INSTRUCTIONS FOR USE
Cooker hood
EN
CBB761SSC
CBB861SSC
CBB862WGC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CBB761SSC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asko CBB761SSC

Summary of Contents for Asko CBB761SSC

  • Page 1 INSTRUCTIONS FOR USE CBB761SSC Cooker hood CBB861SSC CBB862WGC...

  • Page 2: Table Of Contents

    Contents Pictograms used ........Switching on the timer ......... Safety ............Switching on recirculation mode ....Your cooker hood ........Switching off recirculation mode ....Dear customer! ..........Clean Air function ........Description hood ......... Switching the light on and off ...... Description user interface ......

  • Page 3: Pictograms Used

    Pictograms used The following symbols are used throughout the manual, and they have the following meanings: INFORMATION! Information, advice, tip or recommendation WARNING! Warning general danger ELECTRIC SHOCK! Warning danger of electric shock HOT SURFACE! Warning danger of hot surface DANGER OF FIRE! Warning danger of fire...

  • Page 4: Safety

    Safety WARNING! READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! Safe use The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings. Damage caused by incorrect connection, incorrect fitting, or incorrect use is not covered by the warranty. Children shall not play with the appliance.
  • Page 5 Safety WARNING! This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 Safety Follow the instructions in the manual for cleaning or replacing the grease filters and/or carbon filters! DANGER OF FIRE! There is a risk of fire if the instructions for cleaning or replacing grease filters and/or carbon filters are not followed. Through grease deposits in the metal grease filter.

  • Page 7: Your Cooker Hood

    Your cooker hood Dear customer! Welcome to our growing ASKO family! We are proud of our appliances. We hope that this appliance will be an appreciated and dependable aid for many years to come. Please read the operating instructions before use. They include general tips, information about the settings and adjustments you can make, and the best way to take care of your appliance.

  • Page 8: Description Hood

    Your cooker hood Description hood 1. Button Control 2. LED bar 3. Edge extraction panel 4. Grease filter 5. Magnet Description user interface 1. Filter reset button 2. Filter indicator, signals when filters require cleaning 3. Lighting button, switches on/off and dims the lighting 4.

  • Page 9: Operation

    Operation Switching extraction on and off 1. Press the + (plus) button. The cooker hood will switch on at the lowest setting. 2. Press the + (plus) button again for a higher fan setting. Press and hold the + (plus) button for 1 second to select the highest setting (boost).

  • Page 10: Switching On Recirculation Mode

    Operation TIP! This hood is set as an extractor hood on delivery (the air is exhausted to the outside). The hood can also be set to recirculation use (the air is blown back into the room after filtration through grease filters and a combi-filter). With an RMS kit (recirculation modification set), the air will first be cleaned by the grease filters, and then odours will be filtered by the combi-filter.

  • Page 11: Switching The Light On And Off

    Operation Switching the light on and off 1. Shortly press and release the light button. The light switches on at maximum strength. 2. Press and hold the lighting button to set the lighting strength. The lighting changes from maximum to minimum strength and vice versa. 3.

  • Page 12: Wi-Fi Connectivity

    Wi-Fi connectivity ConnectLife-app and Wi-Fi connection This appliance is equipped with a Wi-Fi module that allows the appliance to connect to the internet via your home network and to use it with the ConnectLife-app, installed on a mobile device like a smartphone or tablet.
  • Page 13 Wi-Fi connectivity First steps to set up the Wi-Fi connectivity: 1. Check the “Requirements” as described above. 2. The hood and lights must be switched off. 3. Press the Wi-Fi button for 3 seconds. Speed levels 2 and 3 indicators will light up. The Wi-Fi menu is activated.
  • Page 14 Wi-Fi connectivity Depending on the Wi-Fi state, there are 1 to 3 options available in the menu: The Connection Setup Mode The Pairing Mode Remote control mode If more than 1 option is available then use the + (plus) and - (minus) buttons to toggle between the options.
  • Page 15 Wi-Fi connectivity Remote control mode switch on and off To be able to change function settings remotely, the appliance must be switched on and the ConnectLife-app must be enabled. Speed level 4 indicator and Wi-Fi indicator will lit static. Remote control mode is only available if the Wi-Fi connectivity setup has been performed. Touch the timer key to enable 'Remote control'.
  • Page 16 Wi-Fi connectivity Switching off Wi-Fi: The hood and lights must be switched off. Press the Wi-Fi button for 3 seconds. Speed levels 2 and 3 indicators will light up. The Wi-Fi menu is activated. Press the Wi-Fi button to turn off Wi-Fi. The Wi-Fi indicator will turn off. After 3 seconds it will return to the Wi-Fi menu.
  • Page 17 Wi-Fi connectivity Wi-Fi troubleshooting Symptom Possible cause Solution Wi-Fi icon not shown. Wi-Fi turned off. Switch on Wi-Fi (see 'Switching on Wi-Fi'). Wi-Fi setup failed. Home network issues. Check that your home network signal is strong and internet connection is working.

  • Page 18: Remote Control

    Remote control Description remote control NOTE! The remote control is available as an accessory for this cooker hood and is not included with this appliance. 1. Timer function 2. Increase light intensity 3. Colder light temperature 4. Decrease light intensity 5.

  • Page 19: Switching Extraction On And Off

    Remote control Switching extraction on and off 1. Press and hold the ‘Fan’ key on the remote for 1 second. The cooker hood will switch on at the lowest setting. 2. Press the ‘+’ key again for a higher fan setting. Press and hold the ‘+’ key for 1 second to select the highest setting (boost).

  • Page 20: Switching On Recirculation Mode

    Remote control TIP! The cooker hood can be used in extraction mode or recirculation mode. The air extraction capacity is adapted to the selected mode. The hood will start-up in the default extraction mode. It has to be reset for recirculation mode. With an RMS kit (Recirculation modification set) the air will first be cleaned by the grease filters and then odours will be filtered by the charcoal filter.

  • Page 21: Switching The Light On And Off

    Remote control Switching the light on and off 1. Press and hold the light key for 1 second. The light switches on at maximum strength. 2. Press and hold the ‘increase light’ or ‘decrease light’ key to set the lighting intensity. 3.

  • Page 22: Maintenance

    Maintenance Cleaning WARNING! Important! For all maintenance, first, switch off the mains power to the cooker hood by pulling the plug out of the socket or by turning off the home's master switch. The hood needs to be cleaned regularly, both inside as well as outside (at least as often as the grease filter). Do not use abrasive cleaning products.

  • Page 23: Filter Indication

    Maintenance The filter is now in position again. 4. Press the edge extraction panel firmly in the magnetic seal again (you will hear a click). TIP! The edge extraction panel can be removed for cleaning. Active carbon filters The regenerable active carbon filter must be washed by hand with neutral cleaning products, or in the dishwasher at a maximum temperature of 65 °C (the washing should be done without any plates, dishes, cups, etc.

  • Page 24: Battery Of The Remote

    Maintenance Battery of the remote NOTE! When the batteries are replaced the pairing connection will remain. Replace the batteries in time, as the receiving distance will be shortened if the voltage of the battery is too low. Don’t forget to remove the batteries if you don’t use the remote for a long time. Don’t leave the remote lying upside down on a conductive surface.

  • Page 25: Technical Data

    Technical data EU Product Sheet Data determined according to: Standard EN61591 and Commission Regulations (EU) no. 65/2014 and (EU) no. 66/2014. Model identification CBB761SSC CBB861SSC CBB862WGC Annual Energy Consumption (AEC 20.7 20.7 20.7 hood [kWh/a] Time increase factor (f) Fluid Dynamic Efficiency (FDE 37.6...

  • Page 26: Compliance Information

    Radio equipment type BLE module Operating frequency range 2402 - 2480 MHz Maximum output power 7.63 dBm EIRP average (calculated) Maximum antenna gain 0 dBi Hereby, ASKO declares that the radio equipment type Cooker hood is in compliance with Directive 2014/53/EU.

  • Page 27: Installation

    Installation Safety regulations Faulty parts may only be replaced by original parts. The manufacturer can only guarantee that original parts meet safety requirements. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

  • Page 28: Preparations For Installation

    Installation If the safety instructions and warnings are not followed, the manufacturer cannot be held responsible for any resulting damage. If you decide to discontinue using the appliance because of a fault, we recommend you cut off the cable after removing the plug from the plug socket. Take the appliance to your municipality’s waste disposal site.

  • Page 29: Appliance Dimensions

    Installation Appliance dimensions Built-in...

  • Page 30: Environmental Aspects

    Environmental aspects Tips for energy-efficient cooking with hoods Use a low extractor setting and use the highest setting (boost) only if necessary. A well-ventilated kitchen makes the range hood more efficient. Clean filters regularly and replace filters when needed to keep the filter efficiency high, as a saturated filter cannot perform and leads to longer usage times.

  • Page 31: Your Notes

    Your notes...
  • Page 32 926728 We reserve the right to make changes.
