ASSEMBLY INSTRUCTIONS
Quadro A Leg
Counter Table
STEP 08
Place desktop ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (J) sockets attached top to frame.
Need help!
Call us on
1300 527 665
J
TABLE TOP
BOTTOM VIEW
nut insert
www.jasonl.com.au
nut insert
6 of 7
