MINIECLFRFC
FRESNEL PROIECTOR
USER MANUAL
MANUALE UTENTE
EN - IT

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINIECLFRFC and is the answer not in the manual?

Questions and answers

Summary of Contents for ProLights MINIECLFRFC

  • Page 1 MINIECLFRFC FRESNEL PROIECTOR USER MANUAL MANUALE UTENTE EN - IT...
  • Page 2 All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be reproduced in any form or by any means for any commercial use. In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
  • Page 3: Table Of Contents

    4. 1 Maintenance and cleaning the unit 4. 1 Maintenance and cleaning the unit 4. 2 Fuse replacement 4. 2 Fuse replacement 4. 3 Trouble shooting 4. 3 Trouble shooting • MINIECLFRFC Packing content • Barn doors • Gel frame • User manual...
  • Page 4: General Instructions

    MINIECLFRFC WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instruction • The products referred to in this manual conform to the European Community Directives and are there- fore marked with .
  • Page 5: Technical Drawing

    MINIECLFRFC - 1 - TECHNICAL DRAWING Fig.1 - Technical drawing...
  • Page 6: Operating Elements And Connections

    MINIECLFRFC 1.1 OPERATING ELEMENTS AND CONNECTIONS Fig.2 1. AIR OPENING 2. LOCKING KNOB for mounting bracket 3. MOUNTING BRACKET 4. BARN DOOR HOLDER for insertion and lock- ing barn door 5. Rotary knob for manual focus 6. CONTROL PANEL with display, 4 button and...
  • Page 7: Installation

    20 cm. The adjust the projector and use the knobs. NOTE - To install the MINIECLFRFC projector, insert the clamp or a suitable clamp to fix it to a suspended system.
  • Page 8: Functions And Settings

    - 3 - FUNCTIONS AND SETTINGS 3.1 OPERATION To turn on the MINIECLFRFC connect the supplied main cable to a socket (100-240 VAC-50/60 Hz). Then the unit is ready for operation. To switch off, disconnect the mains plug from the socket. For a more convenient operation it is recom- mended to connect the unit to a socket which can be switched on and off via a light switch.
  • Page 9: Menu Structure

    MINIECLFRFC 3.3 MENU STRUCTURE MENU DMX Address Value (001-512) ð CONNECT ð DMX Mode Theater Amber Shift on Default: 2800K ð ð Color Temperature (2800 ~ 8000K) Hue -025 ~ 025 Manual Color Red 000 ~ 255, Green 000 ~ 255...
  • Page 10 MINIECLFRFC ð Fixture Hours ð 0-9999 INFORMATION Version V1.0 Temperature **°C 15D00224**** ð Master/Slave ð Master Default: Slave STAND ALONE Slave Effects ð Effect 1 ð 1 ~ 100 Default: Effect 2 Effect1,Speed=100 Effect 3 Effect 4 Effect 5 Static ð...
  • Page 11: Dmx Mode

    • Press the MENU button to go back or to meet the waiting time to exit the setup menu. To able to operate the MINIECLFRFC with a light controller, adjust the DMX start address for the first a DMX channel. If e. g. address 33 on the controller is provided for controlling the function of the first DMX chan- nel, adjust the start address 33 on the MINIECLFRFC.
  • Page 12: Dmx Configuration

    MINIECLFRFC 3.5 DMX CONFIGURATION MINIECLFRFC is equipped with different DMX configuration. • Press the button MENU so many times until shows DMX Mode, and press the button ENTER to confirm. • Select the desired DMX mode and configuration (Theater: 1CH - 2CH - 3CH - 4CH 1 - 5CH - 9CH1 - 14CH - 17CH; Tour: 4CH 2 - 6CH - 7CH - 9CH 2 - 12CH) through the buttons UP/DOWN.
  • Page 13: Fixture Information

    MINIECLFRFC 3.8 FIXTURE INFORMATION To view all the information on the device, proceed as follows: • Press the ENTER button to access the main menu. • Press the UP/DOWN button to scroll the menu, select Information, then press the ENTER button to enter the next menu.
  • Page 14: Manual Mode

    MINIECLFRFC 3.12 MANUAL MODE This mode allows to combine the colors (Red, Green,Blue and Lime). • Press the MENU button so many times until the display shows Stand Alone, then press the ENTER button. • Using UP/DOWN buttons Select Static, then press ENTER.
  • Page 15: Connection Of The Dmx Line

    MINIECLFRFC 3.13 CONNECTION OF THE DMX LINE DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped- ance and low capacity. The following diagram shows the connection mode: DMX - INPUT DMX - OUTPUT XLR plug XLR socket...
  • Page 16: Channels Dmx

    MINIECLFRFC 3.15 CHANNELS DMX 1 CHANNEL THEATER THEATER 4 CHANNELS 1 MODE MODE FUNCTION FUNCTION Value Value 4 Ch1 1 Ch DIMMER DIMMER 0~100% 000 - 255 0~100% 000 - 255 2800 K - 3200 K 000 - 051 3200 K - 4200 K...
  • Page 17 MINIECLFRFC 1 THEATER THEATER CHANNELS CHANNELS MODE MODE FUNCTION FUNCTION Value Value 9 Ch 1 14 Ch DIMMER DIMMER 0~100% 000 - 255 0~100% 000 - 255 DIMMER FINE 0~100% 000 - 255 0~100% 000 - 255 GREEN 0~100% 000 - 255...
  • Page 18: Channels Tour

    MINIECLFRFC THEATER 4 CHANNELS 2 TOUR CHANNELS MODE MODE FUNCTION FUNCTION Value Value 4 Ch 2 17 Ch DIMMER 0~100% 000 - 255 0~100% 000 - 255 GREEN DIMMER FINE 0~100% 000 - 255 0~100% 000 - 255 BLUE STROBE...
  • Page 19 MINIECLFRFC 7 CHANNELS TOUR CHANNELS TOUR MODE MODE FUNCTION FUNCTION Value 7 Ch Value 12 Ch DIMMER DIMMER 0~100% 000 - 255 0~100% 000 - 255 DIMMER FINE 0~100% 000 - 255 0~100% 000 - 255 GREEN 0~100% 000 - 255...
  • Page 20: Maintenance

    MINIECLFRFC - 4 - MAINTENANCE 4.1 MAINTENANCE AND CLEANING THE UNIT • Make sure the area below the installation place is free from unwanted persons during setup. • Switch off the unit, unplug the main cable and wait until the unit has cooled down.
  • Page 21: Troubleshooting

    MINIECLFRFC 4.3 TROUBLESHOOTING Problems Possible causes Checks and remedies No mains supply Check the power supply voltage • • Dimmer fader set to 0 Increase the value of the dimmer channels Fixture does not light up • • Faulty LED Replace the LED board •...
  • Page 22 Music & Lights S.r.l. si riserva ogni diritto di elaborazione in qualsiasi forma delle presenti istruzioni per l’uso. La riproduzione - anche parziale - per propri scopi commerciali è vietata. Al fine di migliorare la qualità dei prodotti, la Music&Lights S.r.l. si riserva la facoltà di modificare, in qualunque momento e senza preavviso, le specifiche menzionate nel presente manuale di istruzioni.
  • Page 23 4. 1 Manutenzione e pulizia del sistema ottico 4. 1 Manutenzione e pulizia del sistema ottico 4. 2 Sostituzione fusibile 4. 2 Sostituzione fusibile 4. 3 Risoluzione dei problemi 4. 3 Risoluzione dei problemi • MINIECLFRFC Contenuto dell'imballo: • Barn doors • Gel frame • Manuale utente...
  • Page 24: Minieclfrfc

    MINIECLFRFC ATTENZIONE! Prima di effettuare qualsiasi operazione con l’unità, leggere con attenzione questo manuale e conservarlo accuratamente per riferimenti futuri. Contiene informazioni importanti riguardo l’installazione, l’uso e la manutenzione dell’unità. SICUREZZA Avvertenze generali • I prodotti a cui questo manuale si riferisce sono conformi alle Direttive della Comunità Europea e per- tanto recano la sigla .
  • Page 25 MINIECLFRFC - 1 - DISEGNO TECNICO Fig.1 - Disegno tecnico...
  • Page 26: Elementi Di Comando E Di Collegamento

    MINIECLFRFC 1.1 ELEMENTI DI COMANDO E COLLEGAMENTI Fig.2 1. PRESA DI VENTILAZIONE apertura per uscita flusso d'aria da non ostruire. 2. MANIGLIE 3. STAFFA DI MONTAGGIO 4. SUPPORTO PER ALETTE per l’inserimento e bloc- caggio delle stesse 5. Manopola per la messa a fuoco 6.
  • Page 27: Installazione

    20 cm. Quindi orientare il proiettore. NOTA - Per l’installazione del proiettore MINIECLFRFC inserire il gancio o un morsetto idoneo per fissarlo ad un sistema sospeso.
  • Page 28: Funzioni E Impostazioni

    - 3 - FUNZIONI E IMPOSTAZIONI 3.1 FUNZIONAMENTO Per accendere il MINIECLFRFC, inserire la spina del cavo di alimentazione in una presa di rete (100-240V~/50- 60Hz). Dopo l’utilizzo spegnere il dispositivo, staccare la spina dalla presa di rete. Per maggiore comodità è con- sigliabile collegare l’unità...
  • Page 29: Struttura Menù

    MINIECLFRFC 3.3 STRUTTURA MENU MENU DMX Address Value (001-512) ð CONNECT ð DMX Mode Theater Amber Shift on Default: 2800K ð ð Color Temperature (2800 ~ 8000K) Hue -025 ~ 025 Manual Color Red 000 ~ 255, Green 000 ~ 255...
  • Page 30 MINIECLFRFC ð Fixture Hours ð 0-9999 INFORMATION Version V1.0 Temperature **°C 15D00224**** ð Master/Slave ð Master Default: Slave STAND ALONE Slave Effects ð Effect 1 ð 1 ~ 100 Default: Effect 2 Effect1,Speed=100 Effect 3 Effect 4 Effect 5 Static ð...
  • Page 31: Modalità Dmx

    DMX per il primo canale DMX. Se, per esempio, sull’unità di comando è previsto l’indirizzo 33 per coman- dare la funzione del primo canale DMX, si deve impostare sul MINIECLFRFC l’indirizzo di start 33. Le altre funzioni del pannello saranno assegnate automaticamente agli indirizzi successivi. Segue un esempio con...
  • Page 32: Configurazione Canali

    MINIECLFRFC 3.5 CONFIGURAZIONE CANALI DMX L’ MINIECLFRFC dispone di diverse configurazioni dei canali DMX a cui si può accedere dal pannello di con- trollo. • Premere il tasto MENU per accedere al menu principale. • Premere il tasto UP/DOWN per scorrere nel menu, selezionare Connect, quindi premere il tasto ENTER per accedere al menu successivo.
  • Page 33: Informazioni Sul Dispositivo

    • Premere il tasto MENU più volte per uscire dal menu e per salvare le modifiche apportate. 3.10 MODALITA’ EFFECTS MINIECLFRFC dispone di programmi automatici incorporati. Per accedervi, fare riferimento alle seguenti istruzioni: • Premere il tasto MENU per accedere al menu principale.
  • Page 34: Modalità Manual

    MINIECLFRFC • Muoversi con il tasto UP/DOWN, selezionare Static, confermare la scelta con il tasto ENTER. • Attraverso i tasti UP/DOWN selezionare Fixed Color, quindi premere il pulsante ENTER per confermare. • Impostare il colore (R, G, B, L, RG, RB, RL, GB, GL, BL, RGB, RGL, RBL, GBL, RGBL, 2800 K, 3200 K, 4200 K, 5500 K, 6000 K, 8000 K) o il valore (000 ~ 255), tramite i pulsanti UP/DOWN, quindi premere il tasto ENTER button per confermare.
  • Page 35: Collegamenti Della Linea Dmx

    MINIECLFRFC 3.13 COLLEGAMENTI DELLA LINEA DMX La connessione DMX è realizzata con connettori standard XLR. Utilizzare cavi schermati, 2 poli ritorti, con impedenza 120Ω e bassa capacità. Per il collegamento fare riferimento allo schema di connessione riportato di seguito: DMX - INPUT...
  • Page 36: Canali Dmx

    MINIECLFRFC 3.15 CANALI DMX 1 CHANNEL THEATER THEATER 4 CHANNELS 1 MODE MODE FUNCTION FUNCTION Value Value 4 Ch1 1 Ch DIMMER DIMMER 0~100% 000 - 255 0~100% 000 - 255 2800 K - 3200 K 000 - 051 3200 K - 4200 K...
  • Page 37 MINIECLFRFC 1 THEATER THEATER CHANNELS CHANNELS MODE MODE FUNCTION FUNCTION Value Value 9 Ch 1 14 Ch DIMMER DIMMER 0~100% 000 - 255 0~100% 000 - 255 DIMMER FINE 0~100% 000 - 255 0~100% 000 - 255 GREEN 0~100% 000 - 255...
  • Page 38: Channels Tour

    MINIECLFRFC THEATER 4 CHANNELS 2 TOUR CHANNELS MODE MODE FUNCTION FUNCTION Value Value 4 Ch 2 17 Ch DIMMER 0~100% 000 - 255 0~100% 000 - 255 GREEN DIMMER FINE 0~100% 000 - 255 0~100% 000 - 255 BLUE STROBE...
  • Page 39 MINIECLFRFC 7 CHANNELS TOUR CHANNELS TOUR MODE MODE FUNCTION FUNCTION Value 7 Ch Value 12 Ch DIMMER DIMMER 0~100% 000 - 255 0~100% 000 - 255 DIMMER FINE 0~100% 000 - 255 0~100% 000 - 255 GREEN 0~100% 000 - 255...
  • Page 40: Manutenzione

    MINIECLFRFC - 4 - MANUTENZIONE 4.1 MANUTENZIONE E PULIZIA DEL SISTEMA OTTICO • Durante gli interventi, assicurarsi che l’area sotto il luogo di installazione sia libera da personale non qualificato. • Spegnere l’unità, scollegare il cavo di alimentazione ed aspettare finché l’unità non si sia raffreddata.
  • Page 41: Risoluzione Dei Problemi

    MINIECLFRFC 4.3 RISOLUZIONE DEI PROBLEMI Anomalie Possibili cause Controlli e rimedi Mancanza di alimentazione di rete Verificare la presenza della tensione alimentazione • • Dimmer impostato a 0 Incrementare i valori del canale dimmer Il proiettore non illumina • •...
  • Page 44 MUSIC & LIGHTS S.r.l. - Phone +39 0771 72190 - www.musiclights.it...
