Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 62841-1; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
• using the tool for different applications, or with
different or poorly maintained accessories,
may significantly increase the exposure level.
• the times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2.
1. On/off switch
2. Rear Handle
3. Battery
4. Battery Indicator
5. Front Handle
6. Safety Switch
7. Hand guard
8. Cutting blade
9. Blade guide
10. Battery release buttons
11. Charger LED indicator
12. USB charger cable
13. Blade sleeve
3. ASSEMBLY
Before any work on the power tool,
remove the battery.
The battery must be charged before first
use.
Inserting the battery into the machine
Fig. B
Ensure that the exterior of the battery is clean and
dry before connecting to the charger or machine.
• Insert the battery into the base of the machine.
8
• Push the battery further forward until it clicks
into place.
Removing the battery from the machine
Fig. B
• Push the battery release buttons (11) and pull
the battery (3) out of the machine.
Charging the battery (with the charger)
Fig. C
• Plug the USB-C connector of the charger
cable (12) into the battery (3).
• Plug the other USB-C connector of the
charger cable into an USB power adapter (not
included).
• Alternatively, for example a powerbank or
laptop can be used as a power source.
• The charger indication light (11) will lighten up
and show the charging status.
LED indicator (11)
Fig. C
The battery has 1 LED indicator which indicates
the status of the charging process:
LED
Red
Green Battery charging finished, battery fully charged
After the battery is fully charged remove the
charger plug from the outlet and unplug the
charging cable from the battery.
When the machine is not being used
over a longer period of time it is best to
store the battery in charged condition.
Before using, always visually inspect to
see that the blades, blade bolts and cutter
assembly are not worn or damaged.
Warning! You may not use the grass
trimmer without the protection guard.

4. OPERATION

Before using, always visually inspect to
see that the blades, blade bolts and cutter
assembly are not worn or damaged.
Charger status
Battery charging in progress
