CYW920820M2EVB-01 evaluation kit user guide
CYW20820

About this document

Scope and purpose
CYW20820M2EVB-01 is an evaluation kit for the AIROC™ CYW20820 Bluetooth® & Bluetooth® LE SoC, designed to
support several medical, security, and industrial applications. The system features an Arm® Cortex®-M4 core
with programmable and reconfigurable analog and digital blocks. It is a combination of a microcontroller with
the following:
Auxiliary ADC with up to 28 analog channels
Digital peripherals such as PWMs
Bluetooth® stack, peripheral drivers, and security functions built into the ROM allowing applications to
efficiently use on-chip flash
5-dBm Tx output power (LE), 11.5-dBm Tx output power (BR), 2.5-dBm Tx output power (EDR)
Serial communication interfaces such as I
Over-the-air (OTA) firmware updates
Intended audience
This document is intended for anyone using the CYW20820M2EVB-01 evaluation board.
Document conventions
Table 1
Conventions
Convention
Explanation
Bold
Emphasizes heading levels, column headings, table and figure captions, screen names,
windows, dialog boxes, menus and sub-menus
Italics
Denotes file/folder names
Courier New
Denotes APIs, functions, interrupt handlers, events, data types, error handlers, command
line inputs, code snippets
>
Indicates that a cascading sub-menu opens when you select a menu item
User guide
Please read the sections "Important notice" and "Warnings" at the end of this document
www.infineon.com
C, UART, PCM, and Quad-SPI
2
002-35512 Rev. *A
2024-07-23
