USER MANUAL – OPTIMA-33-RT10 5K-20K

USER MANUAL: OPTIMA-33-RT10

400/230V: 10K/15K/20K

3-PHASE INPUT / 3-PHASE OUTPUT

3-PHASE INPUT / 1-PHASE OUTPUT (VIA SETTING)

ONLINE DOBLE CONVERSION UPS

208/120V: 5K/10K/20K

MODELS: (400/230V)

VER. 2405.08

ENGLISH

(208/120V)

Ver 2405.08 (ESP)

Table of Contents

Troubleshooting

Need help?

Do you have a question about the Xmart OPTIMA-33-RT10 5K and is the answer not in the manual?

Questions and answers

Summary of Contents for Integra Xmart OPTIMA-33-RT10 5K

Page 1 USER MANUAL – OPTIMA-33-RT10 5K-20K VER. 2405.08 ENGLISH USER MANUAL: OPTIMA-33-RT10 208/120V: 5K/10K/20K 400/230V: 10K/15K/20K 3-PHASE INPUT / 3-PHASE OUTPUT 3-PHASE INPUT / 1-PHASE OUTPUT (VIA SETTING) ONLINE DOBLE CONVERSION UPS MODELS: (400/230V) (208/120V) Technical information on this manual is property of XMART®. This manual Information cannot be copied or distributed totally or partially without written ▪...
Page 2 USER MANUAL – OPTIMA-33-RT10 5K-20K www.xmart-ups.com Ver 2405.08 (ESP)
Page 3: Table Of Contents
USER MANUAL – OPTIMA-33-RT10 5K-20K TABLE OF CONTENTS 1.- GENERAL SAFETY INSTRUCTIONS 2.- PRODUCT DESCRIPTION & AVAILABLE MODELS 3.- INTERNAL BLOCKS DIAGRAM 4.- PRINCIPLES AND OPERATION MODES 5.- INSTALLATION: SITE CONDITIONS REVISION SITE PLANING UPS INSTALLATION EXTERNAL PROTECTION SELECTION WIRES SELECTION 6.- SINGLE UPS WIRING: TERMINAL BLOCK &...
Page 4: General Safety Instructions
USER MANUAL – OPTIMA-33-RT10 5K-20K 1. GENERAL SAFETY INSTRUCTIONS – SAFETY, QUALITY & PERFORMANCE STANDARDS WARNING: Strictly adhere to all safety warnings and advice. It is required to read and understand this manual. Follow all instructions given in this manual for starting up and operating this product. Only qualified technician must start-up, operate and maintain this product. Keep manuals as a guide for future consults.
Page 5 USER MANUAL – OPTIMA-33-RT10 5K-20K SAFETY STANDARDS / QUALITY AND PERFORMANCE SAFETY - LOW VOLTAGE DIRECTIVE (2006/95/EC) IEC/EN 62040-1 UPS Part 1-1: General & Safety UPS in accessible areas ELECTROMAGNETIC COMPATIBILITY - EMC DIRECTIVE (2004/108/EC) UPS, Part 2, Electromagnetic Compatibility: Radiated & Conducted IEC/EN 62040-2 (Cat 3) Low Freq.
Page 6: Product Description & Available Models
USER MANUAL – OPTIMA-33-RT10 5K-20K 2.- PRODUCT DESCRIPTION & AVAILABLE MODELS UPS DESCRIPTION This is an ONLINE UPS (Uninterruptible Power Supply), with single-phase input and output. Classification according to "Classification of UPS by Performance", (EN-62040-3): V F I (Output dependency): Stands for Voltage and Frequency Independent (from those of the input) unit.
Page 7 USER MANUAL – OPTIMA-33-RT10 5K-20K BATTERIES: CARE AND MAINTENANCE • Only top-quality batteries are used in our equipment. • Batteries, in general (regardless of their technology), are components that lose capacity over time and with use. • The batteries lifespan in our ONLINE UPS is 4 to 5 years, considering environmental temperatures below 25°C and optimal working conditions.
Page 8: Front View - All Models
USER MANUAL – OPTIMA-33-RT10 5K-20K PARTS ID, REAR PANEL & TERMINAL BLOCKS A.-Color Touch Screen 7.- Smart port 8.- Share Current (Note 2) (Note 1) 2.- RS232 9.- Parallel Control Port (Note 2) 3.- USB 10.- Output Grounding Termina 4.- XBAT DC Connection 11.- AC Output Terminal Block 5.- EPO (Emergency Stop) 12.- Bypass Input Terminal Block...
Page 9 USER MANUAL – OPTIMA-33-RT10 5K-20K REAR VIEW – MODELS: - OPTIMA-33-RT10-10K-208-NB - OPTIMA-33-RT10- 15K / 20K -400-NB 2 jumpers on the Terminal Block (between Neutral "N" lines) should come factory installed. If any jumper is missing when unpacking the UPS, the installer must install them. Missing jumper should be in the equipment's packaging. REAR VIEW –...
Page 10: Internal Blocks Diagram
USER MANUAL – OPTIMA-33-RT10 5K-20K 3.- INTERNAL BLOCKS DIAGRAM: OPTIMA-33-RT10 www.xmart-ups.com Ver 2405.08...
Page 11: Principles And Operation Modes
USER MANUAL – OPTIMA-33-RT10 5K-20K 4.- PRINCIPLES AND OPERATION MODES This is an ONLINE Double Conversion UPS, and it is designed to deliver clean, seamless, and highest-quality power, protecting your computer equipment and your valuable information. Waveform delivered by this UPS is pure sinewave, just like the main electrical service. Depending on the state of the incoming power service and its configuration, the UPS can assume different operation modes as described in this section.
Page 12 USER MANUAL – OPTIMA-33-RT10 5K-20K OPERATION MODES ONLINE Mode (Also Known as NORMAL Mode o AC Mode) If AC input is within the acceptable configured range and UPS is started through the energizing and power-on procedure, it will enter ONLINE mode.
Page 13 USER MANUAL – OPTIMA-33-RT10 5K-20K SCREENS ACCORDING TO OPERATION MODE The UPS will alternately display different screens with the following information: OPERATION MODES With UPS properly installed and powered, its screen lights up and indicates that it is performing Description self-diagnosis for a brief period until it adopts its valid operating mode.
Page 14: Line Mode
USER MANUAL – OPTIMA-33-RT10 5K-20K When BYPASS mode is disabled, and conditions to go to BYPASS mode occur, UPS is forced to Description adopt STANDBY mode, which involves turning off outputs and waiting to return to ONLINE mode. STANDBY (Powered, bypass disabled &...
Page 15: Battery Mode
USER MANUAL – OPTIMA-33-RT10 5K-20K When Frequency Converter mode is active, inverter will generate a constant frequency of 50Hz or Description 60Hz (depending on the configuration). In this mode, BYPASS mode is disabled. CVCF (FREQUENCY CONVERSION) Screen When UPS is in ONLINE mode and input goes out of the acceptable range, UPS automatically switches Description to BATTERY mode.
Page 16 USER MANUAL – OPTIMA-33-RT10 5K-20K If a non-critical abnormal condition occurs that allows the UPS to continue operating in ONLINE mode, the UPS will display the code and description of the problem intermittently on the screen and emit an intermittent audible signal. The Alarm table lists the codes and their meanings. These situations are Description recorded in the UPS's Data Log.
Page 17: Installation: Site Conditions Revision
USER MANUAL – OPTIMA-33-RT10 5K-20K 5.- INSTALLATION: SITE CONDITIONS REVISION SAFETY INSTRUCTIONS WARNING: Before reading this section, you must read and understand very well section 1 of this manual: “GENERAL SAFETY INSTRUCTIONS”. WARNINGS, RECOMMENDATIONS AND LIABILITY LIMITATION SCOPE AND LIABILITY LIMITATION: Site preparation, wiring and all protection devices must be supplied by end user, and it will not be responsibility neither the UPS distributor nor the UPS technician in charge of the start-up, unless explicitly determined in the contracted scope.
Page 18: Site Inspection
USER MANUAL – OPTIMA-33-RT10 5K-20K SITE INSPECTION AND INSTALLATION CONDITIONS REGULATIONS AND LEGAL DIRECTIVES It is necessary to check that installation site, wiring and power protection in the installation supplied by end user, fulfill technical parameters required by UPS. A particular installation might accomplish with UPS requirements but not with local directives and regulations. The end user and/or electrical contractor will be responsible of watching for complying with electrical regulations and normative during electrical installation managed by end user.
Page 19: Ups Installation
USER MANUAL – OPTIMA-33-RT10 5K-20K UPS INSTALLATION UNPACKING AND HANDLING This equipment comes packed on a pallet and is protected with wood and cardboards. Cut the straps and carefully remove the packaging. Unpack the equipment according to the following figure. We suggest using sufficient personnel to handle the weight of the equipment.
Page 20: Tower Mounting
USER MANUAL – OPTIMA-33-RT10 5K-20K TOWER MOUNTING This UPS can also be installed in a tower format using the bases that come included with the equipment. Follow the instructions shown below. TOWER MOUNTING FOR UPS AND BATTERIES: Assemble the plastic supports included with the equipment so that they create the required width for the UPS and Battery modules. Place the supports on a completely flat surface that can support the weight of the equipment.
Page 21: Electrical Requirements
USER MANUAL – OPTIMA-33-RT10 5K-20K ELECTRICAL REQUIREMENTS ALL power lines (input and output) of this UPS must be protected by protection devices (Breaker) against overcurrent and earth-leakage. With the capacity and appropriate technology to effectively fulfill its function. Moreover, the site must offer an appropriate EARTHING system. This UPS must be connected to appropriate electrical service according to selected model.
Page 22 USER MANUAL – OPTIMA-33-RT10 5K-20K CIRCUIT BREAKERS AND WIRES SELECTION External circuit breakers, switches, and wire gauges must be able to handle currents indicated in the table shown below. Suggested values have been selected to ensure proper operation. NOTE: Each country or region may have local regulations more demanding than the values suggested in this manual. In those cases, the requirements of the local regulations must be followed.
Page 23: Single Ups Wiring: Terminal Block & External Batteries
USER MANUAL – OPTIMA-33-RT10 5K-20K 6.- SINGLE UPS WIRING: TERMINAL BLOCK & EXTERNAL BATTERIES Connections must be made on the terminal block located on the UPS rear panel. This section provides all the necessary information to make the AC and DC connections in UPS and batteries installation. AC LINES CONNECTION * Make sure the UPS is Off before starting the installation.
Page 24 USER MANUAL – OPTIMA-33-RT10 5K-20K AC CONECTION – MODEL OPTIMA-33-RT10 – 10K -208-NB www.xmart-ups.com Ver 2405.08...
Page 25 USER MANUAL – OPTIMA-33-RT10 5K-20K AC CONECTION – MODEL OPTIMA-33-RT10 – 20K-208-NB www.xmart-ups.com Ver 2405.08...
Page 26 USER MANUAL – OPTIMA-33-RT10 5K-20K AC CONECTION – MODEL OPTIMA-33-RT10 – 10K-400-NB www.xmart-ups.com Ver 2405.08...
Page 27: Important Notes
USER MANUAL – OPTIMA-33-RT10 5K-20K AC CONECTION – MODEL OPTIMA-33-RT10 – 15K / 20K -400-NB 2-Pole Jumper, included with UPS IMPORTANT NOTES: For systems with separate inputs (main and secondary/bypass), the jumpers that come factory-connected between UPS inputs (Main AC and Bypass) must be disconnected. If UPS is to be powered by a single energy source (Most common case), jumpers should be kept in place and electrical service connected to the MAIN INPUT terminals.
Page 28: External Battery Connection
USER MANUAL – OPTIMA-33-RT10 5K-20K EXTERNAL BATTERY CONNECTION OPTIMA-33-RT10 UPS have their own DC battery voltage. To connect external battery packs, it is essential to respect the DC voltage of the UPS model used and to use the original XMART cables. Battery Modules have 3 connection points to the UPS: 1.
Page 29 USER MANUAL – OPTIMA-33-RT10 5K-20K 4. Using the cable supplied with the equipment, connect the UPS to the first XBAT. The minimum XBAT array depends on the UPS model. Refer to the connection diagrams on the following pages for reference. 5.
Page 30: Optima-33-Rt10-05K-208
USER MANUAL – OPTIMA-33-RT10 5K-20K EXTERNAL BATERY CONECTION – 208/120Vac Models OPTIMA-33-RT10-05K-208 www.xmart-ups.com Ver 2405.08...
Page 31: Optima-33-Rt10-10K-208
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-10K-208 www.xmart-ups.com Ver 2405.08...
Page 32: Optima-33-Rt10-20K-208
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-20K-208 www.xmart-ups.com Ver 2405.08...
Page 33: Optima-33-Rt10-10K-400
USER MANUAL – OPTIMA-33-RT10 5K-20K EXTERNAL BATERY CONECTION – 400/230Vac Models OPTIMA-33-RT10-10K-400 www.xmart-ups.com Ver 2405.08...
Page 34: Optima-33-Rt10-15K-400
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-15K-400 www.xmart-ups.com Ver 2405.08...
Page 35: Optima-33-Rt10-20K-400
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-20K-400 www.xmart-ups.com Ver 2405.08...
Page 36: Parallel Ups Wiring
USER MANUAL – OPTIMA-33-RT10 5K-20K 7.- PARALLEL UPS WIRING GENERAL INFORMATION Up to 3 units can be installed for parallel operation. This section describes connections for parallel systems. ▪ UPS operating in parallel must be configured and started up as explained in this manual. ▪...
Page 37 USER MANUAL – OPTIMA-33-RT10 5K-20K AC LINES: CONNECTION PROCEDURES * Make sure the UPS is Off before starting the installation. * Remember to check all wires to be connected are not powered (including external batteries). TERMINAL BLOCK PREPARATION Remove safety plate that covers terminal block as described in the section on individual UPS connections in this manual (section 6). Each line must be protected by a circuit breaker.
Page 38 USER MANUAL – OPTIMA-33-RT10 5K-20K 2 PARALLEL UPS, THREE-PHASE INPUT & OUTPUT NOTES: - To connect 3 or 4 UPS in parallel, same connection philosophy as shown with 2 UPS units must be followed. www.xmart-ups.com Ver 2405.08...
Page 39 USER MANUAL – OPTIMA-33-RT10 5K-20K 2 PARALLEL UPS, THREE-PHASE INPUT, SINGLE-PHASE OUTPUT NOTES: - To connect 3 or 4 UPS in parallel, same connection philosophy as shown with 2 UPS units must be followed. www.xmart-ups.com Ver 2405.08...
Page 40 USER MANUAL – OPTIMA-33-RT10 5K-20K 2 PARALLEL UPS, THREE-PHASE INPUT & OUTPUT NOTES: - To connect 3 or 4 UPS in parallel, same connection philosophy as shown with 2 UPS units must be followed. This model does not support single-phase output configuration. www.xmart-ups.com Ver 2405.08...
Page 41 USER MANUAL – OPTIMA-33-RT10 5K-20K PARALLEL UPS: CONTROL CABLES Connection diagram for Control Cables for 2, 3, and 4 UPS. Connector are located on UPS rear panel. 2 UPS 3 UPS www.xmart-ups.com Ver 2405.08...
Page 42 USER MANUAL – OPTIMA-33-RT10 5K-20K 4 UPS PARALLEL UPS: XBAT CONECTION When installing OPTIMA-33-RT10 units in parallel, special attention must be paid to the connection of the XBAT, which refers to the external batteries. If 2 OPTIMA-33-RT10 units are installed, they can either share the XBAT or use them separately, without needing any special configuration. If more than 2 OPTIMA-33-RT10 units are installed, it is not possible to share the XBAT, as shown in connection diagrams shown later on this manual.
Page 43: Optima-33-Rt10-05K-208
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-05K-208 – 2 UPS PARALLEL SYSTEM WTH SHARED BATTERIES www.xmart-ups.com Ver 2405.08...
Page 44: Optima-33-Rt10-10K-208
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-10K-208 – 2 UPS PARALLEL SYSTEM WTH SHARED BATTERIES www.xmart-ups.com Ver 2405.08...
Page 45: Optima-33-Rt10-20K-208
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-20K-208 – 2 UPS PARALLEL SYSTEM WTH SHARED BATTERIES www.xmart-ups.com Ver 2405.08...
Page 46: Optima-33-Rt10-10K-400
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-10K-400 – 2 UPS PARALLEL SYSTEM WTH SHARED BATTERIES www.xmart-ups.com Ver 2405.08...
Page 47: Optima-33-Rt10-15K-400
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-15K-400 – 2 UPS PARALLEL SYSTEM WTH SHARED BATTERIES www.xmart-ups.com Ver 2405.08...
Page 48: Optima-33-Rt10-20K-400
USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10-20K-400 – 2 UPS PARALLEL SYSTEM WTH SHARED BATTERIES www.xmart-ups.com Ver 2405.08...
Page 49: Operation Interface
USER MANUAL – OPTIMA-33-RT10 5K-20K 8.- OPERATION INTERFACE FRONTAL PANEL: COLOR TOUCH SCREEN Previous image shows the operation interface of the OPTIMA 33-T10 family, an efficient 3.5-inch color touch screen with a variety of relevant UPS information, divided into Operational Zones, identified as A, B, C, D, and E, Pressing the "SETTING"...
Page 50: Battery Icon
USER MANUAL – OPTIMA-33-RT10 5K-20K OPERATIONAL ICONS Rectifier (PFC) Inverter Electronic Internal Bypass BATTERY ICON: Battery Icon changes color according to Charge Capacity, as well as if Battery is either Charging or Discharging as next table explains: Battery Capacity when are being: Icon Color Charging...
Page 51: Ups Operation & Configuration
USER MANUAL – OPTIMA-33-RT10 5K-20K 9.- UPS OPERATION & CONFIGURATION This UPS family features a versatile and powerful touchscreen with icons to provide access to various UPS configuration and operation menus, as explained in previous section. The UPS configuration and operation menu is structured as shown in the following diagram: Below, the different operations that can be performed with this UPS, including configuration procedures.
Page 52: Control Menu
USER MANUAL – OPTIMA-33-RT10 5K-20K After a few seconds, the UPS should go to a state as shown on the right, indicating that everything is correct and waiting to be powered on. Touching the icon , you will access the following screen as shown below.
Page 53: Battery Test
USER MANUAL – OPTIMA-33-RT10 5K-20K ON/OFF UPS If UPS is Off: Confirmation Request (On UPS?) YES: Power on UPS and return to main screen NO: Cancels and returns to the menu screen. Returns to previous screen. If UPS is On: Confirmation Request (Off UPS?) YES: Power off UPS and return to main screen NO: Cancels and returns to the menu screen.
Page 54 USER MANUAL – OPTIMA-33-RT10 5K-20K MUTE ALL If alarms are not Muted: Confirmation Request (Mute All?) YES: Mutes alarms. Icon will be shown in top left corner of the screen. NO: Cancels and returns to the menu screen. Returns to previous screen. If alarms are Muted: Confirmation Request (Cancel Mute All?) YES: Unmutes alarms.
Page 55: Measurement Menu
USER MANUAL – OPTIMA-33-RT10 5K-20K EXIT PARALLEL (See Safety Note) If UPS is working in a parallel system: Confirmation Request (Exit Parallel?) YES: Removes UPS from Parallel System, turns off output. UPS goes to STANDBY Mode. NO: Cancels and returns to the menu screen. Returns to previous screen.
Page 56 USER MANUAL – OPTIMA-33-RT10 5K-20K MEASUREMENT – PAGE 2 / 10 DESCRIPTION OF LISTED VALUES: INVERTER VOL: Real-time value of Inverter Voltage (L1, L2, & L3), Phase to Phase voltage (L1-L2: L12, L1-L3: L13. & L2-L3: L23) and its Frequency. OUTPUT VOL: Real-time voltages of Output phases (L1, L2, &...
Page 57 USER MANUAL – OPTIMA-33-RT10 5K-20K MEASUREMENT – PAGE 5 / 10 DESCRIPTION OF LISTED VALUES: OUTPUT W: Output power in Watts on phases L1, L2, and L3. OUTPUT W (%): Percentage output power in Watts on phases L1, L2, and MEASUREMENT –...
Page 58 USER MANUAL – OPTIMA-33-RT10 5K-20K MEASUREMENT – PAGE 8 / 10 DESCRIPTION OF LISTED VALUES: OUTPUT CURR: Real-time current in output phases L1, L2, and L3. OUTPUT PF: Power factor connected to the UPS output. MEASUREMENT – PAGE 9 / 10 DESCRIPTION OF LISTED VALUES: BUS P VOL: Voltage on “P”...
Page 59: Settings Menu
USER MANUAL – OPTIMA-33-RT10 5K-20K SETTINGS MENU: You can access this menu by tapping the icon and tapping the icon takes you back to the main screen from any screen. As this page includes several screens, icons can be used to scroll among them. Icon returns to previous screen.
Page 60 USER MANUAL – OPTIMA-33-RT10 5K-20K SCREEN: SETTING → GENERAL – PAGE 2 / 2 GENERAL MENU PARAMETERS – PAGE 2 / 2: BUZZER: When you press this button, authorization for the operation will be requested: YES or NO. - YES: Activates the UPS's buzzer to indicate that it has entered an alarm state. - NO: Deactivates the UPS's buzzer, and it will not sound if it enters an alarm state.
Page 61 USER MANUAL – OPTIMA-33-RT10 5K-20K If password 0000 is entered: Access to SETTING→ADVANCE→USER Menu Returns to previous screen If wrong password is entered: Notification message (Password Error!!), password must be entered again. Returns to previous screen SETTING → ADVANCE→USER Remember that touching icon returns to Home Screen, from any screen.
Page 62 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→USER → ELECTRIC ACCESS: PAGE 1 / 3 ELECTRIC PARAMETERS IN THIS MENU: OUTPUT VOL: Sets UPS nominal voltage. Available options: - 400/230V Models: 208V, 220V, 230V, 240V - 208/120V Models: 120V, 127V OUTPUT FRE: Sets UPS nominal frequency.
Page 63 USER MANUAL – OPTIMA-33-RT10 5K-20K SCREEN: SETTING → ADVANCE→USER → ELECTRIC – PAGE 2 / 3 PARAMETERS IN THIS MENU: Bypass UPS off: Bypass Mode When UPS Is Turned Off. This setting only applies when the “Bypass forbid” parameter is disabled. - Enable: Choosing this option activates Bypass Mode when the UPS is turned off.
Page 64 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→USER → BATTERY ACCESS: PAGE 1 / 1 BATTERY PARAMETERS IN THIS MENU: BATT Warn VOLT: Batteries voltages that trigger alarms. - HIGH: High battery voltage alarm value. Available range: 14.0V to 15.0V. Factory setting: 14.4V - LOW: Low battery voltage alarm value.
Page 65 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→SERVICE This menu is reserved for special maintenance tasks because configuration errors can cause damage to the UPS, so access to this menu is restricted. SCREEN: SETTING → ADVANCE From this screen, you can access the two levels of ADVANCE menus, depending on the entered key. Below is the description of access to ADVANCE→SERVICE menu: The key for this level is reserved for special maintenance tasks and is not public domain.
Page 66 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→SERVICE Remember icon takes you back to the main screen from any other screen. Since this menu contains multiple screens, you can use icons (where available) to scroll between them. Icon returns to previous screen. In this menu, there are 9 sub-menus as shown in the following image: SCREEN: SETTING →...
Page 67 USER MANUAL – OPTIMA-33-RT10 5K-20K SCREEN: SETTING → ADVANCE→SERVICE → SYS PARAMETERS – PAGE 2 / 3 PARAMETERS IN THIS MENU: BATT Number: Number of batteries connected in series on the positive or negative side of the battery bank. - 400/230V Model: Range:16 to 20. Factory setting: 20. Except 10K Model, which has same configuration as 208/120V UPS, see next line. - 208/120V Models: Range:8 to 10.
Page 68 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→ SERVICE → VOLTAGE CALIBRATION ACCESS: PAGE 1 / 6 VOLT CALI Bus VOL: Voltage calibration of the two lines of internal UPS bus (P and N). Setting procedure: - Tap on the percentage of the value to be adjusted, and setting icon will appear as seen on the right. - Up key increases the value by 0.1%, and down key decreases it by 0.1%.
Page 69 USER MANUAL – OPTIMA-33-RT10 5K-20K SCREEN: SETTING → ADVANCE→SERVICE → VOLT CALI – PAGE 3 / 6 Line VOL: Voltage calibration of input phases (L1, L2, & L3). Setting procedure: - Tap on the percentage of the value to be adjusted, and setting icon will appear as seen on the right. - Up key increases the value by 0.1%, and down key decreases it by 0.1%.
Page 70 USER MANUAL – OPTIMA-33-RT10 5K-20K Inverter VOL: Voltage calibration of Inverter phases (L1, L2, & L3). Setting procedure: - Tap on the percentage of the value to be adjusted, and setting icon will appear as seen on the right. - Up key increases the value by 0.1%, and down key decreases it by 0.1%. - When desired value is reached, tap the "OK"...
Page 71 USER MANUAL – OPTIMA-33-RT10 5K-20K mode will be automatically disabled. However, each time you turn on the UPS, there will be a 2-second transient period during which the UPS will operate in bypass mode, passing power from input to output. - If the UPS triggers input circuit breaker when being powered, UPS might be configured to operate at a different frequency than the system it has been connected to.
Page 72 USER MANUAL – OPTIMA-33-RT10 5K-20K ECO mode: - Enable: Habilita el Modo ECO. - Disable: Inhabilita el Modo ECO. This is the factory default value. ECO VOL Range: Sets valid voltage range for Bypass ECO Mode. - Low Limit: From -5V up to -11V below nominal voltage. Factory setting: -5V below nominal voltage. - High Limit: From +5V up to +11V over nominal voltage.
Page 73 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→ SERVICE → BATTERY ACCESS: PAGE 1 / 2 BATTERY PARAMETERS IN THIS MENU: BATT Warning Volt: Batteries voltages that trigger alarms. - HIGH: High battery voltage alarm value. Available range: 14.0V to 15.0V. Factory setting: 14.4V - LOW: Low battery voltage alarm value.
Page 74 USER MANUAL – OPTIMA-33-RT10 5K-20K CONFIGURACION → ADVANCE→ SERVICE → INITIAL ACCESS: PAGE 1 / 2 INITIAL Initialization Menu. From here, many UPS parameters can be reset to their factory values, as well as data from the log can be deleted. PARAMETERS IN THIS MENU: DATA LOG: Deletes UPS event log.
Page 75 USER MANUAL – OPTIMA-33-RT10 5K-20K CALI: Restores callibration parameters of the UPS to factory values. Confirmation asked: Initial CALI? YES: Restores initial UPS calibration parameters, from factory. NO: Cancels and returns to previous screen. Cancels and returns to previous screen EEPROM: Deletes UPS EEPROM memory content.
Page 76 USER MANUAL – OPTIMA-33-RT10 5K-20K TOUCH CALI: Recalibrates UPS Touch Screen. Tapping the button TOUCH CALI deletes the Touch Screen calibration, to start a new calibration. Returns to previous screen After selecting calibration, UPS will display an empty screen as shown on the right.
Page 77 USER MANUAL – OPTIMA-33-RT10 5K-20K SETTING → ADVANCE→SERVICE → UPS SELF TEST ACCESS: PAGE 1 / 1 SELF TEST UPS Self-test function, only to be performed by highly qualified personnel. This function only Works for parameter UPS TYPE is configured to HV. If parameter UPS TYPE is configured as LV before running a UPS Self-Test the following procedure must be done: - Disconnect the UPS from all system loads and power.
Page 78 USER MANUAL – OPTIMA-33-RT10 5K-20K - Disable: This option enables Auto Restart. Shutdown Delay: UPS shuts down after the number of minutes entered in this field. Countdown starts upon confirming the command. Restore Delay: After the shutdown from the previous command, UPS will restart after the number of minutes entered in this field. SCREEN: SETTING→...
Page 79 USER MANUAL – OPTIMA-33-RT10 5K-20K INFORMATION: You can access this menu by tapping the icon and tapping the icon takes you back to the main screen from any other screen. As this page includes 2 screens, icons can be used to scroll among them. Icon returns to previous screen.
Page 80 USER MANUAL – OPTIMA-33-RT10 5K-20K SCREEN: INFORMACION – RATED – PAGE 2 / 2 DESCRIPTION OF LISTED VALUES Bypass UPS Off: UPS Bypass Function status when turning off the UPS. Auto Restart: Auto Restart Function status. ECO Mode: ECO Function status. INFO →...
Page 81 USER MANUAL – OPTIMA-33-RT10 5K-20K DESCRIPTION OF LISTED VALUES ECO VOL Range: Valid voltage range for ECO Mode. ECO FRE Range: Valid frequency range for ECO Mode. BATT Work Time: Maximum backup time (Minutes) in Battery Mode, no matter the battery array connected to the unit. This function is disabled at factory, so backup time is defined by used battery bank.
Page 82 USER MANUAL – OPTIMA-33-RT10 5K-20K DATA LOG: You can access this menu by tapping the icon and tapping the icon takes you back to the main screen from any other screen. As this page may include more than 1 screen, icons can be used to scroll among them.
Page 83: Important Notes
USER MANUAL – OPTIMA-33-RT10 5K-20K 10.- PUESTA EN MARCHA: UPS INDIVIDUAL VERIFICACION PREVIA A LA PUESTA EN MARCHA 1- Make sure all wires are TIGHTLY connected to terminal blocks. Any loose connection will cause UPS overheating, failures, and damage. 2- Make sure all instructions of installation (5) and wiring (6) sections have been correctly performed. Check wiring and breakers are correct.
Page 84 USER MANUAL – OPTIMA-33-RT10 5K-20K POWER OFF PROCEDURE – SINGLE UPS ONLINE MODE For UPS power-off: - Touch SETTING icon / Touch CONTROL icon / Touch ON/OFF UPS command / Confirmation Question “OFF UPS?”, Touch “YES” At this time, if allowed, UPS will enter Bypass Mode, powering the output with the Bypass input, so the output will remain energized. It is important to always keep this in mind.
Page 85 USER MANUAL – OPTIMA-33-RT10 5K-20K If battery voltage falls under low voltage alarm threshold, the alarm will sound every second, to remind the user that batteries are in critical state and the UPS's automatic shutdown is imminent. At this time, it is recommended to turn off non-critical equipment to extend battery availability.
Page 86: Startup: Parallel Ups
USER MANUAL – OPTIMA-33-RT10 5K-20K 11.- STARTUP: PARALLEL UPS INSPECTION BEFORE STARTUP OUTPUT VOLTAGES REVISION When multiple UPS operate in parallel, their outputs are connected to each other, and each UPS provides a proportional share of the total system power. In this type of system, it is VERY IMPORTANT that voltage supplied by the inverters of all UPS are similar. Voltages should not differ by more than 1.0 Volt AC.
Page 87 USER MANUAL – OPTIMA-33-RT10 5K-20K ESSENTIAL REQUIREMENTS FOR PARALLEL CONNECTION WARNING: If all requirements listed below are not met, a successful startup of the parallel UPS system cannot be carried out. Maximum number of units in parallel is 4. Do not try with more than 4 units. All UPS must be of the same model and must have the same firmware version.
Page 88: Startup Procedure. Parallel Ups
USER MANUAL – OPTIMA-33-RT10 5K-20K STARTUP PROCEDURE. PARALLEL UPS WARNING: If all the requirements listed below are not met, a successful startup of the parallel UPS system cannot be carried out. Make sure all equipment connected to parallel UPS system are off. Set ALL Battery Bank breaker to ON.
Page 89 USER MANUAL – OPTIMA-33-RT10 5K-20K COLD START POWER ON PROCEDURE – PARALLEL UPS IN BATTERY MODE This procedure allows powering up a Parallel System, without AC Power, to use it as a Power Generator. The startup procedure is as follows: 1.
Page 90: Operation: Parallel Ups
USER MANUAL – OPTIMA-33-RT10 5K-20K 12.- OPERATION: PARALLEL UPS Operating modes of UPS connected in parallel are essentially the same as those of single operating UPS. However, it's important to note that in a parallel system, ALL UPS must operate in the same mode simultaneously. Parallel connection does not allow any UPS to operate in a different mode from the rest UPS in the system.
Page 91 USER MANUAL – OPTIMA-33-RT10 5K-20K the UPS in the system. At this point, the UPS to be serviced can be removed. Close (set to ON) the external AC input circuit breaker of the other UPS, and the system will switch to Bypass Mode. Move the external maintenance switch of all units from "BYPASS"...
Page 92: Errors, Alarms & Troubleshooting
USER MANUAL – OPTIMA-33-RT10 5K-20K 13.- ERRORS, ALARMS & TROUBLESHOOTING ERROR / FAILURE CODES ON SCREEN If a malfunction or failure occurs in the UPS, an error code and description will be displayed on the UPS screen, which will help identify the issue that needs to be addressed by technical support.
Page 93 USER MANUAL – OPTIMA-33-RT10 5K-20K WARNING CODES ON SCREEN WARNING WARNING WARNING DESCRIPTION WARNING DESCRIPTION CODE CODE Battery not connected In parallel systems: Bypass situation different Input Neutral loss Locked in bypass after overload 3 times in 30min Input Phase Abnormal Converter current unbalance Bypass phase abnormal Cover of maintenance switch is open...
Page 94: Troubleshooting: Solving Problems
USER MANUAL – OPTIMA-33-RT10 5K-20K TROUBLESHOOTING: SOLVING PROBLEMS SITUATION PROBABLE CAUSE ACTION Screen loses the input voltage indication. AC input UPS AC input cable is not properly connected Check UPS AC Input wiring and correct if necessary. failure alarm is activated (1 beep/4 s). However, the main power supply is normal UPS AC input cable is connected to UPS Check UPS AC Input wiring and correct if necessary.
Page 95: Maintenance Bypass Mode (Mbs)
USER MANUAL – OPTIMA-33-RT10 5K-20K 14.- MAINTENANCE BYPASS MODE (MBS) STARTING MAINTENANCE BYPASS MODE (REQUIRES EXTERNAL MAINTENANCE SWITCH): If UPS setting allows BYPASS mode, proceed to power-off UPS using the procedure explained in section 9. UPS OPERATION & CONFIGURATION. Shutdown makes UPS to go to internal STATIC-BYPASS Mode. UPS output will connect to Bypass input through static bypass line. Check internal Block Diagram in this manual.
Page 96: Emergency Power Off
USER MANUAL – OPTIMA-33-RT10 5K-20K 15.- EMERGENCY POWER OFF This UPS counts on a 2 input terminals port as EPO (Emergency Power Off) input located in UPS rear panel, refer to “PARTS ID, REAR PANEL & TERMINAL BLOCKS” section. These terminals are connected in factory (Closed Contact) to avoid the emergency stop status. For connecting an Emergency Stop Switch to UPS EPO port (C2), remove the original jumper and connect an appropriate switch (Normally Closed Contact).
Page 97: Communication Options
USER MANUAL – OPTIMA-33-RT10 5K-20K 16.- COMMUNICATION OPTIONS USB PORT: For communicating with a PC using the XMART Viewpower software. Software is available on CD and on our website: www.xmart-ups.com. RS-232 PORT: Serial communication port that allows communicating with a PC using the XMART Viewpower software. Software is available on CD and on our website: www.xmart-ups.com.
Page 98 USER MANUAL – OPTIMA-33-RT10 5K-20K 17. TECHNICAL SPECIFICATIONS – 400/230V MODELS OPTIMA-33-RT10 (400/230V) Page 1 of 2 10K-400-NB 15K-400-NB 20K-400-NB Capacity / Capacidad (VA) 10KVA/10KW 15KVA/15KW 20KVA/20KW Parallel Units / Unidades en Paralelo Installation / Instalación Rack & Tower / Rack y Torre Input-Output / Entrada-Salida 3Ph-3Ph ( 3ph-1ph Configurable ) INPUT / ENTRADA...
Page 99 USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10 (400/230V) Page 2 of 2 10K-400-NB 15K-400-NB 20K-400-NB BATTERIES / BATERIAS VRLA Sealed & Free maintenance / Sellada de libre mantenimiento VRLA (12V-9AH) Battery Type / Tipo de Baterías Batteries location / Ubicación de las Baterías External (XBAT) / Externas (XBAT) Battery Voltage / Voltaje de Baterías +/- 120 Vdc...
Page 100: Technical Specifications
USER MANUAL – OPTIMA-33-RT10 5K-20K TECHNICAL SPECIFICATIONS – 208/120V MODELS OPTIMA-33-RT10 (208/120V) Page 1 of 2 5K-208-NB 10K-208-NB 20K-208-NB Capacity / Capacidad (VA) 5KVA / 5KW 10KVA / 10KW 20KVA / 20KW Parallel Units / Unidades en Paralelo Installation / Instalación Rack &...
Page 101 USER MANUAL – OPTIMA-33-RT10 5K-20K OPTIMA-33-RT10 (208/120V) Page 2 of 2 5K-208-NB 10K-208-NB 20K-208-NB BATTERIES / BATERIAS Battery Type / Tipo de Baterías VRLA Sealed & Free maintenance / Sellada de libre mantenimiento VRLA (12V-9AH) External (XBAT) / Externas (XBAT) Batteries location / Ubicación de las Baterías Battery Voltage / Voltaje de Baterías +/- 120 Vdc...
Page 102: Support And Warranty
USER MANUAL – OPTIMA-33-RT10 5K-20K 18.- SUPPORT & WARRANTY Support: If a failure or problem is detected please check troubleshooting section in user manual. If problem cannot be solved, please contact authorized service center or authorized dealer. Batteries: Rechargeable batteries can be charged and discharged hundreds of times. However, they will eventually wear out. This is not a defect or failure so that batteries wear out is not covered by this warranty.
Page 103 USER MANUAL – OPTIMA-33-RT10 5K-20K ANNEX A CONNECTIONS FOR UPS CONFIGURED FOR SINGLE-PHASE OUTPUT This UPS family can be configured to operate with three-phase input and single-phase output, except for the OPTIMA-33-RT10 20K - 208V. Below are the wire gauge tables and connection diagrams for each model. 208/120VAC MODELS –...
Page 104 USER MANUAL – OPTIMA-33-RT10 5K-20K 208/120VAC MODELS – THREE-PHASE INPUT / SINGLE-PHASE OUTPUT AC Input Bypass Line (Note 1) AC Output Line (Note 1) Battery Max. AC Neutral Ground L2, & L3 +, N, & - Lines Current x Phase(A) WARNING: MAKING THIS CONNECTION WITHOUT FIRST CHANGING THE UPS OUTPUT CONFIGURATION TO SINGLE-PHASE WILL PERMANENTLY DAMAGE IT, WHICH IS NOT COVERED BY THE WARRANTY.
Page 105 USER MANUAL – OPTIMA-33-RT10 5K-20K 400/230VAC MODELS – THREE-PHASE INPUT / SINGLE-PHASE OUTPUT AC Input Bypass Line (Note 1) AC Output Line (Note 1) Battery Max. AC Neutral Ground L2, & L3 +, N, & - Lines Current x Phase(A) WARNING: MAKING THIS CONNECTION WITHOUT FIRST CHANGING THE UPS OUTPUT CONFIGURATION TO SINGLE-PHASE WILL PERMANENTLY DAMAGE IT, WHICH IS NOT COVERED BY THE WARRANTY.
Page 106 USER MANUAL – OPTIMA-33-RT10 5K-20K 400/230VAC MODELS – THREE-PHASE INPUT / SINGLE-PHASE OUTPUT AC Input Bypass Line (Note 1) AC Output Line (Note 1) Battery Max. AC Neutral Ground L2, & L3 +, N, & - Lines Current x Phase(A) CAPACITY 15KW 20KW...
