- Page 1 Horizon Elite Ice Machine Models with RIDE Technology ™ ™ Installation Instructions for Vision ™ D710, E710, C1010, C1410 Order parts online www.follettice.com 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 www.follettice.com 01113208R06...
- Page 2 CAUTION! • This appliance should be connected by a qualified person in accordance with applicable codes. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Docking assembly Dispenser preparation Ice transport tube External connection Internal connection Front cover VISION • RIDE Technology self-contained...
-
Page 4: Unpack Ice Machine
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ VISION • RIDE Technology... -
Page 5: Prepare The Installation Site
• 10-70 psi (69-483 kpa) • 45 to 90 F (7 to 32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Bin Signal Installation ➏ ➎ ➐ ➋ Ground ➌ ➊ 24" (610 mm) ➌ • Mount the electrical box to the side of the Vision dispenser ➊ to establish a ground connection. Note: If a 4 x 4 box is mounted to a non-grounded surface, connect ground wire at an appropriate ground. •... -
Page 7: Before Proceeding
Docking assembly Install the docking assembly. BEFORE PROCEEDING Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting. - Page 8 Undercounter installation detail Front View Top View Access panel/ door on counter ➌ ➊ 2" (51 mm) ➍ 1010/1410: 2.25" (57 mm) 710: 2" (51 mm) bottom of ice machine side of ice machine 1010/1410: 2" (51 mm) 710: 3.25" (82.55 mm) CAUTION •...
-
Page 9: Ice Transport Tube
Ice transport tube Install the ice transport tube. Ice transport tube installation. ➋ Hot Water 160 F (71 C) ➎ ➍ ➏ ➐ ➊ 1/4" ➌ Ice transport tube tips • One end of the ice transport tube has 1/8" holes drilled into it; this end connects on the inside of the Vision dispenser. - Page 10 Dispenser ice transport tube installation Ice tube retainer bracket 1" (25mm) ice tube retaining bracket ice tube ice tube Front View Front View VU155 VU300 ice tube retaining bracket thermostat thermostat ice tube retaining bracket tabs in ice tube tabs in ice tube ice tube retainer bracket retainer bracket...
-
Page 11: External Connections
External connections Connect utilities to docking assembly. Air-cooled ice machines only Water-cooled ice machines only ➊ ➊ ➋ ➏ ➋ ➐ ➌ ➌ Minimum 8" ➏ Minimum 8" ➑ radius radius 2 ft. x 1" OD 2 ft. x 1" OD silicone tubing silicone tubing 3/4"... - Page 12 Chassis drain plumbing - required • Plug must be removed from John Guest fitting. • Route 3/8" drain tubing through knockout in back of docking station and insert fully into John Guest fitting connection at the rear of the machine chassis. Route other end of 3/8"...
-
Page 13: Internal Connections
Internal connections Connect docking assembly to ice machine. CAUTION • Plug must be accessible after final installation. • E710 230/50/1 requires a 15A circuit (1.50 mm wire) Air-cooled ice machines – follow steps 7.1 through 7.5. Water solenoid, shut-off valve, Ice transport tube and potable water line options If water solenoid is already mounted to... - Page 14 Water-cooled ice machines – follow steps 7.6 through 7.12. Cooling lines Set TDS switch HIGH CLEAN • Install ice machine cooling water lines to • Set the TDS switch on the electrical box: docking assembly HIGH: for extended service life LOW: for low-scale water Ice transport tube Water solenoid, shut-off valve,...
- Page 15 7.10 Power cord Cooling lines and power ➋ ➊ • Remove twist tie • Carefully pass cord through opening and • Connect cooling water lines to ice plug into wall outlet machine ➊ • For H_E units, install a suitable plug •...
-
Page 16: Front Cover
Front cover Install front cover to ice machine. Install front cover Front cover installation – air-cooled undercounter only ➊ ➋ ➋ ➌ ➊ ➌ • Slide ice machine cover over machine ensuring that tabs on back of cover slip under louvers on back of docking ➊... - Page 17 Long tube run recommendations max. 2 ft (.6m) ➊ 1/4" ➋ • Pitch ice transport tube to allow melt water to drain towards ice machine ➊ • Secure insulated ice transport tube at least every 2 ft (0,6 m) to prevent dips or traps ➋...
- Page 18 VISION • RIDE Technology self-contained...
- Page 19 VISION • RIDE Technology self-contained...
- Page 20 Maestro, Vision, Ice Manager, Horizon, Horizon Elite are trademarks of Follett Products, LLC. Chewblet, RIDE, Follett are registered trademarks of Follett Products, LLC. 801 Church Lane • Easton, PA 18040, USA 01113208R06 Toll free (877) 612-5086 • +1 (610) 252-7301 ©...
