- Page 1 Meijer KM8 / KM16 Meijer KM12M / KM15M Manual Bale grab Meijer Holland bale handling systems Duinkerkenstraat 11 NL-9723 BN Groningen The Netherlands T +31 (0)50 3126448 info@meijerholland.com www.meijerholland.com...
-
Page 3: Table Of Contents
5. Installation, starting up, adjustment ................... 8 6. Operation and use ......................9 7. Maintenance ........................10 8. Problems and solutions ....................11 9. Environment and disposal ....................12 10. Assembly drawings Meijer KM8 ..................13 CE-Declaration of conformity ....................15 bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 4: Introduction
1. Introduction The Meijer Holland bale grabs of the ‘Meijer KM’ type are designed to be attached to a telescopic handler, front loader, wheel loader or crane (hereinafter referred to as ‘vehicle’) in order to grab and transport straw or hay bales over a short distance. The bale grab is equipped with a hydraulic circuit that is to be connected to the hydraulic system of the vehicle. -
Page 5: Technical Specifications
▪ The non-observance of the rules and instructions stated in this manual is to be considered as serious negligence which leads to the extinguishment of any liability on the part of Meijer Holland concerning the resulting consequences. In this case, the risk lies exclusively with the user. -
Page 6: Safety Precautions
Build the stack of straw and hay bales in a stable way so that it cannot fall over. The driver must be aware of the rules that apply to the lifting and hoisting of heavy loads. bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 7: The Functioning Of The Bale Grab
▪ The clamping of the bales takes place with the help of hooks that are mounted on rotatable shafts which are powered by a hydraulic cylinder. This movement can be seen in the figure below. movement hooks bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 8: Installation, Starting Up, Adjustment
Check if the bale grab is undamaged and in good condition on delivery. Please contact Meijer Holland if you notice any damages. Use the grab only if it is found to be in good order and after this manual has been read. -
Page 9: Operation And Use
5. The vehicle can now be driven away from the bales in reverse. 6. The bale grab is ready to grab and move another series of bales. use KM8 bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 10: Maintenance
Put grease on the grease nipples. At extensive use: after every eight working hours add a bit of grease (0,86 grams per grease nipple). bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 11: Problems And Solutions
Malfunction in the hydraulic system of Consult the manual of the the vehicle. vehicle. The hooks or the shafts on which Look for the blockade and they are attached are blocked. remove it. bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 12: Environment And Disposal
▪ Drain the hydraulic system and let the fluid be disposed by an authorised company. ▪ The rest of the bale grab is made of coated steel and can be disposed of as scrap. bale grab Meijer KM8, KM16, KM12M and KM15M – EN... -
Page 13: Assembly Drawings Meijer Km8
10. Assembly drawings front view KM8 top view KM8 Isometric view KM8 bale grab Meijer KM8, KM16, KM12M and KM15M – EN... - Page 14 KM16 foldable (2x 8 bales next to each other) bale grab Meijer KM8, KM16, KM12M and KM15M – EN...
-
Page 15: Ce-Declaration Of Conformity
3. the machine is designed and constructed according to European standards, including: ▪ EN 349:1993+A1:2008 ▪ EN-ISO 4413:2010 ▪ EN-ISO 12100:2010 The electrics and the control section are the responsibility of the customer. Groningen, 1 July 2016 J.F. Lommerts, director bale grab Meijer KM8, KM16, KM12M and KM15M – EN...
