Oasis AQUILA P1TPVKY User Manual

EN MAINTENANCE / WARRANTY
Maintenance
CLEANING THE COOLER
Under no circumstances use abrasive cleaning
products or chlorine based cleaners – they will
damage the surface finish of the coolers.
Use mild soap and warm water to clean the panels.
OASIS recommends that you use an anti-bacterial
wipe to clean the water outlet on a weekly basis.
COOLER START UP
When plugging the unit to the electrical socket, make
sure there is ~20cm free space in front of the screen panel.
On power up, the touchless sensors need 2 seconds
to calibrate – if this space is obstructed and an error
occurs, then unplug the unit and reconnect to the
mains power supply.
EMPTYING THE DRIP TRAY
(No auto drain system models)
Lift it up by
about 50mm
before you pull
it forward.
Note : Check with your service provider if self-drain
option has been installed – if you have a self-draining
drip tray then you do not need to remove it for emptying.
WARNING
The warranty and CE/UL certification for this machine are automatically void if any alteration, modification, or combination
with any other machine or device is deemed to be the source of any claim. The CE/UL certification may be void as the
result of any alteration or modification. The manufacturer accepts no liability resulting from any alteration, modification, or
combination with any other machine or device. EXCEPT AS SET FORTH HEREIN, THE MANUFACTURER MAKES
NO OTHER WARRANTY, GUARANTEE, OR AGREEMENT EXPRESSED, IMPLIED OR STATUTORY, INCLUD-
ING ANY IMPLIED WARRANTY OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
4
030099-732
Check the
NORMAL
FULL!!
float Indicator
UNITS WITH HOT TANK
Do not turn on hot tank switch until it is fully filled with
water. Three cycles of hot water dispense (25s each)
are needed to fully fill hot tank.
© 2025 OASIS
OASIS AQUILA
USER GUIDE
Safety / WEEE
Operating
Maintenance
Warranty
OASIS IRELAND OASIS POLAND
Bunree Industrial Est., Ballina, ul.Gutenberga 20,
Co. Mayo, Ireland F26 D5R3 44-164, Gliwice Poland
+ 353 96 71222 + 48 32 332 65 01
www.oasiscoolers.eu | info@oasis.ie
DOWNLOADS
www.oasiscoolers.eu/
downloads
1
