Summary of Contents for Tescom TEOS+100RT

Page 1 TEOS+ 100RT 6-10 kVA 1 Phase In – 1 Phase Out USER MANUAL...
Page 3: Table Of Contents
Table of Contents Important Safety Instructions ..............1 1 Product Description ................2 1.1 Declaration of Safety Conformity and CE marking ............2 1.2 Electromagnetic Compatibility..................2 1.3 Features ..........................3 1.4 Models ..........................3 1.5 Appearance ........................4 1.6 System Description ......................6 1.7 UPS Working Mode ......................
Page 4 7 Troubleshooting ................34 Annex A Parallel Setting ................38 Annex B Battery Run Time ..............39...
Page 5: Important Safety Instructions
Important Safety Instructions Save these instructions This manual contains important safety instructions. Read all safety and operating instructions before operating the uninterruptible power systems (UPS). Adhere to all warnings on the unit and in this manual. Follow all operating and user instructions. This equipment can be operated by individuals without previous training.
Page 6: Product Description
Declaration of Safety Conformity and CE marking TESCOM UPS system is designed and manufactured in accordance with ISO 9001 Quality Management Systems and ISO 14001 Environmental Management System standards. The CE marking indicates compliance with the EEC Directive by the application of the following standards in accordance with the specifications of the harmonized standards: •...
Page 7: Features
NOTICE： This is a product for restricted sales distribution to informed partners. Installation restrictions or additional measures may be needed to prevent radio interference. Operated the UPS in an indoor enviroment only in an ambient temperature range of 0-40C(32- 104F). Install it in a clean environment, free from moisture, flammable liquids, gases and corrosive substance.
Page 8: Appearance
1.5 Appearance Teos+106RTXL / Teos+110RTXL Teos+106RT / Teos+110RT Fig 1- 1: Front View Teos+106RTXL / Teos+110RTXL（1/1） Teos+106RT /Teos+110RT（1/1）...
Page 9 Teos+106RTXL /Teos+110RTXL（3/1） Teos+106RT /Teos+110RT（3/1） Fig 1- 2: Rear View As shown in Fig 1-2, the rear panel provides the following compoentes and function: SNMP: DB9 type, used to connect monitoring software Fans: intelligent fan speed control Parallel port: option RS232: DB9 type, used to connect monitoring software EPO: NO USB: B type, used to connect monitoring software Temperature option...
Page 10: System Description
1.6 System Description TVS&RFI/ EMI filter Input Output Battery Fig 1- 3: UPS system 1.6.1 Transient Voltage Surge Suppression (TVSS) and EMI/FRI Filters These UPS components provide surge protection and filter both electromagnetic interference (EMI) and radio frequency interference (RFI). They minimize any surge or interference present in the utility line and keep the sensitive equipment protected.
Page 11: Ups Working Mode
power. 1.6.5 DC to DC Converter The DC to DC converter utilizes energy from the battery system and raises the DC voltage to the optimum operating voltage for the inverter. The converter includes boost circuit which is also used as PFC. 1.6.6 Battery The Teos+106RT/Teos+110RT Standard includes value regulated, sealed lead acid,...
Page 12 Fig 1- 5: Bypss Mode Battery Mode If input power is failure when in normal mode, UPS will transfer to battery mode. In this mode, the battery provide power to inverter. Shown as Fig 1-6. NOTICE: press“ ”in battery mode will shutdown UPS completely. Fig 1- 6: Battery Mode ECO Mode (only available for single unit) When UPS works in ECO mode, load is feed by bypass.
Page 13: Product Specifications
Fig 1- 7: ECO Mode Frequency Converter Mode In this mode, input and output nominal frequency is different, and the bypass is forbidden to use. NOTICE: if overload timeout, UPS will shutdown output. NOTICE: the load should be derated to 50% and below. Self Aging Mode If users want to burn in UPS without load, could set the UPS as Self Aging Mode, in this mode, the current flow through rectifier, inverter, and back to input through bypass.
Page 14 Input Model Voltage Frequency Power Factor Single-phase 40 - 70 Hz > 0.99 (Full load) Output Voltage Power Frequency Regulatio Distortion Overload capacity Crest ratio Factor tolerance. 110% load: transfers to Bypass mode after minutes THD < 1% 125% load: transfers to 0.1 of Full load 1%...
Page 15: Installation
2 Installation The system should be installed and wired only by qualified electricians in accordance with applicable safety regulations. NOTICE：UPS operation in sustained temperature outside the range of 15 - 25C (59 - 77F) reduces battery life. 2.1 Unpacking and Inspection 1.
Page 16 Fig.2-1 Support bases Step 2: If optional external battery cabinets are connected to the UPS to provide additional battery run time, assemble the spacers and the support bases, as shown in Fig.2-2. Fig.2-2 Installing support bases with spacers Step 3: Adjust the direction of UPS operation and display panel. 1.
Page 17 90° Rotating Fig.2-4 Rotating the operation and display panel 3. Restore the front plastic bezel cover to the UPS. At this point, the UPS operation and display panel have been rotated 90 degrees clockwise, which provides upright viewing for users. Step 4: Place the UPS (and battery cabinet) on the support bases.
Page 18 installation personnel are required to install them at the same time. Please install them from bottom to top. Rack installation: fix the UPS and battery cabinet onto the rack through brackets. Installation method: 1. Take out two brackets and six M4 screws from the accessories, and fix the brackets onto the UPS using the screws through installation hole, as shown in Fig.2-6.
Page 19: Connect Input/Output Power
2.3 Connect Input/Output Power 1. Notes for installation (1) The UPS must be installed in a location with good ventilation, far away from water, inflammable gas and corrosive agents. (2) Ensure the air vents on the front and rear of the UPS are not blocked. Allow at least 0.5 m of space on each side.
Page 20: Connect The Long Backup Time Model Ups With The External Battery
OUT_L OUT_N BAT+ BAT- BYP_L IN_L3 IN_L1 IN_L2 IN_N Teos+106RTXL/ Teos+106RT Teos+110RTXL/ Teos+110RT (3/1) Fig 2- 8: Terminal Block Wiring Diagram NOTICE：Make sure that the input and output wires and the input and output terminals are connected tightly. (4) Connect the input, output and battery wires to the terminals as Fig 2-8. (5) The protective earth ground wire refers to the wire connection between the equipment which consumes electric equipment and the ground wire.
Page 21: Connect Parallel Cables
2. For UPS 6/Teos+110RTXL, select the UL1015 10/8 AWG (6/10 mm ). For UPS 15/20KH, select 6/4 AWG (16/25 mm ) wire or other insulated wire which complies with UL Standard for the UPS battery wirings. The procedure of installing battery bank should be complied with strictly. Otherwise you may encounter the hazardous of electric shock.
Page 22 UPS 1# UPS 2# BAT. INPUT INPUT BAT. BAT2 BAT2 BAT1 BAT1 INPUT INPUT Teos+106RTXL/ Teos+106RT Teos+110RTXL/ Teos+110RT UPS 1# UPS 2# INPUT INPUT BAT2 BAT1 OUTPUT INPUT L2 L3 Teos+106RTXL/ Teos+106RT Teos+110RTXL/ Teos+110RT (3/1) Fig 2- 9: Parallel Wiring Diagram...
Page 23: Connect Communication Cables
2.6 Connect Communication Cables Connect communication cables: If there are 2 UPS are paralleled, connect communication cables as Fig 2-10. UPS 1# UPS 2# Fig 2- 10: 2 UPS Paralleled System If there are 3 UPS are paralleled, connect communication cables as Fig 2-11. UPS 1# UPS 2# UPS 3#...
Page 24: Controls And Indicators
3 Controls and Indicators Fig 3- 1: Display Panel Description of Panel Controls Description 1. Press “ ” to power on the UPS from battery without utility power. NOTE Not available when UPS is set in automatically start mode 2. Press “ ”...
Page 25 Indicators Description Inverter indicator: green--inverter is normal, green flicker— rectifier or inverter is starting or tracking with bypass(ECO), dark—rectifier and inverter is not working Battery indicator: yellow—battery discharged, yellow flicker— No battery or battery alarm, dark—battery is connected Bypass indicator: yellow—bypass is normal, yellow flicker— bypass is abnormal and alarm ,dark—UPS is in normal mode and bypass is normal FAULT indicator: red—UPS is abnormal, red flicker—UPS...
Page 26  The area of event log query page showing page number of history records  In non-setting interface, it indicates the relevant information of UPS. Press the “ ” or “ ” button to display input voltage and frequency, output voltage and frequency, battery voltage and capacity, pieces of battery, load, temperature, software version, etc.
Page 27 Page 3: Display UPS load information Page 4: Display UPS software version and temperature information Page 5: Display UPS input information Page 6: Display UPS battery voltage, battery capacity percentage...
Page 28 Page 7: Display UPS battery numbers, Warning code Page: Display UPS warning code (ALA means alarm) warning code information refer to “troubleshooting”. H - history, H01 - first history event. 044 - history event code. StS 0-event appears. 1- event disappears History event query is for qualified personnel use only.
Page 29 Charger Charger current could be set as current follow, Press “ “ ” or ” setting select, press ” to confirm “ selection Standard model:1A Long backup model :1,2,3,4,5A Optional charger 12A for 6- 10kVA:1-12A Optional charger 10A for 15- 20kVA：1-10A Parallel ID 1- parallel Id 1...
Page 30 Rated Could select rated voltage as 208 voltage Vac / 220 Vac / 230 Vac / 240 Vac, setting press “ to select, “ ” or ” press ” to confirm selection. “ The setting will be activated after restart UPS. Could select mode ON: enable...
Page 31 Rated Could select rated frequency as frequency 50 Hz / 60 Hz, press “ ” or setting “ to select, press ” to ” “ confirm selection. The setting will be activated after restart UPS. NOTICE: when rated voltage is 200 / 208 Vac, the output PF is 0.9. If other parameters are needed to change, please set it via monitoring software.
Page 32: Operation
4 Operation 4.1 Operation Mode 4.1.1 Turn on the UPS in Normal Mode (1) After you make sure that the power supply connection is correct, and then close the battery breaker (this step only for long backup time model), after that close the main input and bypass input breaker.
Page 33: Parallel Operation
4.2 Parallel Operation 4.2.1 Turn on the UPS of Parallel System Make sure the power cables and communication cables are correctly. Shown as Fig 2-9, Fig 2- 10, Fig 2-11: (1) Close external output CB1 and CB2. (2) Close mains input breakers and bypass input breakers of UPS1 and UPS2, after about 2 minutes, UPS work in parallel mode.
Page 34: Rs232 And Usb Port
NOTICE: Only one of SNMP card, dry contact and RS485 can be at the same time. Only one of RS232 and USB is available at the same time. Connect the UPS and monitoring equipment (computer) by standard RS232 port (standard configuration) and standard USB port (optional configuration) to make single unit communication.
Page 35  SNMP card (optional) SNMP card is used to monitor the UPS via TCP/IP, user can check the UPS status, voltage and current on the internet. Please refer to the user manual of SNMP card to get more detailed information. ...
Page 36: Maintenance
6 Maintenance This chapter includes battery maintenance, battery disposal and replacement, check UPS status and function. 6.1 Battery Maintenance The UPS only requires minimal maintenance. The batteries used for standard models are value regulated, sealed lead-acid, maintenance free battery. When being connected to the utility power, whether the UPS is turned on or not, the UPS keeps charging the batteries and also offers the protective function of overcharging and over-discharging.
Page 37: Battery Replacement Procedures
6.3 Battery Replacement Procedures (1) Press “ ” button to transfer to bypass mode (2) Close the manual bypass breaker (3) Remove both side covers from the UPS. (4) Disconnect the battery wires one by one. (5) Remove metal bars which are used to fasten batteries. (6) Replace batteries one by one.
Page 38: Troubleshooting
7 Troubleshooting This chapter describes checking the UPS’s status. This section also indicates various UPS symptoms a user may encounter and provides a troubleshooting guide in the event the UPS develops a problem. Use the following information to determine whether external factors caused the problem and how to remedy the situation.
Page 39 Inverter is overload, please remove numbers of non-critical loads, or else UPS could transfer to bypass 50 - 54 Overload If bypass overload, Check the load and remove some non-critical load until the load is below 55 - 59 Negative power fault Please contact your supplier.
Page 40 Warning code informing: Warning Warning name Solutions code Check if all parallel communication cables are Parallel cables error connected correctly Check if battery cables are connected correctly Battery reversed Check if inverter cables of battery packs are connected correctly Remove non-critical devices to reduce the loads Overload connected to UPS.
Page 41 Check whether the parallel wire connecting and Parallel current unbalance parallel boards are abnormal or not. Battery maintenance ok Battery maintenance abnormal Input current unbalance Mains and battery transfer for 5 times in 1hour,while Over transfer times Bus is low UPS mains input is abnormal.
Page 42: Annex A Parallel Setting
Annex A Parallel Setting 1. Connect UPS1# with RS232 cable to PC. Connect UPS with monitoring software “iServerceTool”. Select “EA900P6-20K G4”. 2. Enter in menu “Settings”, set “device address” as “1”and “baud rate” as “9600”, select the right serial port in menu “Communication Setting”. Click “OK” to connect UPS 3.
Page 43 Annex B Battery Run Time Standard battery pack includes 16 blocks 9 Ah batteries. Please refer to the table below for the battery runtime to configure battery packs. Pack’s Backup Time (mins) number 10kW NOTICE: Backup time of batteries is depending on other facts such as battery brand, working temperature, working time and so on, the table is calculated according to ideal situation.
Page 44 Recycling information in accordance with the WEEE The product is marked with the wheelie bin symbol. It indicates that at the end of life the product should enter the recycling system. You should dispose of it separately at an appropriate collection point and not place it in the normal waste stream.
