Separate the side (prop) stand swithc plug.
•
Separate the neutral indicator plug.
•
Detach the left plug holder plate.
•
Remove the injectors.
•
Pull the plugs off the injector lines.
•
Disconnect the brake light switch plug and de-
tach the cable.
•
Detach the breather hose at the air cleaner cas-
ing.
•
Detach the throttle cable at the twistgrip.
•
Remove rear section of frame.
•
Detach the footrest assembly.
•
Remove the starter motor cover.
•
Detach the positive lead from the starter motor.
•
Remove the battery.
•
Unscrew rear battery mount.
•
Raise the battery holder at the rubber mount.
•
Detach the clutch slave cylinder mount and pull
out of the gearbox.
•
Pull out the thrust rod.
•
Detaching the gearbox
23 1 820
23 1 820
•
When removing, pull the gearbox out on guide
pins, BMW No. 23 1 820.
•
Install by following the above work instructions in
the reverse order.
