SMART  electric
height-adjustable
floor  stand
User guide
FSE-520-B (FS5-3)
Was this document helpful?
smarttech.com/docfeedback/171920

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSE-520-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMART FSE-520-B

  • Page 1 SMART  electric height-adjustable floor  stand User guide FSE-520-B (FS5-3) Was this document helpful? smarttech.com/docfeedback/171920...
  • Page 2 © 2019–2024  SMART  Technologies  ULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written consent of SMART  Technologies  ULC. Information in this manual is subject to change without notice and does not represent a commitment on the part of SMART.
  • Page 3: Table Of Contents

    Contents Chapter 1 About the stand Features Components Accessories Chapter 2 Assembling the stand Environmental requirements Considerations when assembling the stand Chapter 3 Using the stand Calibrating the stand Moving the stand Raising and lowering the stand Chapter 4 Troubleshooting the stand Resolving general issues Recalibrate the stand Resetting the stand after a surge...
  • Page 4: Chapter 1 About The Stand

    Chapter 1 About the stand Features Components Control panel Accessories Features The SMART electric height-adjustable mobile stand has the following features: Feature Description Powered height With its 26" (65 cm) of electric-powered height adjustment, you can easily adjustment adjust the height of a mounted display with the press of a button.
  • Page 5: Components

    Chapter 1 About the stand Components The stand consists of the following components: Description Vertical VESA mounting brackets Dual-locking 4” casters [Not shown] Back cover (rear surface) Control panel You can raise and lower the stand with the control panel. It’s located on the right side of the stand, but you can remove and attached it to a mounted display.
  • Page 6: Accessories

    The maximum allowable load is 11 lb. (5 kg). Camera bracket Use the camera bracket to mount a compatible camera on the stand. Note  The camera bracket is not compatible with 86" (218 cm) SMART Board GX (V2) or 86" (218 cm) SMART Board 6000S (V3) displays. docs.smarttech.com/kb/171920...
  • Page 7: Chapter 2 Assembling The Stand

    Chapter 2 Assembling the stand Environmental requirements Considerations when assembling the stand The stand requires assembly. Consult the SMART  electric height-adjustable mobile stand illustrated installation instructions (smarttech.com/kb/171906) included with the stand for assembly instructions. Warning  Failure to follow the installation instructions included with the stand could result in personal injury or product damage.
  • Page 8 Chapter 2 Assembling the stand Considerations when assembling the stand Warning    Two people are required to safely assemble the stand and to mount or remove the display.   Lock the casters before installing or working with the display on the stand or adjusting its height. Notes ...
  • Page 9: Chapter 3 Using The Stand

    Moving the stand Raising and lowering the stand Raising and lowering the stand manually Raising and lowering the stand using the SMART Electric Stand app Calibrating the stand using the SMART Electric Stand app Setting and using favourite positions Calibrating the stand Calibrating the stand After assembling the stand, you must calibrate it before you start to use it.
  • Page 10: Moving The Stand

    Chapter 3 Using the stand Moving the stand Warning    Do not move the stand while external cables are connected or when the power is on.   Move the display to its lowest position before you move the stand.   Secure all cords and cabling before you move the stand.
  • Page 11: Raising And Lowering The Stand Manually

    Chapter 3 Using the stand   Allow adequate clearance above and below the stand to ensure safe raising and lowering.   Use the stand only on a flat surface.   Ensure cables will not be pulled out or tangled when you lower and raise the display. Caution ...
  • Page 12: Raising And Lowering The Stand Using The Smart Electric Stand App

      2. Release the down button to stop lowering the stand. Raising and lowering the stand using the SMART Electric Stand app You can control the stand using the SMART Electric Stand app . To download and install the app to your display, see support.smarttech.com/docs/accessories/stands-and-wall-mounts/fse- 500/en/home.cshtml.
  • Page 13: Calibrating The Stand Using The Smart Electric Stand App

      3. Tap the SMART Electric Stand icon to open the app.   4. Press and hold the Memory 1 button until the display shows SMART electric stand position added. Now when you select the Memory 1 button, the stand will move to this assigned position.
  • Page 14: Chapter 4 Troubleshooting The Stand

      Recalibrate the stand (see below)   The display doesn’t fit Ensure you’re using the mounting plate supplied with the SMART on the stand. display.   If you’re using the stand with a third-party display, ensure the stand supports the display’s dimensions and weight.
  • Page 15: Recalibrate The Stand

    Chapter 4 Troubleshooting the stand Recalibrate the stand If the stand lowers but does not move when you try raising it, or if you replace the controller, you may need to calibrate the stand again. To calibrate the stand   1. Connect the stand to a power outlet.  ...
  • Page 16 Chapter 4 Troubleshooting the stand docs.smarttech.com/kb/171920...
  • Page 17: Important Information

      Use the stand only for it’s intended use as described in these instructions. Do not use attachments not recommended by  SMART  Technologies.   Do not operate the stand if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or if it has been dropped into water.
  • Page 18   Use only SMART-supplied mounting hardware or hardware that is designed to properly support the weight of the mounted display and accessories.   Use the FSE-520 (FS5-3) stand only with displays with diagonal measurements that range from 55"...
  • Page 19   Do not use the stand if the power cord is damaged. Replace a damaged power cord only with a new cord provided by SMART Technologies or a qualified service technician.   Do not modify or make changes to the control unit or hand switches.
  • Page 20 Important information   Refer all servicing to qualified service personnel. Servicing is required when the stand has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the stand, the stand has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 21: Federal Communication Commission Interference Statement

    Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: FS5-3 Responsible Party – U.S. Contact Information SMART Technologies Inc. 2401 4th Ave, 3rd Floor Seattle, WA 98121 compliance@smarttech.com docs.smarttech.com/kb/171920...
  • Page 22: Innovation, Science, And Economic Development Canada Statement

      2. ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. EU Declaration of Conformity Hereby, SMART Technologies ULC declares that the FS5-3 complies with Directive 2014/30/EU. The full text of the EU and UK declaration of conformity is available at the following Internet address: smarttech.com/compliance...
  • Page 23 SMART Technologies smarttech.com/support smarttech.com/contactsupport docs.smarttech.com/kb/171920...
