Tektronix 12RM05 Instructions Manual

Tektronix 80186 MNEMONICS
ROM PACK
with Option 02
The 80186 Mnemonics ROM Pack configures a 1240 Logic Analyzer
to acquire and disassemble data from an 80186 microprocessor. The
PM202 Personality Module monitors the contents of the queue,
provides fetch prediction, and arranges the address, data, and
_ control lines for use with the setup supplied by the 80186 Mnemonics
77. ROM Pack. (The PM202, which is ordered as Option 02 to the
'e 12RM05, is required for successful use of the 801 86 Mnemenics
ROM Pack.)
NOTE
To use this ROM Pack and the PM202, your 1240 Logic
Analyzer must be equipped with at least three 1240D2
cards and your 80186 must be mounted in an 68-pin
i JEDEC Type A Socket.
Insert this manual at the back of your 1240 Logic Analyzer Opera-
tor''s Manual, or in the 1240 Optional Accessories binder.
C. PLEASE CHECK FOR CHANGE INFORMATION
AT THE REAR OF THIS MANUAL
Product Group 57 FIRST PRINTING FEBRUARY 1984
