- Page 1 / Air Line Kit エアーラインキット AL - M1201BL / OPERATION MANUAL 取 扱 説 明 書 日本語：P1 - P7 / English：P9 - P15 OM-K0650 001...
-
Page 2: Cautions For Handling And Operation
Thank you for purchasing the " AL-M1201BL " Air Line Kit for brushless motors and motor / spindles. This Air Line Kit desinged for adjust the air supply flow with oil mist automatic lubrication to the air tool and redcer. The <motor>, <redcer>, <spindle>, <CONTROLLER>... - Page 3 CAUTION Use of dry air ① Using compressed air containing excessive moisture could result in malfunction or failure of the motor and spindle. If excessive moisture or condensation is found in Air Filter Bowl, it will be necessary to install a dryer larger Air Filter on the primary side of the Air Line Kit to prevent and remove excessive moisture.
-
Page 4: Specifications
3 . SPECIFICATIONS Model AL - M1201BL Primary air pressure Less than 1.0MPa Secondary air pressure Less than 0.85MPa Maximum Operation Pressure 1.0MPa Maximum Peak Pressure Less than 1.5MPa Maximum Peak Pressure at Hose Connection Less than 1.0MPa Filtration of the Air Filter 0.3µm Drain Reservoir Capacity 80cm... -
Page 5: Parts Name
4 . PARTS NAME Adjusting Dome ② Regulator ① Air Filter ON / OF Valve Oil Filler Cap Primary Joint Secondary Joint φ6 One-Touch Joint Connector for Air Hose Lubricator Regulator Knob Bowl Oil Reservoir Auto-Drain Valve Alarm Buzzer Adjustment Sound Volume Knob Fig. -
Page 6: Operation
5 . OPERATION 5 - 1 Air Filter The water, dirt and debris are separated from the compressed air. The separated debris is collected in the Bowl. 5 - 2 Automatic Drain Mechanism Upper Oil Limit When collected drain will be " Upper Oil Limit " of the Bowl, draining directly the drain to the Auto-Drain outlet Port by "... - Page 7 （3） Adjustment of oil drip rate (Fig 5) Increase Decrease ① Set the air pressure to the motors recommended maximum air pressure. ② Adjust the oil drip rate to the recommended Adjusting Dome volume which is 1 to 3 drops/min. Counterclockwise : Increase.
-
Page 8: Troubleshooting
（5） Mount the Air Line Kit to the vertical wall. Spacer Because the head of the mounting screw Hexagon Socket Bolt (M8×20L) is sticking out from the Base Plate, Use the (Standard Accessories : 4pcs) Hexagon Socket Bolts and Spacers (Standard Accessories : 4pcs. - Page 9 2022-09-06 CACC0907 0005S...
