- Page 1 T-300P SERIES T-3250 T-3300 250-300 kVA 3 Phase Input / 3 Phase Output (12 Pulse Rectifier) USER MANUAL...
-
Page 3: Table Of Contents
CONTENTS SAFETY..............................1 GENERAL DESCRIPTION ......................... 2 1.1 Introduction ..........................2 1.2 Design Concept ........................... 3 1.2.1 The Operating Modes of UPS ................... 4 1.2.2 The Power Configuration of UPS..................4 1.3 Technical Specifications......................7 FRONT PANEL ..........................8 2.1 Introduction ..........................8 2.2 Alarms And Status Messages ..................... - Page 4 INSTALLATION PROCEDURE ......................24 5.4 Introduction ..........................24 5.5 Unpacking ........................... 24 5.6 Equipment Positioning ........................ 24 5.7 Connecting The UPS Power Cables ................... 25 5.7.1 Safety Earth ........................26 5.7.2 Cable Connections......................26 5.7.3 Battery Installation ......................27 5.7.4 The Communication (UPS-Server) ................... 29 VI.
-
Page 5: Safety
SAFETY This manual contains important instructions for T-300P series UPS that should be followed during installation and maintenance. IMPORTANT NOTICES 1. Read instructions carefully before operating the UPS 2. All warnings in the manual should be adhered to. 3. All operating instructions should be followed. 4. -
Page 6: General Description
I. GENERAL DESCRIPTION 1.1 Introduction T-300P Uninterruptible Power Supplies, are On-Line UPS’s, being manufactured with the state-of-the art PWM and IGBT technology, produce microprocessor controlled pure sine wave output to critical loads. T-300P series UPS’s install between the critical load and the mains. The advantages of using UPS: •... -
Page 7: Design Concept
1.2 Design Concept Mechanic Transfer Switch Maintenance By-pass Static Transfer Switch Static By-pass 3 Phase 3 Phase Line Load Input Output Inverter 12 Pulse Rectifier Battery Group Figure 1-1 Block Diagram : Inverter input power switch : Static by-pass input switch : Maintenance by-pass power switch : UPS power output witch... -
Page 8: The Operating Modes Of Ups
MECHANIC TRANSFER SWITCH (MAINTENANCE BY-PASS): A second, manually controlled, ”maintenance by-pass” supply is also incorporated into the UPS design. Its purpose is to enable the critical load to be powered from the mains (by-pass) supply while the UPS is shut down for maintenance or troubleshooting. The load is unprotected against mains power supply aberrations or failure when it is connected to either the static by-pass or maintenance by-pass supply. - Page 9 Mechanic transfer switch Maintenance Bypass Static Transfer Switch 3 Phase By-Pass Static By-Pass Supply Input 3 phase 3 Phase load Line output Input Inverter 12 pulse Rectifier Battery group Figure 1.2 UPS Split (external) By-Pass Block Diagram...
- Page 10 Battery Current Sensor Battery Fuse ( - ) 12 Pulse Rectifier Input RS232 Communication Port (DB9 Female) Battery Circuit Emergency Line Failure Battery Low By-Pass Breaker Input Stop Relay Relay Relay Dry Relay Output Contacts Figure 1.3 250-300 kVA Power Switch Locations...
-
Page 11: Technical Specifications
1.4 Technical Specifications GENERAL SPECIFICATIONS Output Power (kVA) Output Power (kW) Output Power factor Parallel Operation Up to 2 UPS or 1 Redundant Hot Stand-by Operation 2 UPS (1 Redundant) Battery charging temperature compensation Optional INPUT Number of phases Input voltage 220/380 Vac or 230/ 400 Vac 3 phase +N Voltage tolerance +15% , -15%... -
Page 12: Front Panel
II. FRONT PANEL 2.1 Introduction The front panel of UPS, consisting of a 2 lines alphanumeric display, 7 status lamps, plus 5 function keys, allows the complete monitoring of the UPS status. The mimic flow diagram helps to comprehend the operating status of the UPS. - Page 13 ALARM DESCRIPTION A4 OUT FAILURE UPS output voltage is out of tolerance at 3 times in 30 min. Internal failure. Call service. A5 BATT AUT END Batteries empty at last of line out. Wait to return of electric. A6 CHARGER FAULT Rectifier is not to produce DC bus voltage.
- Page 14 ALARM DESCRIPTION A28 P.FAILURE 21 Parallel controller board failure A29 P.TEST MODE Paralel controller is in test mode A30 P FAILURE 23 Parallel controller board failure A31 DUBL UPS NR. Same UPS number is used in parallel system. Possible Causes: 1) Change from settings menu Power supply is not functioning possibly because either of a wrong phase A39 PSP FAILURE sequence or rectifier fault.
-
Page 15: Menu Description
WARNING STATUS : Some events recorded to log event file stays on LCD PANEL but UPS continues to work, these messages named as warning messages, user can clear this messages by pressing ENTER key for 3 seconds. These are: • A20 Boost charge alert •... - Page 16 Menu and submenu items MAIN MENU SUBMENU MEANING MEASURES MENU LD%: 050 030 060 Output load OPV: 220 221 219 V Output voltage FREQU: 50.0 Hz Output frequency IPV: 240 230 226 V Input voltages BYP: 225 221 219 V Bypass source voltages IPI: 031 040 020 A Ginput currents...
-
Page 17: Main Menu
MAIN Menu The main menu items is given at the following table you can move on main menu items by using UP and DOWN keys. Main Menu item Function STATUS MENU The status message which shows the UPS status → Enter MEASURES MENU "go to Meausures submenu"... -
Page 18: Information Menu Items
2.7 INFORMATION Menu Items This menu gives some information about UPS. Submenu item Function If the UPS is operating syncron to mains SYNC:OK ,if not syncron SYNC:-- SYNC :OK COMM :OK If communication is active COMM:OK ,if not active COMM:-- POWER: 25000 VA The maximum power rating of the UPS VERSION : MC1xx... -
Page 19: Command Menu Items
2.9 COMMAND Menu Items You can give immediate commands to ups by using this menu. Submenu items Function Use for turn on/off beep alert sound. If you press ENTER key the option will change, one press ON, one press SOUND : ON/OFF OFF. -
Page 20: Time Menu Items
2.10 TIME MENU Items You can ses date and time of RTC (real time clock) on UPS. And you can adjust date and time. Submenu item Function TIME : 23 :15 time DATE : 11-10-2006 date SET HOURS: 11 (+) and (-) adjust hours (0-23) SET MINS : 38 (+) and (-) adjust minutes (0-59) SET DAY : 21... -
Page 21: Parallel Operation
III. PARALLEL OPERATION 3.1 Introduction Two of T-300P UPS can be used in parallel mode, the purpose of parallel use: • Increasing security • Redundancy • Power increment purpose 3.1.1 Security At stand alone UPS systems mains voltage is spare energy in case of UPS failure, but some critical loads don’t works with mains tolerances. -
Page 22: Redundant Parallel Mode
The general diagram of parallel connection is shown below : UPS1 BATT.1 AC/DC -1 INVERTER 1 OUTPUT UPS2 BATT.2 AC/DC -2 INVERTER 2 Figure 3-1 Parallel connected UPS The inputs of two UPS is connected to mains, outputs of two UPS is connected to each other there is two battery group. -
Page 23: Hot Standby Mode
3.2.3 Hot Standby Mode If current sharing is active two UPS is operating continuesly and lifetime of some parts will be shorten. Hot standby mode is solution for UPS lifetime. In this mode UPS 1 feeds the load and the UPS 2 waits spare there is no current it is in standby mode but it is ready to work. - Page 24 IMPORTANT NOTE: Parallel system installation is much more complex from stand alone UPS installation, it needs qualified sevice personnel. You have to keep 80 cm distance between two UPS for service purposes. The maximum length of digital and analog cable is 2 meters. Add %20 tolerant to cables, fuses and circuit breakers in parallel connection.
-
Page 25: Operating Instructions
IV. OPERATING INSTRUCTIONS 4.1 Introduction UPS can operate in one of the following operating modes: a) Normal Operation : All the circuit breakers (except the maintenance by-pass switch) are turned on (“1” position) and load is connected to the UPS. b) Maintenance By-Pass Operation : Ups is not in use because of maintenance purposes. -
Page 26: Procedure For Switching The Ups Into A Maintenance Bypass From Normal Operation
4.3 Procedure For Switching The UPS Into a Maintenance Bypass From Normal Operation This procedure should be followed when turning from normal operation to maintenance bypass. This procedure can be used in giving temporary mains voltage to the system during the maintenance of the UPS or in case of failure. -
Page 27: Procedure For Switching The Ups On From Static By-Pass
Procedure For Switching The UPS ON From Static By-Pass Press on the UP or DOWN button until there is “COMMAND MENU” message on the front panel of the UPS. Then press “ENTER” button. Press on the UP or DOWN button when there is “ENTER <INVERTER>” message on the front panel of the UPS. -
Page 28: Installation Procedure
V. INSTALLATION PROCEDURE 5.1 Introduction WARNING!!! • Do not apply electrical power to the UPS equipment before the arrival of authorized service personnel. • The UPS equipment should be installed by a qualified service personnel. • The connection of the batteries and the maintenance should be done by the qualified service personnel. •... -
Page 29: Connecting The Ups Power Cables
5.4 Connecting The UPS Power Cables CAUTION! Only qualified personnel should install or service UPS / batteries. The ac input to the UPS should be supplied by a separate line from the ac distribution board. The input/output cables can be sized to suit the modules rating according to the table below. The connections of the electric panel should be supplied by grounded outlet. -
Page 30: Safety Earth
NOTES: The neutral conductor should be sized for 1,5 times the output/bypass phase current. The Earth conductor should be sized at 2 times the output/bypass conductor (this is dependent on the fault rating, cable lengths, type of protection etc.) These recommendations are for guideline purposes only and are superceded by local regulations and codes of practice. - Page 31 NORMAL CONNECTIONS SPLIT BY-PASS CONNECTIONS Figure 5-2 250-300 kVA UPS Power Connections...
-
Page 32: Battery Installation
5.7.7 Battery Installation ATTENTION!!! Remove the battery fuse before making the connection of the battery circuit breaker box during the battery installation. The batteries associated with the UPS equipment are usually contained in a purpose-built battery cabinet, which sits alongside the main UPS equipment. Sealed, maintenance-free batteries are normally used in this type of installations. - Page 33 BATTERY GROUP-1 BATTERY GROUP-2 Figure 5-3-a 250 kVA UPS Battery Group Connections...
- Page 34 BATTERY GROUP-1 BATTERY GROUP-2 optional Figure 5-3-b 300 kVA UPS Battery Group Connections...
-
Page 35: The Communication (Ups-Server)
5.7.8 The Communication (UPS-Server) Dry relay alarm contacts or optional RS232 communication port can be used to inform the user about any possible alarm like “Battery Low” “Line Failure” “Load On By-pass”. The relay interface AS400 and Windows NT is an special edition for the systems. You should use ITF3 and RS330 board for the communicate with the PC. -
Page 36: Customer Service
VI . CUSTOMER SERVICE WARNING! There are no customer serviceable components inside. DO NOT open the cover or attempt to service the unit. High voltage may remain when the unit is shut down. Unauthorized service will void the warranty and could cause serious injury. 6.1 Maintenance The unit is designed for easy maintenance. -
Page 37: Remote Monitoring And Control
VII. REMOTE MONITORING AND CONTROL Following external connections are available at T-300P series • Communication By serial port connection • Dry contact (interface board) connection • Remote panel monitoring 7.1 Using Serial Port A standart Serial communication port is installed to all T-300P series UPS, by using this port user can take all information about UPS. -
Page 38: Hardware Configuration
7.3.1 Hardware Configuration All needs for modem connection is as follows: • PC with modem • WINDOWS 98 • Available UPS control software • DUMP modem which is connected to UPS In order to perform this function a PC with UPS control software and an external or internal modem device connected to telephone line are needed. -
Page 39: Dry Contact (Interface) Connection
7.4 Dry Contact (Interface) Connection Some important events can be monitored by this connection for each event a relay is located on interface board and NC-C-NO contacts are connected terminals. these events are: • LINE FAILURE • BATTERY LOW • LOAD ON BYPASS •... -
Page 40: Limited Warranty
VIII. LIMITED WARRANTY The UPS is warranted against all defects in workmanship and materials under normal use for a period of one ) year from the date of shipment to the original user. The conditions of this warranty and the extent of responsibility of ……………………………………………………………………………………………………………………... - Page 42 AGKK6142 02/2010...
