GENUINE
USER'S INSTRUCTIONS
Vehicle MAZDA CX-9, MAZDA6
Thank you for purchasing a genuine Mazda accessory.
Before use, be sure to thoroughly read these instructions.
Please read the contents of this booklet in order to properly use the cable. Your safety
depends on it.
After using this instruction manual, store it in a place where it can be easily located.
<Safe and correct use of the product>
Various warnings and cautions are displayed in this manual to assist you in the safe and
correct use of the product and as precautions against you or others being injured, or the
product being damaged.
Depending on the degree of possible injury or damage that may be incurred, precautionary
items have been divided into 'Warnings' and 'Cautions' and illustrated with symbols to
depict the nature of the precautionary content.
WARNING
CAUTION
ABOUT SYMBOLS
This symbol indicates prohibited actions or behavior. The prohibitive
action or behavior is depicted as shown below.
Disassembly prohibited
This symbol directs the user to take precaution when performing a
particular task.
* iPod is a trademark of Apple Inc., registered in the United States and other countries.
CAUTION
x Connect only the iPod to this cable. Even if other devices (such as USB
portable audio players, USB memory) are connected, the audio will not
operate.
iPod CABLE
Parts number
GEA1 79 970
A WARNING indicates a situation in which serious injury
or death could result if the warning is ignored.
A CAUTION indicates a situation in which bodily injury or
damage to objects, or both, could result if the caution is
ignored.
1
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Mazda GEA1 79 970
Summary of Contents for Mazda GEA1 79 970
- Page 1 Vehicle MAZDA CX-9, MAZDA6 Parts number GEA1 79 970 Thank you for purchasing a genuine Mazda accessory. Before use, be sure to thoroughly read these instructions. Please read the contents of this booklet in order to properly use the cable. Your safety depends on it.
-
Page 2: Safety Precautions
Safety Precautions (1) WARNING For more complex operation which requires viewing the screen, do not operate the system while driving the vehicle (moving vehicle). Otherwise it could result in an accident due to a lapse in attention for what is ahead of the vehicle. Always park the vehicle in a safe location to operate the system. - Page 3 Safety Precautions (2) CAUTION Adjust the audio volume while driving the vehicle to a level that allows you to hear sounds outside the vehicle. If exterior sounds cannot be heard while driving the vehicle, it could result in an accident. The cable is for in-car use only and is not to be used outside of the vehicle.
-
Page 4: Table Of Contents
CONTENTS Before Use························································································· 5 iPod and Display Audio functions ······················································ 7 Connecting/Disconnecting································································· 8 Troubleshooting (1)············································································ 9 Troubleshooting (2)··········································································· 10 iPod Operation Image······································································· 11 iPod Playback (1)·············································································· 12 iPod Playback (2)·············································································· 13 Screen Display ················································································· 14 MUSIC MENU Switching ·································································· 15 Shuffle Playback (SHUFFLE PLAY) ·················································... -
Page 5: Before Use
The cable is provided for connection of an iPod (with a Dock connector) to a genuine display audio. The iPod can be operated from a genuine Mazda audio system. iPod models (software) which can be connected and used with the audio system are as... - Page 6 CAUTIONS when connecting the iPod When not in use, disconnect the iPod. The iPod has not been designed to withstand extreme temperature changes inside the vehicle and if left in the vehicle it could result in damage or battery depletion due to extreme high temperature or humidity. The iPod is not warranted against any possible loss of iPod data while connecting it to the audio system.
-
Page 7: Ipod And Display Audio Functions
Playlists Artists Albums Songs Music menu switching Podcast Genres Composers Audio book Songs Repeat Songs Shuffle Albums Song (track) name Title display Artist name Album name Track number Play time *1 Can only be done while music menu is “Playlists” *2 Can only be done while music menu is “Artists”... -
Page 8: Connecting/Disconnecting
iPod Connecting/Disconnecting <iPod CONNECTION> Connect iPod to the USB connector located inside the glove comportment. CAUTION When connecting the connector, be careful about the connector direction. When connecting the iPod, disconnect the earphones. Turn the audio power off before connecting or disconnecting the iPod. Depending on the audio, there may be noise produced when the iPod is connected. -
Page 9: Troubleshooting (1)
TROUBLESHOOTING (1) Symptom Cause Solution The iPod version Use the correct iPod version (for the number is different applicable version, refer to page 5.) Detection requires Check again to make sure that the The iPod is time. connector is firmly connected not detected There is some Reset the iPod unit. -
Page 10: Troubleshooting (2)
TROUBLESHOOTING (2) Symptom Cause Solution It does not appear as though the music menu has switched even though the Disconnect the iPod from the audio operation has been system and verify the song editing/recording status in the iPod. completed according to the editing/recording Cannot switch status of the songs in... -
Page 11: Ipod Operation Image
iPod Operation Image (iPod screen image) Music (iPod screen image) Playlists (iPod screen image) Playlists > Favorite Artists > Favorite > Albums > Heeling > Track 01 Songs > Jazz Best > Track 02 Genres > J-POP > Track 03 Composers >... -
Page 12: Ipod Playback (1)
iPod Playback (1) Notes x After connecting the iPod to the audio system, perform all operations from the audio unit. Control is not possible from the iPod. x The button operations indicated in the instructions are all audio unit buttons. 1. -
Page 13: Ipod Playback (2)
iPod Playback (2) When connecting iPod to the audio system, playback begins when playback occurs from the iPod itself. If the audio source is changed while the iPod is being played (CD, AM/FM etc.), or the power to the audio unit or the ACC is turned off, the song that was originally being played is temporarily stopped. -
Page 14: Screen Display
Screen Display (Except U.S./E.U.) (U.S./E.U) (U.S./E.U) (Except U.S./E.U.) (U.S./E.U) (Except U.S./E.U.) (U.S./E.U) (Except U.S./E.U.) (U.S./E.U) (Except U.S./E.U.) iPod mode display Track index/number of tracks in the currently selected folder Playback time P-time Name of album currently being played Name of song currently being played Artist name of the song currently being played Menu button Repeat button... -
Page 15: Music Menu Switching
MUSIC MENU Switching 1. Select the Menu button on the iPod playback display. Menu button 2. Select the music menu. x The screen returns to the playback display by pressing the Now Playing button. 3. Select a desired list from the list menu. -
Page 16: Shuffle Playback (Shuffle Play)
Shuffle Playback (SHUFFLE PLAY) 1. A list of songs can be played in shuffled order. 2. The mode changes as follows each time the Shuffle button is pressed. Normal playback Shuffle Albums Shuffle Songs <Shuffle Albums> If the Shuffle button is pressed during normal playback, the Shuffle Albums button is displayed on the screen, then all albums on a list are shuffled and played. -
Page 17: Repeating Playback (Repeat Play)
Repeating Playback (REPEAT PLAY) 1. This function allows you to play a desired song repeatedly. 2. If the Repeat button is pressed, the Repeat Track is displayed on the screen and repeats playback of the song currently being played. Note Repeat playback cannot be canceled by pressing the SHUFFLE button or SEEK/TRACK button (on the side of the screen). -
Page 18: Song (Track) Selection
Song (Track) Selection 1. Select a track by pressing the SEEK/TRACK button, or SEEK/TRACK button turning the TUNE/FILE knob. (Except U.S./E.U.) x If you want to listen to the next track, press the SEEK/TRACK button or turn to the right the TUNE/FILE knob. -
Page 19: Song (Track) Fast Forward And Back
Song (Track) Fast Forward and Back x To fast forward during playback, SEEK/TRACK button press and hold the SEEK/TRACK (Except U.S./E.U.) button. x To fast track backwards during playback, press and hold the SEEK/TRACK button. Release the button to end the function. SEEK/TRACK button (U.S./E.U)
