Travis Industries DaVinci GreenSmart Electric Cheat Sheet

The DaVinci Electric fireplaces have several features and characteristics that require special attention during
installation and set-up. Refer to the installation manual for full details.
Always use proper lifting techniques when moving heavy objects (bend your knees, not your back).
2. There is a magnet tool packed on top of the
appliance that is used to remove the front trim
before removing the front glass of the appliance.
Simply, attach the magnet to the trim and lift the
trim out of the appliance.
3. Use the 2 suction cup tools provided to remove the front glass panel. With the suction cups gently pressed
against the glass panel, pivot the hinged handle to affix the suction cup to the glass. Repeat with the second
suction cup. Gently move the bottom of the glass towards you until the bottom edge can be lowered into the
channel exposed in the previous step. Angle the top edge of the glass away from the appliance and lift the
glass panel out. Place the glass aside in a safe location for reinstallation.
Page 1 of 3
GreenSmart Electric
Cheat Sheet
1. Remove the shipping bracket to gain access to
front trim and glass.
17602301 - 1/9/2025 Travis Industries, Inc.
