DH-L* 3300-6600 lbs
INSTALLATION MANUAL
Manufacturer:
DHOLLANDIA US, L.L.C.
E-mail : us.info@dhollandia.com
270 Southridge Parkway
Bessemer City North Carolina, 28016
website : www.dhollandia.com
Read the manual in its entirety before operating the liftgate
Keep this manual in the vehicle cab, as reference for the driver and liftgate operator
Order ref : xxx Doc: FIT_US installation manual LM_US EN_2020 Rev: 2 Date: OCTOBER 21, 2021
