Infineon CYW9RPI55513-EVK Quick Start Manual

Wi-fi & bluetooth evaluation kit with raspberry pi cm4 host (with cyw55513 radio m2 card)

Download this manual

QUICK START GUIDE

Wi-Fi & Bluetooth

CM4 Host (with CYW55513 radio M2 card)

CYW9RPI55513-EVK

Kit contents

1. CYW9RPI55513-EVK evaluation board

(with Raspberry Pi CM4 module and CYW55513 radio M2 card)

2. Two tri-band dipole antennas

www.infineon.com/CYW9RPI55513-EVK

Evaluation Kit with Raspberry Pi

3. USB-C to USB-C cable

4. Quick start guide (this document)

Need help?

Do you have a question about the CYW9RPI55513-EVK and is the answer not in the manual?

Page 1 ® CM4 Host (with CYW55513 radio M2 card) CYW9RPI55513-EVK Kit contents 1. CYW9RPI55513-EVK evaluation board 3. USB-C to USB-C cable (with Raspberry Pi CM4 module and CYW55513 radio M2 card) 4. Quick start guide (this document) 2. Two tri-band dipole antennas...
Page 2 Before you start 1. Ensure that you have the following: – PC with USB-C port – USB-compatible mouse and keyboard – Monitor with HDMI interface – Pre-flashed SD card present in the SD card slot (J17) 2. Connect the dipole antenna to SMA connectors (ANT1, ANT2) on the baseboard and connect the antenna cable assembly to the UFL connectors (Main and Aux) on the M.2 radio card.
Page 3 Getting started with Serial console access To access the serial debug console of the CYW9RPI55513-EVK, do the following: 1. Ensure that you have the following: – PC with USB-C port – UART terminal so ware such as Tera Term or Minicom 2.
Page 4 *Component is located at the bottom side of the board. **Component is not mounted on the board. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Infineon is under license. Published by Infineon Technologies AG All rights reserved.
