Mounting Instructions LANCOM AirLancer ON-QT60 / ON-QT90
Technical data
Frequency range
Antenna characteristics
Radiation patterns
Recommended use
VSWR
Gain
Mechanical Data
Dimensions (mm)
Weight
Operating temperature
Color
Material
Mounting options
Cables & Connectors
Item
Warranty
Item no.
Scope of delivery
LANCOM Systems GmbH
A Rohde & Schwarz Company
Adenauerstr. 20/B2
52146 Wuerselen | Germany
info@lancom.de | lancom-systems.com
ON-QT60
2,400 - 2,500 MHz, 4,900 - 7,125 MHz
Horizontally 2.4 GHz: 60°
Vertically 2.4 GHz: 60°
Horizontally 5 GHz: 60°
Vertically 5 GHz: 60°
Point-to-Multipoint, Sector
2.4 GHz: 7 dBi max.
5 GHz: 7 dBi max.
233.7 x 183.7 x 40 (W x H x D)
900 g (Antenna without mounting kit)
-40° C to 85° C
UV resistant plastic
Wall- and pole mounting, alignable
4x 100 cm ULA100 cable with N-Plug connector
2 years for AirLancer and accessories
61263
Antenna, mounting kit for wall and pole mounting
LANCOM, LANCOM Systems, LCOS, LANcommunity and Hyper
Integration are registered trademarks. All other names or
descriptions used may be trademarks or registered trademarks of
their owners. This document contains statements relating to future
products and their attributes. LANCOM Systems reserves the right
to change these without notice. No liability for technical errors
and / or omissions. 112149 03/2025
ON-QT90
Horizontally 2.4 GHz: 95°
Vertically 2.4 GHz: 97°
Horizontally 5 GHz: 99°
Vertically 5 GHz: 60°
2.0:1 max.
2.4 GHz: 6 dBi max.
5 GHz: 6 dBi max.
Light grey
61264
