- Page 1 © 2024 Order #XXXXX VK-2310 Sunrise - 10’ x 20’ Display 10’ 20’ Plan View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
-
Page 2: Plan View
© 2024 Order #XXXXX Plan View = 1 sq foot... -
Page 3: General Setup Instructions
© 2024 Order #XXXXX General Information General Setup Instructions WARNING - Read entire setup instruction manual prior to unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly. - Page 4 © 2024 Order #XXXXX Tool-less Frame Assembly Slide connector across seam of extrusions. Disassembly Tighten all knobs. Straight Connection 1) Loosen all knobs. When assembling frame, first attach all straight Straight Connector 2) Slide connectors off of one extrusion. connectors, then attach corner connectors.
- Page 5 © 2024 Order #XXXXX SEG Installation The Perfect Fit SEG Graphic Installation in 3 Steps STEP 1: Attach Corners STEP 2: Attach Middle STEP 3: Attach Sides Always insert graphic into each alternate corner, then into the sides of the frame. Otherwise the graphic will not fit into the frame correctly.
- Page 6 © 2024 Order #XXXXX Case Packing Top View of Each Level Lights Base Plate Graphics Wings Base Plate Setup Hardware Level 1 Level 2 Level 3 Level 4 (Bottom level) Case 1 of 2...
- Page 7 © 2024 Order #XXXXX Case Packing Top View of Each Level Lights Base Plate Graphics Base Plate Setup Hardware Level 1 Level 2 Level 3 (Bottom level) Case 2 of 2...
-
Page 8: Front View
© 2024 Order #XXXXX Backwall Assembly Item Qty. Description Steps: 45”h TSP46 Vertical Extrusion Refer to the Tool-less Frame Assembly general information page. 45”h TSP46 Vertical Extrusion 45”h TSP46 Vertical Extrusion 1) Assemble extrusions [1-2], [3-4], [5-6], [7-8] & [1-2], [3-4], [5-6], [7-8] together 45”h TSP46 Vertical Extrusion using straight connectors. - Page 9 © 2024 Order #XXXXX Backwall Attachments Steps: 1) Connect Wings to A10 clamps on vertical extrusions. A10 Clamp Attachment detail. 2) Attach light to top of frame. See Light Attachment detail. Light Attachment Attach clamp of stem light to top of Light horizontal extrusion where desired.
