- Page 1 Flintstone Manual Bale collector Meijer Holland bale handling systems Duinkerkenstraat 11 NL-9723 BN Groningen The Netherlands T +31 (0)50 3126448 info@meijerholland.com www.meijerholland.com...
-
Page 3: Table Of Contents
Content 1. Introduction ........................4 2. Technical specifications ..................... 5 3. Safety precautions ......................6 4. The functioning of the bale collector .................. 7 5. Installation and adjustment ....................8 6. Mounting platform to the baler ..................10 7. Maintenance ........................12 8. -
Page 4: Introduction
1. Introduction The Meijer Holland Flintstone bale collector is designed to be attached behind a baler in order to collect two straw or hay bales at a time. The Flintstone is mechanically powered by the force of the big baler. This manual provides an overview of all the aspects that have to be kept in mind, before, during and after the use of the machine. -
Page 5: Technical Specifications
▪ The non-observance of the rules and instructions stated in this manual is to be considered as serious negligence which leads to the extinguishment of any liability on the part of Meijer Holland concerning the resulting consequences. In this case, the risk lies exclusively with the user. -
Page 6: Safety Precautions
3. Safety precautions The following precautions are important to prevent injuries and damages. Read the manual before use. Only experts should (dis)mount the collector to the vehicle. Only experts should operate the collector. Use the collector only for bales. Do not stand on the bale collector or the roller conveyor – this is dangerous! Mount the platform according to the instructions (chapter 6). -
Page 7: The Functioning Of The Bale Collector
4. The functioning of the bale collector The collector can only work if it is correctly mounted behind the baler with the supplied platform. ▪ The first bale slides over the platform and tilts into the collector, pushing down the spring- loaded roller bottom. -
Page 8: Installation And Adjustment
Check if the bale collector is undamaged and in good condition on delivery. Please contact Meijer Holland if you notice any damages or missing parts. Only use the collector only if it is found to be in good order and after this manual has been read. - Page 9 5.2 Adjustment 5.2.1 Spring tailgate Adjust the spring so that the tailgate, after unloading the bales, folds back into the locked position. Too tight adjustment of the spring can cause the valve to close too early when passing the bales. It is also possible that the valve will lock too hard, causing it to not lock properly.
-
Page 10: Mounting Platform To The Baler
6. Mounting platform to the baler Figure 1: after complete assembly 6.1 Parts illustration name item no. number extended platform MH90x61-000 guide bracket - set MH90x07-002 1 left platform 1 right Steering rod - set MH90x07-004 platform mounting bracket - MH90x07-003 2 sets set, complete... - Page 11 6.2 Mounting in steps step 1 step 2 step 3 step 4 bale collector Flintstone – EN...
-
Page 12: Maintenance
7. Maintenance Regular maintenance extends the life span of the collector. Maintenance schedule Before every use Check the bale collector for damages and wear. Replace damaged or worn parts. At least once a week Clean the collector of caked dirt and dust. When using a high-pressure washer, avoid the electrical parts. -
Page 13: Problems And Solutions
The bale collector is composed of several moveable parts. Repair or replace the damaged or worn parts immediately. Spare parts are available at Meijer Holland. ▪ Turn off the baler and the vehicle when you are fixing one of the following problems. -
Page 14: Environment And Disposal
9. Environment and disposal The bale collector is made of coated steel that can be disposed of as scrap. bale collector Flintstone – EN... -
Page 15: Assembly Drawings
10. Assembly drawings top view side view isometric view bale collector Flintstone – EN... -
Page 16: Ce- Declaration Of Conformity
CE- Declaration of conformity We, Meijer Holland bale handling systems Duinkerkenstraat 11 NL-9723 BN GRONINGEN The Netherlands tel. +31 (0)50-312 64 48 +31 (0)50-313 80 18 declare under our sole responsibility that: 1. we are the manufacturer of: MH Flintstone (model MHFS02) 2.
