  • Page 1 Network Camera Installation Manual DC-D2233WHX Powered by...

  • Page 2: Before Reading This Manual

    Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.

  • Page 3: Safety Precautions

    Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.

  • Page 4: Fcc Compliance Statement

    © 2016 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    • Two-way audio communication support for remote You can use the IDIS Discovery program to change audio dialog network camera settings or the IDIS Solution Suite • Video stream buffering to counter pre-/post-event...
  • Page 7 • Network-based integrated management of multiple Remote monitoring and recording via multistreaming network cameras are available using the IDIS Solution Suite Compact program. For more information on using IDIS Solution • Multiple event detection modes Suite Compact, refer to its operation manual.

  • Page 8: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. Network Camera Open Source Guide Quick Guide Allen Wrench Screws (3 ea.) Desiccant CVBS Cable Guide Pattern...

  • Page 9: Overview

    Part 1 – Introduction Overview Dome Cover Screw Hole Safety Wire Dome Cover Screws Dome Cover Assembly Notch Dome Cover • Dome Cover Screw Hole Secures the dome cover to the camera. • Safety Wire Prevents the dome cover from falling on to the floor when detached from the camera.

  • Page 10: Body

    Part 1 – Introduction Body • Lens motorized focus and zoom lens is installed. • IR LED A sensor in the middle monitors lighting levels and activates the IR LED during low-lighting conditions. • Factory Reset Switch Button Restores the camera's default factory settings. For more information, refer to the Factory Reset.

  • Page 11: Factory Reset

    Part 1 – Introduction • Lens Rotator • Bottom Cover Loosen the rotator screw, and turn the lens rotator Allows you to install the camera on a wall or a ceiling. clockwise or counterclockwise to adjust the lens' • Wall/Ceiling Installation Hole rotation angle by using the lens rotator handle.

  • Page 12: Lens

    It's also possible to do a factory reset by pressing and releasing the reset button while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual.
  • Page 13 Part 1 – Introduction • Audio The table below shows the network cable specifications. - Out: Connect an amplifier to this port (line out). This <The network cable specifications> device does not feature a built-in audio amplifier Item Content Note unit and therefore requires the user to purchase a Connector RJ-45 separate speaker system with a built-in amplifier.

  • Page 14: Installation

    Part 1 – Introduction Installation Remove the dome cover. Installation of this product does not require the use of special tools. For more information on other devices comprising the overall system, refer to their respective installation manuals. Product color and design may vary depending on the model.

  • Page 15: Installation

    Part 1 – Introduction Insert a SD memory card into the SD memory card Attach the enclosed desiccant in the SD memory slot with the 'micro SD' print facing upward. card slot cover to prevent moisture. Desiccant Push the SD memory card until it disengages from the slot, and then pull it out.

  • Page 16: Closing The Dome Cover

    Part 1 – Introduction Connect external devices, the network cable, and Fasten the screws for the dome cover clockwise the power adapter. using the allen wrench provided with the camera. Make sure to shut the side cable hole using the PT 1/2- inch cable cap for waterproof if the hole is not used.

  • Page 17: Angle Adjustment

    Part 1 – Introduction Angle Adjustment Dimensions The lens can be rotated along three axes. Lens Rotation Horizontal Rotation Vertical Rotation • Lens Rotation Used to adjust the lens' rotation angle. Loosen the Ø 155mm (6.1") rotator screw, and turn the lens rotator clockwise or counterclockwise to adjust the lens' rotation angle by using the lens rotator handle.

  • Page 18: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Alarm Out Power Sensor In Network Camera Monitor Out...

  • Page 19: With Non Directip™ Nvr-Based Layout

    Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 20: Part 3 - Appendix

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below.

  • Page 21: Specifications

    Part 3 - Appendix Specifications These product specifications may change without prior notice. Lens Lens Type Motorized focus and zoom lens: F1.3 Focal Length 3mm - 9mm Viewing Angle H: 99.8° (Wide) ~ 33.5° (Tele) V: 52.2° (Wide) ~ 18.6° (Tele) D: 118.2°...
  • Page 22 Part 3 - Appendix Video Signal Format NTSC or PAL (selectable) Compression Algorithm H.264, M-JPEG (supports 4-stage image compression rate) Compression Resolution 352x240, 704x480, 1280x720, 1920x1080 Bitrate Control H.264 – VBR (up to 12 Mbps) Max. Transmission Rate 30ips @ 1920x1080 + 60ips @ 1280x720 + 30ips @ 352x240 (frames per second) Multi-Stream Primary, Secondary, Tertiary, Quaternary...

  • Page 23: Video Out

    Part 3 - Appendix Connector Video Out*** 2 Pin Jack Audio I/O Terminal Block (mono) Alarm I/O Terminal Block Ethernet Port RJ-45 *** Use these ports for previewing video and not monitoring video. General External Dimensions (Ø x H) 155mm x 111.5mm (6.1" x 4.39") Weight (Main Unit) 0.91kg (2.0lb) Working Temperature...
  • Page 24 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
