TRASSIR TR-D2222WDZIR4v2 (C) User Manual

Specification
Model TR-D2222WDZIR4v2 (C)
Image sensor 1/2.8" CMOS STARVIS 2МP
Max resolution 2MP(1920x1080)
Main stream 50Hz: 2MP/960p/720p@25fps
60Hz: 2MP/960p/720p@30fps
Substream
50Hz: 720p/4CIF/VGA@25fps
60Hz: 720p/4CIF/VGA@30fps
Third stream 50Hz: 4CIF/VGA/HVGA@25fps
60Hz: 4CIF/VGA/HVGA@30fps
Electronic shutter speed 1/2 ~ 1/1 000 s
Day/Night mode Mechanical ICR
Sensitivity 0.003Lux(F1.6)
IR range up to 40m
Lens (mm) 2.8 - 8 (motorzoom)
Field of view (horiz./vert.) 99˚ - 47˚ / 53˚ - 27˚
Axes setting Pan: 0˚-360˚
Tilt: 0˚-105˚
Rotation: 0˚-360˚
WDR
Real WDR (120dB)
Digital noise reduction
Video compression Н.265+ / Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 128GB
Audio Built-in microphone
1 in / 1 out
Alarm In/Out
Corridor mode
IVS
General
Power supply
PoE Class
Power consumption
Case material
Dimensions (mm)
Weight Net/Gross (g)
Protection
Power surge suppressor
Working temperature
3D DNR
Technical support
www: helpdesk.trassir.com
1 / 1
mail: helpdesk@trassir.com
Yes
Yes
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D2222WDZIR4v2 (C)
Outdoor IR Mini Bullet Network Camera
PoE (802.3af) / 12V DC
0
DC: 5.2W
PoE: 6.3W
Metal
184.67x66.50x63.05
460 / 565
IP67
TVS 4000V
-40°C ... +60°C
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
