm M12 IP67 connector, 5-wire <Internal Wiring> Connected to connector of F3SJ-A/B Connected to Power Cable or emitter cable Double-Ended Cable of F3SG-RE emitter Emitter Adapter Cable (C) F3SJ Series...
Page 208 Wiring/Installation 4-5-4-4. Simple wiring connector System Reduced wiring can be achieved by using a Y-Joint Plug/Socket Connector (F39-GCNY1, sold separately). When using the Simple wiring connector system, the Operating Range Selection is fixed to Long Mode.  Y-Joint Plug/Socket Connector (F39-GCNY1, sold separately) Plug marked with ●...
Page 209 Wiring/Installation 4-5-5. Functional Earth Connection The F3SG-R operates properly without functional earth connection in a general industrial environment. If the F3SG-R fails due to electrical noise, connecting the F3SG-R to the functional earth may work to prevent the noise. It is recommended the functional earth terminal of the F3SG-R be connected to functional earth cables.
Page 210 Wiring/Installation F3SG-RA/RE User’s Manual...
Page 211 Chapter 5 Input/Output Circuit and Applications 5-1. Input/Output Circuit 5-1-1. Entire Circuit Diagram 5-1-1-1. F3SG-RA Series 5-1-1-2. F3SG-RE Series 5-1-2. Input Circuit Diagram by Function 5-1-2-1. F3SG-RA Series 5-1-2-2. F3SG-RE Series 5-2. Wiring Examples(F3SG-RA Series) 5-2-1. Standalone F3SG-RA using PNP Outputs 5-2-1-1.
Page 212 Input/Output Circuit and Applications 5-2-3-2. Manual Reset Mode, EDM enabled and NPN Outputs205 5-2-3-3. Y-Joint Plug/Socket Connector using NPN outputs206 5-2-3-4. Pre-Reset Mode using NPN Output 5-2-4. Muting using NPN Outputs 5-2-4-1. Standard Muting Mode/Exit-Only Muting Mode using NPN Outputs 5-2-4-2.
Page 213 Input/Output Circuit and Applications 5-1. Input/Output Circuit 5-1-1. Entire Circuit Diagram The entire circuit diagram of the F3SG-R is shown below. The numbers in the circles indicate the connector's pin numbers. 5-1-1-1. F3SG-RA Series  PNP Output Indicator +24 VDC Brown Test Input Black...
Page 214 Input/Output Circuit and Applications  NPN Output Indicator +24 VDC Brown Black TEST Test Input Circuit Emitter White Not used Main Circuit Yellow Not used Blue Brown RESET Yellow Reset input circuit Pink MUTE B Muting input circuit B Load Gray MUTE A Muting input...
Page 215 Input/Output Circuit and Applications 5-1-1-2. F3SG-RE Series  PNP Output Indicator +24 V Brown Operating Range Operating Range White Select Input Select Input circuit Emitter Black Not used Main Circuit Blue Brown Receiver White OSSD 2 Main Circuit 2 Load Black OSSD 1 Receiver...
Page 216 Input/Output Circuit and Applications  NPN Output Indicator +24 V Brown Operating Range White Select Input Operating Range Select Input circuit Emitter Black Not used Main Circuit Blue Brown Load Receiver White OSSD 2 Main Circuit 2 Load Black OSSD 1 Receiver Main Circuit 1 Indicator...
Page 217 Input/Output Circuit and Applications 5-1-2. Input Circuit Diagram by Function The input circuit diagrams of by function are shown below. 5-1-2-1. F3SG-RA Series  TEST <24 V Active> <0 V Active> +24 VDC +24 VDC Short circuit current: Emitter Emitter approx.
Page 218 Input/Output Circuit and Applications 5-2. Wiring Examples(F3SG-RA Series) Examples of a motor control system using the F3SG-RA are shown below. This chapter shows examples equivalent to up to PLe, Category 4 (ISO13849-1). 5-2-1. Standalone F3SG-RA using PNP Outputs 5-2-1-1. Auto Reset Mode, EDM disabled and PNP Outputs The following is the example of Muting disabled, External Device Monitoring disabled, Auto-Reset Mode, PNP outputs and External Test in 24 V Active.
Page 219 Input/Output Circuit and Applications 5-2-1-2. Manual Reset Mode, EDM enabled and PNP Outputs The following is the example of Muting not used, External Device Monitoring enabled, Manual Reset mode, PNP output and External Test in 24 V Active. [DIP Switch settings] *2 Function DIP-SW1 DIP-SW2...
Page 220 Input/Output Circuit and Applications 5-2-1-3. Y-Joint Plug/Socket Connector using PNP outputs The following is the example of Muting not used, External Device Monitoring enabled, Manual Reset mode, and PNP output. [DIP Switch settings] *3 Function DIP-SW1 DIP-SW2 EDM Enabled Receiver Manual Reset PNP (factory default setting) Emitter...
Page 221 Input/Output Circuit and Applications 5-2-1-4. Pre-Reset Mode using PNP Output The following is the example of External Device Monitoring disabled, Pre-Reset mode, PNP output and External Test in 24 V Active. [DIP Switch settings] *4 Function DIP-SW1 DIP-SW2 EDM Disabled (factory default setting) Receiver Pre-Reset PNP (factory default setting)
Page 222 Input/Output Circuit and Applications 5-2-2. Muting using PNP Outputs 5-2-2-1. Standard Muting Mode/Exit-Only Muting Mode using PNP Outputs The following is the example of External Device Monitoring disabled, Auto Reset mode, PNP output and External Test in 24 V Active. [DIP Switch settings] *6 Function DIP-SW1...
Page 223 Input/Output Circuit and Applications 5-2-2-2. F3SG-RA with Y-Joint Plug/Socket Connector in Standard Muting Mode/Exit-Only Muting Mode using PNP outputs The following is the example of External Device Monitoring disabled, Auto Reset mode and PNP output. [DIP Switch settings] *5 Function DIP-SW1 DIP-SW2 EDM Disabled (factory default setting)
Page 224 Input/Output Circuit and Applications 5-2-2-3. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using PNP Outputs The following is the example of External Device Monitoring disabled, Auto Reset mode, PNP output and External Test in 24 V Active. [DIP Switch settings] *5 Function DIP-SW1 DIP-SW2...
Page 225 Input/Output Circuit and Applications 5-2-2-4. Standard Muting Mode with four Muting Sensors using PNP Outputs The following is the example of External Device Monitoring disabled, Auto Reset mode, PNP output and External Test in 24 V Active. [DIP Switch settings] *5 Function DIP-SW1 DIP-SW2...
Page 226 Input/Output Circuit and Applications 5-2-2-5. Standard Muting Mode with F3W-MA (T-Shaped Configuration with 4-Joint Plug/Socket Connector) The following is the example of F3SG-RA with Scan Code B, External Device Monitoring disabled, Auto Reset mode, PNP output and External Test in 24 V Active, and F3W-MA with Scan Code A, Chattering and Void Space Prevention 1, Off-Delay 100 ms and Muting Enable disabled.
Page 227 Input/Output Circuit and Applications 5-2-2-6. Exit-Only Muting Mode with F3W-MA (L-Shaped Configuration with 4-Joint Plug/Socket Connector) The following is the example of F3SG-RA with Scan Code A, External Device Monitoring disabled, Auto Reset mode, PNP output and External Test in 24 V Active, and F3W-MA with Scan Code B, Chattering and Void Space Prevention 1, Off-Delay 100 ms and Muting Enable enabled.
Page 228 Input/Output Circuit and Applications 5-2-3. Standalone F3SG-RA using NPN Outputs 5-2-3-1. Auto Reset Mode, EDM disabled and NPN Outputs The following is the example of Muting disabled, External Device Monitoring disabled, Auto-Reset Mode, NPN outputs and External Test in 0 V Active. [DIP Switch settings] *1 Function DIP-SW1...
Page 229 Input/Output Circuit and Applications 5-2-3-2. Manual Reset Mode, EDM enabled and NPN Outputs The following is the example of Muting not used, External Device Monitoring enabled, Manual Reset mode, NPN output and External Test in 0 V Active. [DIP Switch settings] *2 Function DIP-SW1 DIP-SW2...
Page 230 Input/Output Circuit and Applications 5-2-3-3. Y-Joint Plug/Socket Connector using NPN outputs The following is the example of Muting not used, External Device Monitoring enabled, Manual Reset mode and NPN output. [DIP Switch settings] *3 Function DIP-SW1 DIP-SW2 EDM Enabled Receiver Manual Reset Emitter External Test: 24 V Active (factory default setting) *4...
Page 231 Input/Output Circuit and Applications 5-2-3-4. Pre-Reset Mode using NPN Output The following is the example of External Device Monitoring enabled, Pre-Reset mode, NPN output and External Test in 0 V Active. [DIP Switch settings] *2 Function DIP-SW1 DIP-SW2 EDM Enabled Receiver Pre-Reset Emitter...
Page 232 Input/Output Circuit and Applications 5-2-4. Muting using NPN Outputs 5-2-4-1. Standard Muting Mode/Exit-Only Muting Mode using NPN Outputs The following is the example of External Device Monitoring enabled, Auto Reset mode, NPN output and External Test in 0 V Active. [DIP Switch settings] *3 Function DIP-SW1...
Page 233 Input/Output Circuit and Applications 5-2-4-2. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using NPN Outputs The following is the example of External Device Monitoring enabled, Auto Reset mode, NPN output and External Test in 0 V Active. [DIP Switch settings] *3 Function DIP-SW1 DIP-SW2...
Page 234 Input/Output Circuit and Applications 5-2-4-3. Standard Muting Mode with four Muting Sensors using NPN Outputs The following is the example of External Device Monitoring enabled, Auto Reset mode, NPN output and External Test in 0 V Active. [DIP Switch settings] *3 Function DIP-SW1 DIP-SW2...
Page 235 Input/Output Circuit and Applications 5-3. Wiring Examples (F3SG-RE Series) Examples of a motor control system using the F3SG-RE are shown below. This chapter shows examples equivalent to ISO 13849-1 (PL e/Category 4). 5-3-1. Short Mode +24 V Power Supply Functional Earth Safety Controller *1 *2 *1.
Page 236 Input/Output Circuit and Applications 5-3-2. Long Mode +24 V Power Supply Safety Controller *1 *2 *1. Refer to 5-4. Connectable Safety Control Units for more information. *2. The safety controller and the F3SG-R must share the power supply or be connected to the common terminal of the power supply. Unblocked Beam state Blocked...
Page 237 Input/Output Circuit and Applications 5-3-3. Standalone F3SG-RE with Y-Joint Plug/Socket Connector When using the Y-Joint Plug/Socket Connector, the Operating Range Selection is fixed to Long Mode. Wrong wiring causes the F3SG-RE to go to the Lockout state due to Operating Range Selection Setting error. Make sure that the cables are properly wired to the connector, referring to 4-5-4-4.
Page 238 Input/Output Circuit and Applications 5-4. Connectable Safety Control Units The F3SG-RA or F3SG-RE with PNP output can be connected to the safety control units listed in the table below. Connectable Safety Control Units (PNP output) G9SA-301 G9SX-AD322-T G9SP-N10S □ G9SA-321-T G9SX-ADA222-T G9SP-N10D G9SA-501...
Page 239 Chapter 6 Checklists 6-1. Pre-Operation Checklists 6-2. Maintenance Checklists F3SG-RA/RE User’s Manual...
Page 240 Checklists 6-1. Pre-Operation Checklists Make sure Responsible Person tests the operation of the F3SG-R after installation to verify that the F3SG-R operates as intended. Make sure to stop the machine until the test is complete. Unintended function settings may cause a person to go undetected, resulting in serious injury. After installation, the highest level administrator must use the following checklist to verify the operation, placing a check mark in each of the boxes.
Page 241 Checklists When 2 or more F3SG-R systems are used, they are in cascade connection or prevented from mutual interference with each other. On a secondary sensor farthest from its power supply, either of the following is attached: - End Cap - Lamp (F39-LP and F39-BTLP, sold separately) - Bluetooth Communication Unit (F39-BT, sold separately)
Page 242 Checklists state, the ON/OFF indicator remains red. The RESET input turns the ON/OFF indicator to green. When muting function is used, minimum muting time limit required must be set. When muting function's operation mode is exit-only muting mode, minimum muting end wait time required must be set.
Page 243 Checklists 6-2. Maintenance Checklists Perform daily and 6-month inspection for the F3SG-R. Otherwise, the system may fail to work properly, resulting in serious injury. Do not try to disassemble, repair, or modify this product. Doing so may cause the safety functions to stop working properly.
Page 244 Checklists The test rod is detected when it is moved around in the detection zone as shown in the diagram below. In other words, when a test rod is inserted into the detection zone, the Stable-state indicator turns OFF and the ON/OFF indicator turns red. When fixed blanking function is used, you must ensure that all blanked zones in the detection zone are covered by a hard barrier guard and there must be no zone in the detection zone where the test rod goes undetected.
Page 245 Checklists should not occur when a human body enters a hazardous zone of a machine. When muting function setting is changed, a muting sensor must consist of 2 independent devices. When the configuration of the cascade connection is changed, either of the following is attached on a secondary sensor farthest from its power supply: - End Cap - Lamp (F39-LP and F39-BTLP, sold separately)
Page 246 Checklists F3SG-RA/RE User’s Manual...
Page 247 Chapter 7 Appendix 7-1. Troubleshooting 7-1-1. Lockout State 7-1-2. Warning 7-1-3. Troubles Other Than in Lockout State 7-2. Optional Accessories(Sold Separately) 7-3. Glossary 7-4. Revision History F3SG-RA/RE User’s Manual...
Page 248 Appendix 7-1. Troubleshooting  F3SG-RA Series <Emitter> <Receiver> 1. Top-beam-state indicator (Blue) 2. PNP/NPN mode indicator (Green) 3. Response time indicator (Green) 4. Sequence error indicator (Yellow) 5. Blanking indicator (Green) 6. Configuration indicator (Green) 1. Test indicator (Green) 7. Interlock indicator (Yellow) 2.
Page 249 Appendix LED Blinking Pattern: The timing chart below shows the blinking frequency of the LED blinking patterns (blinking once through seven times) described in the following pages. Blinking: Once Blinking: Twice Blinking: Three times Blinking: Four times Blinking: Five times Blinking: Six times Blinking: Seven times 0.2 s...
Page 250 Appendix 7-1-1-2. Troubleshooting Identify an error according to the combination of the indicators when the error occurs. See the following troubleshooting tables to take measures. Blink <Indicator status at lockout: Receiver> Combination of Indicators and Error Description [Error Description] Cap error Other sensor error Blanking monitoring error BLANK...
Page 251 Appendix Description Error code Cause and measures Cap error A cap may be detached. Attach the cap properly. Other sensor error Other sensor being cascaded caused an error. Check the indicator of the sensor. Blanking monitoring error An error is detected by the fixed blanking monitoring function or the floating blanking monitoring function.
Page 252 Appendix Description Error code Cause and measures Operating range selection setting The setting of the operating range selection may be incorrect. error • F3SG-RA: Check if the Operating Range Selection of the DIP Switch is properly set. • F3SG-RE: Check if the Operating Range Select Input line is properly wired. •...
Page 253 Appendix Description Error code Cause and measures Internal error Error code An error may have occurred in the internal circuit. other than Replace the F3SG-R. those above F3SG-RA/RE User’s Manual...
Page 254 Appendix 7-1-2. Warning 7-1-2-1. Description If an error is detected that prevents the F3SG-R to continue normal operation, the STB or SEQ indicator blinks to notify warning information according to the error. The F3SG-R continues normal operation. In the Auto Reset mode, the F3SG-R automatically recovers from the warning status when the cause of the error is solved.
Page 255 Appendix 7-1-2-3. Muting Sequence Error Indication Sequence error indicator Cause and measures Power supply may have been turned ON with muting input A or B being ON. Check the condition of the muting sensors and light curtains. Muting input B may have been turned ON before muting input A was turned ON. Check the condition of the muting sensors.
Page 256 Appendix 7-1-2-4. Interlock Sequence Error Indication The following table is applied only when the pre-reset function is being enabled. Sequence error indicator Cause and measures The reset or pre-reset switch may have been pressed before the light curtain receives light. Check the reset input and pre-reset input wiring.
Page 257 Appendix 7-2. Optional Accessories(Sold Separately) Single-Ended Cable (for emitter) Appearance Model Cable length Specifications F39-JG3A-L M12 connector (5-pin), 5 wires F39-JG7A-L F39-JG10A-L 10 m F39-JG15A-L 15 m F39-JG20A-L 20 m Single-Ended Cable (for receiver) Appearance Model Cable length Specifications F39-JG3A-D M12 connector (8-pin), 8 wires F39-JG7A-D F39-JG10A-D...
Page 258 Appendix Cascading Cable (two cables per set, one for emitter and one for receiver) Appearance Model Cable length Specifications F39-JGR2W 0.2 m Emitter cable: Cap (5-pin), M12 connector (5-pin) Receiver cable: Cap (8-pin), M12 connector (8-pin) Single-Ended Cable (Round Water-resistant Connector: Connector Connected to Cable, Socket on One Cable End) Appearance Model...
Page 259 Appendix Adapter Cable (C) Appearance Model Cable length Specifications F39-JGR3M-C48-L 0.3 m M12 connector. Used to convert the wiring for F3SJ-A/-B Series Safety Light Curtain to that for F3SG-RE Series. F39-JGR3M-C48-D F39-JGR3M-C48-L: for emitter F39-JGR3M-C48-D: for receiver Y-Joint Plug/Socket Connector Appearance Model Cable length...
Page 260 Appendix Interface Unit Appearance Model Remarks F39-GIF F39-GIF interface unit to connect the F3SG-RA receiver to a USB port of the PC. Accessories: 0.3-m Dedicated Cable 1 (1), 2-m Dedicated Cable 2 (1), Instruction Manual Bluetooth Communication Unit ® Appearance Model Remarks F39-BT...
Page 261 Appendix Laser Alignment Kit Appearance Model Application Remarks F39-PTG You can attach this to Red semiconductor laser F3SG-R. The laser light (wavelength 650 nm, 1 mW max., JIS assists coarse beam Class 2, IEC Class 2, FDA Class II) alignment. Standard Fixed Bracket Appearance Model...
Page 262 Appendix Test Rod Appearance Model Diameter F39-TRD14 14 mm dia., Length: 250 mm, Material: ABS resin F39-TRD30 30 mm dia., Length: 250 mm, Material: ABS resin To check operation before use, purchase and use the test rod. Spatter Protection Cover (two pieces per set, one for emitter and one for receiver) Appearance Model Remarks...
Page 263 Appendix Control Unit Appearance Model Output Remarks □ G9SA-301-P Safety output (relay): NO • An F39-J GA Single-Ended contact x 3 Cable is required. Auxiliary output (relay): NC • An F3SG-R with NPN output can contact x 1 be connected. Control Unit Appearance Model...
Page 264 Appendix Control Unit Appearance Model Output Remarks G9SP-N10S Safety output (solid-state): • An F39-JGA Single-Ended source output (PNP) x 4 Cable is required. Test output (solid-state): source • An F3SG-R with PNP output can output (PNP) x 4 be connected. Standard output (solid-state): source output (PNP) x4 G9SP-N10D...
Page 265 Appendix 7-3. Glossary Term Description Accumulated load switching frequency Total number of operations of a load to be connected to the F3SG-RA, from when the F3SG-RA is first energized until the present time. Allowable Beams Dynamic Muting: Area(s) (or beam(s)) to be added in a Dynamic Muting zone, in order to prevent an accidental interruption of the F3SG-RA due to vibration.
Page 266 Appendix Term Description Interlock reset Cancels the Interlock state. Inverted signal output mode In this mode, the logic of the Auxiliary output signal is reversed. Light level diagnosis information Information to be signaled to the Auxiliary output or Lamp when the Safety output is in the ON state and when the incident light level is from 100% to 170% of the ON-threshold value for 10 seconds or more.
Page 267 Appendix Term Description PELV Protected Extra Low Voltage. A grounded circuit separated by double insulation or equivalent from hazardous voltage. It does not generate voltage that exceeds ELV under normal conditions and under single-fault conditions. Normally, protection against direct contact is required. PNP/NPN Selection Function to select the safety output type between PNP and NPN.
Page 268 Appendix Term Description Teach-in Function to configure target beams of the following functions by blocking the beams. - Fixed Blanking - Floating Blanking Troubleshooting support signal Information to be signaled to the Auxiliary output or Lamp when any one of a Muting Sequence Error, Interference/Vibration Information and Light Level Diagnosis Information signals is in the ON state.
Page 269 Appendix 7-4. Revision History A manual revision code appears as a suffix to the manual number at the bottom of the front and back covers of this manual. Z352-E1- 10 Revision No. Revision Revision date Revisions symbol October, 2014 First edition December, 2014 - Added Lamp.
Page 270 OMRON Corporation Industrial Automation Company (Manufacturer) Authorized Distributor: Shiokoji Horikawa, Shimogyo-ku, Kyoto, 600-8530 JAPAN Contact: www.ia.omron.com Regional Headquarters OMRON EUROPE B.V. (Importer in EU) OMRON ELECTRONICS LLC Wegalaan 67-69, 2132 JD Hoofddorp 2895 Greenspoint Parkway, Suite 200 The Netherlands Hoffman Estates, IL 60169 U.S.A. Tel: (31)2356-81-300/Fax: (31)2356-81-388 Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 ©...

STI Omron F3SG-RA Series User Manual

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STI Omron F3SG-RA Series

Summary of Contents for STI Omron F3SG-RA Series

This manual is also suitable for:
