Fast inline polarimeter

2.2 The Graphics User Interface (GUI)

To start the graphics user interface you have two possibilities:

1. Use the TXP Explorer or

2. Directly start the program: TXP_Polarization_Tools.exe

1) Start the TXP-Explorer and connect to the desired mainframe

system overview of the selected TXP mainframe (all TXP-Explorer details are

explained in the mainframe manual):

Now select the module you want to control (here shown in slot [4]) and launch the

IPM specific operating program by clicking the button 'Use card with standard

module'.

Now the card specific operating software starts (TXP_Polarization_Tools.exe):

/ page 8

IPM5300

Figure 3

The TXP Explorer Window

. You will get a
