DH-L* 1500-3000 kg
INSTALLATION MANUAL
Manufacturer:
DHOLLANDIA N.V.
Zoomstraat 9
9160 LOKEREN (Belgium)
Tel : +32 (0)9 349 06 92
Fax : +32 (0)9 349 09 77
e-mail : info@dhollandia.be
website : www.dhollandia.com
Read the operation manual in its entirety before operating the tail lift
Read this installation manual in its entirety before installing the tail lift
Order ref : xxx Doc: FIT_EUR installation manual LM.30_EUR EN_2020
Rev: 2 Date: FEB 17 2025
