ASSEMBLY INSTRUCTIONS
Quadro A Leg
Counter Table
STEP 01
F
Using Allen Key provided, attach 2 plastic brackets per
leg (D) (as per picture above) using M6x20MM (I)
Socket head screw. Screw the feets (F) to the bottom
of each leg (B)
Need help!
Call us on
STEP 02
I
B
Using Allen Key provided, attach M8x20MM
Socket head (H)- screw socket half way into
leg for both legs (B)
1300 527 665
STEP 03
TOP VIEW
H
Use fixed beam (C) and secure beam
using screws provided to suit desk
www.jasonl.com.au
