1Ph Simplex Timed Dose Panel Model: 10-5454, Rev A
Description: Control, Sim/Td/120/208/240V/1Ph/4X/7-15A/Ald
Introduction
The control panel is capable of controlling and monitoring one pump and five sensor inputs. It can be configured for Three Float control
or Four Float Control with an additional Auxiliary Alarm input on Input 5. Pump mode (hand mode, off mode, and auto mode) is controlled
via a button on the inner front door of the control panel. For controlling the pump, the panel is equipped with a cost saving replaceable
power relay board. The control panel can also be configured for demand dose or time dose control. An auxiliary dry contact output is
also included for interfacing to remote alarms or to building automation systems. This panel also features a menu system to enable
field configuration as well as statistics tracking. Finally, the panel can be connected to Vizzy.Site for remote tracking, control, and
configuration.
Before Installation
Before proceeding with the installation or operation of the control panel read all instructions thoroughly, as well as comply with all
Federal, State and Local Codes, Regulations and Practices. The control panel must be installed by qualified personnel familiar with all
applicable local electrical and mechanical codes. Refer to the National Electrical Code (NFPA 70). Failure to properly install, test, and
operate this product can result in personal injury or equipment malfunction. All conduit connected to the panel must be sealed with
conduit sealant to prevent moisture or gases from entering the panel. NEMA 1 enclosures are for indoor use only while NEMA 4X panel
enclosures may be used indoor or outdoor. Refer to panel model name plate on inside of door for enclosure rating.
Note: If options are ordered that affect the number of floats, refer to the panel schematic for complete information.
Safety Guidelines
1. DO NOT USE WITH FLAMMABLE OR EXPLOSIVE FLUIDS SUCH AS GASOLINE, FUEL OIL, KEROSENE, ETC. DO NOT USE IN EXPLOSIVE
ATMOSPHERES. CONTROL PANEL SHOULD ONLY BE USED IN WATER AND WASTEWATER APPLICATIONS THAT ARE NOT RATED
AS A HAZARDOUS LOCATION.
2. DO NOT WORK ON THE CONTROL PANEL WITH LIVE VOLTAGE APPLIED TO THE CONTROL PANEL WITH WET HANDS OR WHEN
STANDING ON A WET SURFACE.
3. DISCONNECT ALL ELECTRICAL SERVICE BEFORE WORKING ON OR HANDLING THE CONTROL PANEL.
4. INCOMING VOLTAGE MUST MATCH THE CONTROL PANEL VOLTAGE. REFER TO THE PANEL SCHEMATIC FOR COMPLETE
INFORMATION.
®
