- Page 1 SMART Electric Height-Adjustable Floor Stand User guide FSE-500-W (FS5-1) Was this document helpful? smarttech.com/docfeedback/171907...
- Page 2 © 2019–2025 SMART Technologies ULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.
-
Page 3: Table Of Contents
Contents Chapter 1 About the stand Features Components Accessories More information Chapter 2 Assembling the stand Environmental requirements Considerations when assembling the stand Chapter 3 Using the stand Calibrating the stand Moving the stand Raising and lowering the stand Chapter 4 Troubleshooting the stand Resolving general issues Recalibrate the stand Resetting the circuit breaker... -
Page 4: Chapter 1 About The Stand
Features Components Control panel Accessories More information Features The SMART electric height-adjustable floor stand has the following features: Feature Description Powered height With its 26" (65 cm) of electric-powered height adjustment, you can easily adjustment adjust the height of a mounted display with the press of a button. -
Page 5: Components
Chapter 1 About the stand Components The stand consists of the following components: Description 1 Vertical VESA mounting brackets 2 Dual-locking 4” casters [Not shown] Back cover (rear surface) Control panel You can raise and lower the stand with the control panel. It’s located on the right side of the stand, but you can remove and attached it to a mounted display. -
Page 6: Accessories
The maximum allowable load is 5 kg. Camera bracket Use the camera bracket to mount a compatible camera on the stand. Note The camera bracket is not compatible with 218 cm SMART Board GX (V2) or 218 cm SMART Board 6000S (V3) displays. Warnings ... -
Page 7: More Information
Chapter 1 About the stand More information See the following resources for more information: FSE-500 specifications: docs.smarttech.com/kb/171921 FSE-500 illustrated installation instructions: docs.smarttech.com/kb/171929 These documents are available in the Support section of the SMART website: smarttech.com/support. docs.smarttech.com/kb/171907... -
Page 8: Chapter 2 Assembling The Stand
Chapter 2 Assembling the stand Environmental requirements Considerations when assembling the stand The stand requires assembly. Consult the SMART electric height-adjustable floor stand illustrated installation instructions (docs.smarttech.com/kb/171906) included with the stand for assembly instructions. Refer to the Important safety instructions (docs.smarttech.com/kb/171939) included with the stand for full safety information. - Page 9 Chapter 2 Assembling the stand Considerations when assembling the stand Warning Two people are required to safely assemble the stand and to mount or remove the display. Lock the casters before installing or working with the display on the stand or adjusting its height. ...
-
Page 10: Chapter 3 Using The Stand
Moving the stand Raising and lowering the stand Raising and lowering the stand manually Raising and lowering the stand using the SMART Electric Stand app Calibrating the stand using the SMART Electric Stand app Setting and using favourite positions Calibrating the stand After assembling the stand, you must calibrate it before you start to use it. -
Page 11: Moving The Stand
Chapter 3 Using the stand Moving the stand Warning Do not move the stand while external cables are connected or when the power is on. Move the display to its lowest position before you move the stand. Secure all cords and cabling before you move the stand. - Page 12 Chapter 3 Using the stand Use the stand only on a flat surface. Ensure cables will not be pulled out or tangled when you lower and raise the display. The FSE-500 (FS5-1) stand is certified for Usage Area IA. This means the stand is intended for use in a classroom setting where children under 8 and users with cognitive disabilities may be present.
-
Page 13: Raising And Lowering The Stand Manually
Chapter 3 Using the stand Raising and lowering the stand manually To raise the stand 1. Press and hold the Up button on the control switch. The stand rises. 2. Release the Up button to stop raising the stand. docs.smarttech.com/kb/171907... -
Page 14: Raising And Lowering The Stand Using The Smart Electric Stand App
2. Release the Down button to stop lowering the stand. Raising and lowering the stand using the SMART Electric Stand app You can control the stand using the SMART Electric Stand app. To download and install the app to your display, see support.smarttech.com/docs/accessories/stands-and-wall-mounts/fse- 500/en/home.cshtml. -
Page 15: Calibrating The Stand Using The Smart Electric Stand App
3. Tap the SMART Electric Stand icon to open the app. 4. Press and hold the Memory 1 button until the display shows SMART electric stand position added. Now when you select the Memory 1 button, the stand will move to this assigned position. -
Page 16: Chapter 4 Troubleshooting The Stand
Recalibrate the stand (see below) The display doesn’t fit Ensure you’re using the mounting plate supplied with the SMART on the stand. display. If you’re using the stand with a third-party display, ensure the stand supports the display’s dimensions and weight. -
Page 17: Recalibrate The Stand
Chapter 4 Troubleshooting the stand Recalibrate the stand If the stand lowers but does not move when you try raising it, or if you replace the controller, you may need to calibrate the stand again. To calibrate the stand 1. Connect the stand to a power outlet. ... -
Page 18: Certification And Compliance
Responsible Party – U.S. Contact Information This equipment has been tested and found to SMART Technologies Inc. comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits... -
Page 19: Eu Declaration Of Conformity
EU Declaration of Conformity Hereby, SMART Technologies ULC declares that the FS5-1 complies with Directive 2014/30/EU. The full text of the EU and UK declaration of conformity is available at the following Internet address: smarttech.com/compliance... - Page 20 SMART Technologies smarttech.com/support smarttech.com/contactsupport docs.smarttech.com/kb/171907...
