edition
DH-RM.25
INSTALLATION MANUAL
1500-2000-2500kg
** Pictured: RM.25 tail lift
Manufacturer:
DHOLLANDIA N.V.
Zoomstraat 9
9160 LOKEREN (Belgium)
Tel : +32 (0)9 349 06 92
Fax : +32 (0)9 349 09 77
e-mail : info@dhollandia.be
website : www.dhollandia.com
Read the manual in its entirety before operating the tail lift
Keep this manual in the vehicle cab, as reference for the driver and tail lift operator
Doc: FIT_RM.25_CE_EN_2020_rev0
Rev: 0 Date: JANUARY 1, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH-RM.25 and is the answer not in the manual?

Questions and answers

Related Manuals for Dhollandia DH-RM.25

Summary of Contents for Dhollandia DH-RM.25

  • Page 1 9160 LOKEREN (Belgium) Tel : +32 (0)9 349 06 92 Fax : +32 (0)9 349 09 77 e-mail : info@dhollandia.be website : www.dhollandia.com Read the manual in its entirety before operating the tail lift Keep this manual in the vehicle cab, as reference for the driver and tail lift operator Doc: FIT_RM.25_CE_EN_2020_rev0...

  • Page 2: Table Of Contents

    CONTACT INFORMATION ................................4 SAFETY PRECAUTIONS FOR OPERATION ..........................5 SAFETY PRECAUTIONS FOR INSTALLATION ........................... 5 TAIL LIFT TERMINOLOGY ................................8 DH-RM.25 Tail lift terminology ............................. 8 Installation parameters terminology ............................ 10 Getting started ..................................13 Installation dimensions ................................ 15 FLOOR EXTENSION PLATE AND CHASSIS CUT ........................

  • Page 3: Understanding Safety And Warning Signs

    Many safety signs and symbols used in this manual are based on international standards, others refer to specific situations or actions.  Consult Appendix 1 for an overview of signs and symbols used in DHOLLANDIA manuals, and their meaning. Make sure you understand these signs and symbols prior to starting the installation. Examples of standard ANSI...

  • Page 4: Introduction And Disclaimers

    Prior to operating the tail lift, make sure you understand the safety and warning signs used, and read them in conjunction with the instructions in this manual.  If in doubt, DO NOT operate the tail lift. Contact your national DHOLLANDIA distributor. See page 4 for contact info. 2 INTRODUCTION AND DISCLAIMERS ...

  • Page 5: Contact Information

    Contact your national DHOLLANDIA distributor if you have any questions regarding the installation, operation, repair and maintenance of DHOLLANDIA tail lifts, to obtain replacement copies of manuals or decals, or to learn about available equipment options for DHOLLANDIA tail lifts.

  • Page 6: Safety Precautions For Operation

    These instructions are supplied as a separate manual with your tail lift.  You can also contact the national DHOLLANDIA distributor for the latest edition of this manual. See page 4 for contact info. Or download the latest edition from the website: www.dhollandia.com →...
  • Page 7 DHOLLANDIA tail lift.  In case of doubt, ALWAYS contact the national DHOLLANDIA distributor for further advice, prior to continuing.  ALWAYS wear appropriate Personal Protective Equipment. This includes but may not be limited to: ANSI rated glasses with side guards, or a wrap-around face shield;...
  • Page 8 Except for the support channels and bracing of the side steps, which are usually welded to the cross members of the auxiliary chassis, DHOLLANDIA tail lifts are designed as a bolt-on system, and don’t require any welding. See Appendix 2 for prescribed torque values.

  • Page 9: Tail Lift Terminology

    6 TAIL LIFT TERMINOLOGY DH-RM.25 Tail lift terminology See Figure 6.1 on next page for parts corresponding to numbers in this table Description Platform Assembly: combination of the main and flip sections of the platform. Platform, Main Section: inboard section of the foldable platform. Manufactured from steel or lightweight aluminium, with a permanent non-slip working surface.
  • Page 10 Centre point of maximum load: point up to which the maximum rated capacity of the tail lift is valid. Beyond that point, the maximum safe working load diminishes according to the applicable load charts. Figure 6.1 4, 5, 6 DHOLLANDIA...

  • Page 11: Installation Parameters Terminology

    Required mounting space to end of premounted pump unit [= Lift Overhang to Pump unit] LBUG Vertical clearance of RUPD to ground [= Lift Bumper to Ground] LBUP Horizontal dimension from rear of platform to rear of RUPD [= Lift BUmper to rear of Platform] DHOLLANDIA...
  • Page 12 Figure 6.2 DHOLLANDIA...
  • Page 13 See Figure 6.3 for parts corresponding to numbers in this table: Width of the lift arms [= Lift Arm Centre] Vehicle chassis width [= CHassis Width] Min. body width with pump unit in premounted position [= Body Width Outside] Figure 6.3 DHOLLANDIA...

  • Page 14: Getting Started

    / or body will not adversely affect the structural integrity of the chassis and / or body.  In the event instructions of vehicle manufacturer conflict with the installation instructions issued by DHOLLANDIA (e.g. on fuse ratings, etc.), contact your national DHOLLANDIA distributor for further assistance. ...
  • Page 15 During installation and while testing, verify that the tail lift and its moving parts don’t interfere with, or cause damage to the vehicle systems (e.g. to suspension, braking system, hydraulic and electrical circuits, etc.).  DO NOT release the locking bolts of the auto-tilt brackets on the lift frame before the tail lift installation is fully finished. DHOLLANDIA...

  • Page 16: Installation Dimensions

    The max. floor height VFH MAX. should be measured for an UNLOADED vehicle (= worst case)  The min. floor height VFH MIN. should be measured for a FULLY LOADED vehicle (= worst case) Figure 6.4 Dimensions table CTH MAX VFH MAX 1450 VFH MIN 1194 LARM RANGE DHOLLANDIA...
  • Page 17 If you decide to remove the mounting bar and change the mounting height MFT of the tail lift, ensure to stay within the applicable ranges for the installation parameters VFH, MFT and MTG.  Consult the national DHOLLANDIA distributor for confirmation of max. and min. mounting dimensions and obtain a chassis cut-out drawing for the new mounting height MFT. ...

  • Page 18: Floor Extension Plate And Chassis Cut

    The installation can be a STANDARD MOUNT [see Figure 7.1] whereby the bed extension is added behind the rear sill of the vehicle body. Or it can be a FLUSH MOUNT [Contact DHOLLANDIA for guidance], whereby the bed extension is integrated into the vehicle floor.

  • Page 19: Mounting Of The Extension Plate

    Measure, mark and drill the 13 holes dia. 14.3mm required for mounting the extension, then coat the holes to protect against corrosion.  Position the floor extension up to the rear sill using a fork lift or hoists. Figure 8.1 Dimensions table 1180 DHOLLANDIA...
  • Page 20 1. Mount all bolts and locking nuts and fasten them hand-tight. 2. Ensure the extension plate is level with the vehicle floor [Figure 8.2]; and flush with the top surface of the rear sill. 3. Then tighten the bolts to the required torque. Work from the centre outward. DHOLLANDIA...
  • Page 21 Before welding, note that welding on galvanized parts releases hazardous fumes. Provide adequate ventilation, and wear an appropriate toxic fume rated welding respirator.  It is strongly recommended to first grind off the galvanizing in areas where welding is to be done. DHOLLANDIA...

  • Page 22: Mounting Of The Lift Frame (Premounted Platform)

    Therefore, handle the platform with care. Use lifting aids such as a forklift, gantry crane, hoists and clamps etc… to assist you  through the unfolding movement DHOLLANDIA...
  • Page 23 See also [Figure 10.2] on page 29. Figure 9.2 ❶ ❷ ❸ ❺ ❻ ❹ ❻ ❶ ❼ ❷ ❸ ❹ ❻ ❺ ❻ ❼ Per side ❶ 4x M16x2 (8.8) hand tightened See also 2x M14x1.5 (10.9) hand tightened ❹ DHOLLANDIA...
  • Page 24 Hoist the platform and attached lift frame and place a hydraulic jack under the lift frame. [Figure 9.4] Figure 9.4 DO NOT try to raise and hold the tail lift via the flip-over point. Affix hoists to the platform main section! DHOLLANDIA...
  • Page 25 Ensure that the platform is centred in the centreline of the vehicle, and that it is flush and parallel with the extension plate.  Secure the correct platform position by clamping the platform main section to the 76mm mounting tubes. [Figure 9.5] Figure 9.5 DHOLLANDIA...

  • Page 26: Fixation Of The Bolt-On Mounting Plates

    Ensure the platform and lift frame are positioned in conformance with the mounting instructions and dimensions indicated in the installation drawing and manual, before drilling or welding the mounting plates to the chassis. It is not allowed to reduce the width of the mounting plates without prior written authorization from DHOLLANDIA. 10 FIXATION OF THE BOLT-ON MOUNTING PLATES ...
  • Page 27 Straighten the mounting plates, and make sure they stand perpendicular to the lift frame. Ensure the lift frame is correctly centred under the vehicle chassis and body. [Figure 10.1] The mounting plates MUST be bolted to the lift frame according to the instructions in [Figure 10.2]. Tighten the  bolts and nuts with the prescribed torque. DHOLLANDIA...
  • Page 28 The mounting plates MUST be bolted to the vehicle chassis, the bolts and nuts tightened with the required torque, according to the instructions below and to the right.  Pay special attention to the type, minimum quantity, minimum size and strength, position and prescribed torque. [ Figure 10.3] DHOLLANDIA...
  • Page 29 If not, attach the mounting plates of the tail lift to the long sills on top of the chassis by means of 2 additional bolts M14 per side, or equivalent. [Figure 10.4]. Fasten these bolts with the required torque. DHOLLANDIA...
  • Page 30 During installation, the bolts and nuts should be fastened to the proper torque, shown in these installation instructions.  If you use mounting bolts not supplied by DHOLLANDIA, make sure the total strength is at least equivalent as per this manual. ...

  • Page 31: Installation Of Control Switch

    [see 2 in Figure 10.6].  Further, all points in section 12 above apply to any mounting situation with sleeve holes. 11 INSTALLATION OF CONTROL SWITCH DHOLLANDIA...

  • Page 32: Mounting Of The Control Switch

    Connect the wires of the cable to the connection points in the pump unit, as per wiring diagrams attached.  Coil in the excess cable inside the pump unit. Fix and immobilize it with cable ties to the hydraulic return pipe of the valve block. DHOLLANDIA...
  • Page 33 The main wiring diagrams are included in the pages hereafter, and in the appendix.  The wiring logic for the DH-RM.25 with power down function (ref. OAH025.01) is called DAD4 [Figure 11.4], and uses the following abbreviations: R = starter solenoid for the DC motor...
  • Page 34 Figure 11.4 Figure 11.5 DHOLLANDIA...

  • Page 35: Connection Block Terminology

    S – Control valve (Close/Tilt up) in the power pack O – Electrical self-locking valves (Open/Tilt/Down) on the tilt cylinders I – Control valve (Slide In) in the power pack U – Control valve (Slide In) in the power pack DHOLLANDIA...

  • Page 36: Gravity Down Wiring For The Control Switch

    11.3 GRAVITY DOWN WIRING FOR THE CONTROL SWITCH  The control switch and relay MUST be correctly wired to the connection block for proper operation. [Figure 11.7] Figure 11.7 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...
  • Page 37  For option OAE510.15, see Figure 11.8, below: Figure 11.8 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...

  • Page 38: Power Down Wiring For The Control Switch

    11.4 POWER DOWN WIRING FOR THE CONTROL SWITCH  The control switch and relay MUST be correctly wired to the connection block for proper operation. [Figure 11.9] Figure 11.9 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...
  • Page 39  For option OAE510.15, see Figure 11.10, below: Figure 11.10 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...

  • Page 40: Connection To The Batteries

    12 CONNECTION TO THE BATTERIES  A general schematic of how to correctly connect the batteries to the tail lift is provided in Figure 12.1. Figure 12.1 DHOLLANDIA...
  • Page 41  If not supplied with the tail lift, these can be downloaded from the “DOWNLOAD” section on our website: http://www.dhollandia.com  Please confirm you have reviewed the most up-to-date version of this manual prior to continuing. ...

  • Page 42: Putting The Tail Lift Into Service

    The installer should remain vigilant and stay out of the range of motion of the platform and the moving parts of the tail lift as long as the hydraulic circuits have not been purged. DHOLLANDIA...
  • Page 43 Adjust the length of the platform opener assembly. [Figure 13.4]  It is usually pre-installed at the factory but needs fine-tuning during the installation. If removed, mount it back in its original position to avoid damaging the platform prior to unfolding and folding the platform. DHOLLANDIA...
  • Page 44 [Figure 13.4]  Therefore, it is important that you adjust the platform opener so that the platform stands just inside from vertical position when lowered to the ground, and the operator can unfold the platform sections comfortably. DHOLLANDIA...

  • Page 45: Platform Orientation

    Falling cargo will put the operator and any bystanders at serious risk of bodily injury and death.  Therefore, it is important that the pitch of the flip-over point and complete platform are adjusted correctly conform with instructions in this manual. DHOLLANDIA...
  • Page 46 Figure 14.1 Figure 14.2 DHOLLANDIA...

  • Page 47: Mounting Of The Side Steps & Dock Bumpers

    5. Weld the support channels to the rear sill and underside of the I-beam cross members [Figure 15.3]. Weld to as many I-beam or cross members as possible, to distribute the forces of dock impact as much as possible. DHOLLANDIA...
  • Page 48 3m overhang to the centre of the rear axle [Figure 15.4]. For cases with insufficient ground clearance, side steps with a flexible bottom step are available (option ref. OAM057.LR). Figure 15.3 Weld on inside and outside of channel Per side 2x M16x2 (8.8) 195 Nm DHOLLANDIA...
  • Page 49 Where chassis beams, longs sills, the rear sill and other steel chassis or body components have been cut, grinded, drilled, welded etc…, the installer should apply adequate anti-corrosive coating to protect the vehicle and body against corrosion. Check and make sure you comply with the instructions of the OEM vehicle manufacturer. DHOLLANDIA...

  • Page 50: Mounting Of The Optional Walk-Ramp Kit Oam054

    Fasten all bolts and nuts to the prescribed torque. Pressurize the platform against the stoppers [B] to ensure all bolts are properly secured.  LOWER and LIFT the folded platform at least 3 times. Verify and ensure the platform can unfold and fold freely, without any interference with the walk-ramp assembly; extension plate, or the vehicle chassis. Figure 16.2 DHOLLANDIA...

  • Page 51: Lubrication Instructions

    If so equipped, verify if the platform lock operates smoothly, and lubricate with oil if necessary. NOTICE To maximize the durability and operational reliability of the tail lift, it is important to lubricate the pivot points thoroughly after installation. DHOLLANDIA...
  • Page 52 DHOLLANDIA...

  • Page 53: Commisioning & Quality Control

    During weight test, verify if the hydraulic pump pressure suits the maximum rated lift capacity in this particular mounting situation. Adjust the pressure if too high or too low, seal the pressure relief valve after that using the provided tamper-evident cap. Figure 18.1 Figure 18.2 250mm 400mm 250mm 400mm 400mm 400mm DHOLLANDIA...

  • Page 54: Decals

    2. NEVER remove or paint over any decal. Missing, worn or illegible warning decals MUST be immediately replaced. Get free replacement decals from DHOLLANDIA. Contact your regional DHOLLANDIA distributor. See page 4 for contact info. 3. The operator should comply with all affixed safety and instructions decals. Be aware that the decals merely summarize the main points, and that the operator MUST know, understand, and comply with the full contents of the operation manual.
  • Page 55 ❶ ❷ ❸ ❹ xxxx ❺ ❻ ❼ DHOLLANDIA...
  • Page 56 LIFTGATE DECALS USED AND AFFIXED IN AREAS, OTHER THAN THE REAR OF THE VEHICLE: Cabin switch in driver’s cabin to switch electrical power to liftgate on / off (if so equipped) For circuit breaker in liftgate battery compartment For main fuse in liftgate battery compartment DHOLLANDIA...

  • Page 57: Identification Decals

    19.2 IDENTIFICATION DECALS Every DHOLLANDIA tail lift is identified and labelled with a unique 8-digit serial number (with or without a space between the first and last 4 digits). This number is used for any inquiry on a particular tail lift, or when ordering replacement parts.

  • Page 58: Appendix

    20.1 DECALS WARNING signs MANDATORY ACTION signs Overview and keep visual control over the working Contact your regional DHOLLANDIA distributor. area of the tail lift at all times. General warning sign used to alert the user to Consult the DHOLLANDIA website.
  • Page 59 Switch OFF the electrical power to the tail lift via the main battery disconnect switch and / or cabin switch. This is an operation to be executed manually (as opposed to an electrical function controlled by means of one of the control units). DHOLLANDIA...

  • Page 60: Prescribed Torques Values For Bolts Supplied With Tail Lift

    Type of thread Size Strength class 10.9 Standard M6 x 1 M8 x 1.25 M10 x 1.5 M12 x 1.75 M14 x 2 M16 x 2 Fine M14 x 1.5 M16 x 1.5 M20 x 1.5 M24 x 2 DHOLLANDIA...
  • Page 61 M12 x 1.75 60.5 lbs-ft lbs-ft M14 x 2 lbs-ft 136.5 lbs-ft M16 x 2 lbs-ft lbs-ft Fine M14 x 1.5 lbs-ft lbs-ft M16 x 1.5 lbs-ft lbs-ft M20 x 1.5 lbs-ft lbs-ft M24 x 2 lbs-ft lbs-ft DHOLLANDIA...

  • Page 62: Pdi Checklist 1/2

    The requirement for mechanical or hydraulic stabilizing legs has been checked and been fulfilled (if applicable). The actual fitting dimensions don’t exceed the theoretical maximum fitting dimensions mentioned in the fitting drawings. The lift has been fitted to conform with the fitting instructions of DHOLLANDIA, and the Body Building Guidelines of the OEM vehicle manufacturer.
  • Page 63 ▢ Any other (creaking, grinding or squeaking) noise should be carefully investigated and solved. Dynamic test at 100% of maximum rated lift capacity: ▢ Verify if the lift has sufficient lift capacity. ▢ Verify the general performance & stability. DHOLLANDIA...
  • Page 64 Operating a tail lift that hasn’t successfully passed the PDI can put the operator and third parties at great risk and could result in serious personal injury or death.  It is therefore essential that the PDI check is completed with due diligence, and any shortcomings rectified prior to delivery of the vehicle to the operator. DHOLLANDIA...

  • Page 65: Safe Operator Position On The Platform

     To reduce the risk that the operator crushes their feet between the raising floor and the end of the vehicle floor, DHOLLANDIA recommends that the installer paints a 16x16” (400mmx400mm) safe operator position at a safe distance of min. 10” (250mm) away from the inboard platform edge.

  • Page 66: 2-Button Portable Control

    The handheld control [1] is also equipped with a magnet, so that it will stick to any metal surface.  Mark the safe operator position on the platform and mount a hand grip to the rear frame of the vehicle body in conformance with Appendix 4. DHOLLANDIA...
  • Page 67 Figure 20.4 Figure 20.5 DHOLLANDIA...
  • Page 68  A general wiring schematic for gravity down with the two-button handheld control is shown in Figure 20.6. Figure 20.6 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...
  • Page 69  For option OAE510.15, see Figure 20.7, below: Figure 20.7 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...
  • Page 70  A general wiring schematic for power down with the two-button handheld control is shown in Figure 20.8. Figure 20.8 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...
  • Page 71  For option OAE510.15, see Figure 20.9, below: Figure 20.9 To ground post on pump motor To positive post on motor solenoid DHOLLANDIA...

  • Page 72: Circuit Breaker

    20.6 CIRCUIT BREAKER  A resettable circuit breaker option is also available for the connection to the batteries. [Figure 20.10] Figure 20.10 DHOLLANDIA...

  • Page 73: Cab Cut Off Switch

    Refer to the appropriate connection sequence in Figure 20.11 to properly connect the E0667 illuminated cab switch. Figure 20.11 Figure 20.12  For orders that shipped with option OAE510.15, refer to Figure 20.13 to properly connect the cab switch. Figure 20.13 To liftgate toggle switch To “hot” rail on control block Cabin switch DHOLLANDIA...

  • Page 74: Electric And Hydraulic Information

    The correct diagram applicable for the tail lift supplied can be found on the inside of the control box. If correct diagram is not present inside control box, contact your national DHOLLANDIA distributor for further assistance, or download from the website.

  • Page 75: Dock Lock Compatible Rupd

    It is important to follow these guide-lines with due care. A lot of oils or fluids used in automotive industry, such as transmission fluids and ATF oils, are not suitable for tail lift use. DHOLLANDIA has not tested the potential consequences of oils and fluids with deviating specifications and cannot be held responsible or legally liable for any damage to the tail lift caused by the replenishment with non- compatible oils or fluids;...
  • Page 76 M2902.R / M2902.L [ref. 16-17 in with spring support M2902.R / M2902.L [ref. 16-17 in exploded view], use a soft brackets of the lift frame. exploded view] to join the bumper tubes to rubber hammer to put additional force. the lift frame. DHOLLANDIA...
  • Page 77 M1720.092 [ref. 31 in exploded view] until on the springs VRT104.7 [ref. 8 in at approx.1 .5” of the eye bolts is engaged exploded view]. in the internal thread of the pins. DHOLLANDIA...
  • Page 78 Springs can incorporate a significant amount of energy and can behave unexpectedly if handled in the wrong  way. Incorrect handling, installation, or adjustment can result in serious bodily injury to the operator.  Always install and adjust springs in conformance with instructions. Always wear safety gloves and a face screen when handling springs.  DHOLLANDIA...

  • Page 79: End Note

    20.10 END NOTE  DHOLLANDIA would like to thank you for using our products and leave you with this final notice and warning.  Additional information about this tail lift and many other DHOLLANDIA products is available at the following link: http://www.dhollandia.com...
