Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping your
hands warm, and organizing your work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-5.
1. Hedge trimmer head
2. Head adjustment button
3. Head locking ring
4. Hedge trimmer blade
5. Handle locking lever
6. Power switch
7. Telescopic handle
8. Power connector
9. Shoulder strap
10. Carabiner
11. Protection sleeve
12. Battery
13. Battery charger
14. Battery release button
15. Battery LED indicators button
16. Battery LED indicators
17. Charger LED indicators
3. ASSEMBLY
Before any work on the power tool,
remove the battery.
The battery must be charged before first
use.
Tool assembly (Fig. C, D)
• Attach the shoulder strap (9) to the loop on the
handle (7) using the carabiner (10).
• Release the head locking ring (3) by rotating it
anti-clockwise. Do not completely remove the
ring from the head.
• Fit the hedge trimmer head (1) to the
telescopic handle (7) by inserting the power
connector (8) into the head.
• If the connector (8) is not inserted properly,
there might be no electrical connection and the
tool will not work. Make sure that the power
connector is fully inserted into the hedge
trimmer head. The screw (18) on the handle
should be covered by the trimmer head (1) and
locking ring (3).
• Secure the hedge trimmer head (1) by rotating
the locking ring (3) clockwise
Never fasten the belt diagonally across the
shoulder and chest, but place it on one of
the shoulders. This way you can quickly
remove the tool from your body in case of
danger.
Adjusting the telescopic height (Fig. E-1, E-2)
• Unlock the lever (5) to release the telescopic
handle (7).
• Extend or retract the telescopic handle (7) to
the desired length.
• Secure the telescopic handle by locking the
lever (5).
Adjusting the pivoting hedge trimmer head
(Fig. F-1, F-2)
• Press both the button (2) on the side of the
hedge trimmer head (1).
• Adjust the head to the desired position.
• Release the button (2) and make sure the head
is locked in place.
Inserting the battery into the machine (Fig. A,
D)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (2) into the base of the
machine as shown in Fig. D.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig.
A, D)
1. Push the battery unlock button (3)
2. Pull the battery out of the machine like shown
in Fig. D.

4. OPERATION

Before using, always visually inspect to
see that the blades, blade bolts and
cutter assembly are not worn or
damaged.
11
