1
Introduction
The compact Summit T28 Protocol Analyzer features a small form factor supporting PCI Express data transmission rates
up to 5.0 GT/s and data link widths up to x8 with 4GB (2GB per direction) trace buffer in a single unit. The Summit T28
protocol analyzer can support multiple PCIe storage protocols such as SATA Express, NVM Express and SCSI Express.
Use this document for quick installation and setup. If you experience problems or need more information, see the
PCIe Gen3 Summit T3/T2 Protocol Analyzer User Manual at the Teledyne LeCroy web site
https://teledynelecroy.com/sw/pciexpress
2
Components
The analyzer package includes the following components:
•
Summit T28 analyzer system
•
DC Power Adapter (12V @ 5A) and AC power cable
Inspect the received shipping container for any damage. Unpack the container and account for each of the system
components listed on the accompanying packing list. Visually inspect each component for absence of damage.
In the event of damage, notify the shipper and Teledyne LeCroy. Retain all shipping materials for shipper's inspection.
Please see the PCIe Gen3 Summit T3/T2 Protocol Analyzer User Manual on the Teledyne LeCroy website for component
specifications and further details.
Summit T28 PCIe Protocol Analyzer
https://teledynelecroy.com/sw/pciexpress
Summit T28
PCI Express Protocol Analyzer
Quick Start Guide
•
USB cable
•
Quick Start Guide (this document)
Advertisement
Table of Contents
Related Manuals for Teledyne Lecroy Summit T28
Summary of Contents for Teledyne Lecroy Summit T28
- Page 1 The compact Summit T28 Protocol Analyzer features a small form factor supporting PCI Express data transmission rates up to 5.0 GT/s and data link widths up to x8 with 4GB (2GB per direction) trace buffer in a single unit. The Summit T28 protocol analyzer can support multiple PCIe storage protocols such as SATA Express, NVM Express and SCSI Express.
-
Page 2: Front Panel Description
Blue - Unit ready/connected. [4] DC IN: 12 V, 5 A [3] Trigger LED: Lights when Summit T28 triggers on an [5] Power Switch (black): 1 = On and 0 = Off. event. [4] Upstream [7:0] connector: Connection to the probe for the capture of upstream direction of the link. - Page 3 Interposers and Probes The Summit T28 supports a full range of Teledyne LeCroy PCIe Interposers and Probes. Gen2 Active Slot Interposer: The Gen2 Active Slot Gen2 MidBus Probe: The Gen2 MidBus Probe is Interposer is designed for use with the Summit T28...
- Page 4 Connecting Interposers to the Summit T28 Analyzer Summit T28 PCIe Protocol Analyzer 12V DC from adapter Link Activity supplied LEDs Clock inputs configuration switches Active Gen2 x8 Interposer PE111UIA-X USB for factory iPass Y-Cable configuration only PE010UCA-X Note: Lesser widths and passive Gen2...
- Page 5 Summit T28 Analyzer iPass Y-Cable PE010UCA-X iPass Y-Cable PE010UCA-X Summit T28 Analyzer Summit T28 Analyzer iPass Y-Cable PE010UCA-X...
-
Page 6: Installing The Software
• To take full advantage of the rich visualization and analysis of Teledyne LeCroy software it is recommended that the display is set to at least 1050 lines of vertical resolution with at least 24-bit color depth. -
Page 7: Making Your First Recording
2. Insert the PCI Express device into the PCIe connector on top of the interposer. 3. Connect Summit T28 to the interposer with Analyzer Y cables. Connect cable Side A to the Upstream port of the Analyzer, and connect cable Side B to the Downstream port. -
Page 8: Environmental Conditions
Product specifications are subject to change without notice. Teledyne LeCroy and Summit T28 are trademarks of Teledyne Teledyne LeCroy reserves the right to revise the information in this LeCroy. Microsoft and Windows are registered trademarks of document without notice or penalty.
