Teledyne Lecroy USB Mercury T2C Quick Start

Hide thumbs Also See for USB Mercury T2C:

Download this manual

USB Mercury T2C

Quick Start

Introduction

The Teledyne LeCroy USB Mercury T2C™ USB 2.0 Protocol Analyzer is a verification system

for USB development and testing. It supports USB 2.0 and the Power Delivery Protocol that

runs over the Type-C(TM) connector. It is designed to record USB traffic and graphically

present the logical transactions and events. It connects to a laptop or desktop PC via USB

2.0. The Mercury T2C is powered by the USB cable, so no additional power cord is needed.

Please see the Readme file on the installation DVD for the latest information on

PC requirements and supported operating systems.

The system can monitor USB 2.0 traffic (Hi Speed, Full Speed, and Low Speed) using

compliant USB 2.0 cables, as well as Power Delivery 2.0 traffic over the USB Type-C to

Type-C cables. It will work with all existing USB 2.0 devices and hosts (using the supplied

Adapters), as well as new ones incorporating the Type-C connectors.

The total length of the cables between the Host under test and the Device under test should

be kept to < 4 feet.

Components

The Teledyne LeCroy Mercury T2C Analyzer package includes the following items:

• One Teledyne LeCroy USB Mercury T2C Analyzer

• Five USB cables (A to C, C to C, C to B, C to uB, C to A Receptacle)

• Installation DVD-ROM, including documentation

• Quick Start Guide

Please see the USB Protocol Suite User Manual on the installation DVD for

component specifications.
