1.3 Technical Data IPM5300

(All technical data are valid at 23 ± 5° C and 45 ±15% humidity)
Common technical data:
Operating Temperature
Storage temperature
Weight
Optical input / output connector
Warm-up time for rated accuracy
Mechanical width
Optical Parameters
Wavelength range
Possible Wavelength range (user calibration)
Insertion loss (excl. Connectors)
Insertion loss (incl. Connectors)
Dynamic range
Sampling Rate
Max. Input Power
PDL
Measurable SOP States
Averaging time Continuous mode
Averaging time Buffered Mode
SOP Accuracy
DOP Accuracy
Rel. Power meas. Accuracy
Abs. Power meas. Accuracy (P
Dynamic Input power range
Parameter Resolution
DOP
SOP angles
s , s , s
1 2 3
Analog monitor output
1
At power 0 ±3 dBm, averaging time >1ms
2
Accuracies referring to the IPM5300 internal reference plane
>-20 dBm)
i
1.3 Technical Data IPM5300
1500 ... 1640 nm
1200 ... 1700 nm
3 S/s ... 1 MS/s (selectable)
full Poincaré Sphere
10 µs ... 300 ms
±0.25 deg. on Poincaré Sphere
45 dB, -30 ... +15 dBm
-2.5 V ... + 2.5 V
+5 ... + 40 ° C
- 40 ... + 70 ° C
560 g
FC / APC
10 min
2 slots
< 0.5 dB
< 1 dB
45 dB
+15 dBm
< 0.05 dB
1 µs ... 300 ms
1)2)
1)
±0.25%
1)
±0.01 dB
±0.3 dB
0.01%
0.01°
0.0001
3
