- Page 1 Limo Hydra Manual Bale collector Meijer Holland bale handling systems Duinkerkenstraat 11 NL-9723 BN Groningen The Netherlands T +31 (0) 50 3 12 6 448 F +31 (0) 50 3 138 01 8 in fo @me i jer ho ll an d. com...
-
Page 3: Table Of Contents
Content 1. Introduction ..........................4 2. Technical specifications ......................5 3. Safety precautions ........................6 4. The functioning of the bale collector ..................7 5. Installation, starting up, adjustment ..................9 6. Operation and use ........................ 11 7. Maintenance ........................14 8. -
Page 4: Introduction
1. Introduction The bale collector Meijer Holland Limo Hydra is designed to be attached behind a baler in order to collect 8 to 15 straw or hay bales. The Limo Hydra is mechanically powered by the tractor. This manual provides an overview of all the aspects that have to be kept in mind, before, during and after the use of the machine. -
Page 5: Technical Specifications
Holland concerning the resulting consequences. In this case, the risk lies exclusively with the user. Meijer Holland is constantly improving her products. Therefore she reserves the right to make any change that is considered necessary. There is no obligation to apply these changes to earlier delivered machines. -
Page 6: Safety Precautions
3. Safety precautions The following precautions are important to prevent injuries and damages. Read the manual before use. Only experts should use the collector. Use the collector only for bales. It is forbidden to stand on the bale collector or on the roller conveyor at any time. It is not permitted to stand any closer than five metres to the bale collector while it is being operated. -
Page 7: The Functioning Of The Bale Collector
4. The functioning of the bale collector See the assembly drawings in chapter 10 for the order of positioning of the bales. 1. The first three bales of the Limo Hydra 8 are pushed sideways by the spiral rollers. For the Limo Hydra 15M this applies to the first four bales. 2. - Page 8 Photo C – tailgate pushed down Limo Hydra 8 Photo D – flap pushed down Limo Hydra 15 The smaller roller will spring back to its idle position. After that, the next set of bales will fill the forward half of the collector. The last bale on the collector will operate the mechanism and consequently the smaller roller will be unlocked.
-
Page 9: Installation, Starting Up, Adjustment
Check if the bale grab is undamaged and in good condition on delivery. Please contact the supplier or Meijer Holland if you notice any damages. Only use the bale collector if it is found to be in good order and after this manual has been read. - Page 10 Photo G — complete assembly Limo Hydra Photo H — rotational movement rollers Bale collector Limo Hydra – EN...
-
Page 11: Operation And Use
6. Operation and use 1. Adjust the bale guides Before the use, the four red bale guides must be adjusted to the correct width of the bales. Adjust the bale guides in such a way that the device can be operated optimally and that the bales are moving smoothly on the machine. - Page 12 Photo K – spring tailgate Photo L – spring smaller roller Bale collector Limo Hydra – EN...
- Page 13 5. After use 1. Place the bale collector with the tractor on a solid and even ground. 2. Disconnect the hydraulic hoses and check them for leakage. 3. Dismount the junction of the tractor/baler from the bale collector and drive the tractor straight away.
-
Page 14: Maintenance
7. Maintenance Regular maintenance extends the life span and prevents injuries, leakage of hydraulic oil and damages. Maintenance schedule Before every use Check the bale collector for damages and wear. Replace damaged or worn parts immediately. Check the hydraulic clutch, hoses and cylinders for leakage, wear and damages. -
Page 15: Problems And Solutions
The bale collector is composed by several moveable parts. Repair or replace damaged or worn parts immediately. Spare parts are available at Meijer Holland or at suppliers. Hydraulic fluid is a poisonous liquid that is harmful to the environment. Never try to shut a leak with your hand. -
Page 16: Environment And Disposal
9. Environment and disposal The bale collector has a hydraulic circuit that contains hydraulic fluid, a poisonous liquid that is harmful to the environment. Regularly check the bale collector for leakage and replace damaged or worn parts immediately. 9.1 Disposal of the bale collector ... -
Page 17: Assembly Drawings
10. Assembly drawings Top/side view Limo Hydra 8 Top/side view Limo Hydra 15 Bale collector Limo Hydra – EN... -
Page 18: Parts
11. Parts Bale collector Limo Hydra – EN... - Page 19 Legend parts onderdeel artikelnummer Tailgate MHLH10-28 roller F MHLH10-16 MH spring Hydra MHVEER04B Tailgate mechanism MHLH10-21 roller D MHLH10-18 roller A MHLH10-12 roller C MHLH10-13 roller B MHLH10-14 Pull bar MHLH10-11 Rotor blade MHLH10-17 Tilting mechanism MHLH10-05 roller E MHLH10-15 Guide plate right front MHLH10-01 Guide plate right back...
-
Page 20: Extra Parts
12. Extra parts Bale collector Limo Hydra – EN... - Page 21 Legend extra parts part art.no. bearing MHLH10-58 flange bearing MHLH10-59 lower link pin MHLH10-64 closing pin MHLH10-68 stand jack MHLH10-20 wheel jack holder MHLH10-25 galvanized spring MHVEER13 hydro motor MHLH10-62 connecting rod MHLH10-27 flow control valve MHLH10-63 chainwheel z17 MHLH10-65 chainwheel z14 MHLH10-53 chainwheel simplex z23...
-
Page 22: Ce-Declaration Of Conformity
CE-Declaration of conformity We, Meijer Holland Bale handling systems Duinkerkenstraat 11 NL-9723 BN GRONINGEN The Netherlands declare under our sole responsibility that: 1. we are the manufacturer of: MH Limo Hydra 8 (model MHLH08) MH Limo Hydra 15M (model MHLH15M) 2.
