Page 1: User Manual
____________________________________________________________________________________________ USER MANUAL ONLINE DOUBLE CONVERSION UPS User Manual: 220V (Europe: «Schuko» Zone) 110V (America: «NEMA» Zone) (091214_Sp) Integra EPRO 1K-3K... -
Page 2: Safety And Use
We strongly recommend disposing this UPS according to regulations in your country to prevent possible environmental damages; besides some parts might be recycled. BATTERY WARNING: DO NOT dispose batteries in fire as it might explode. DO NOT try to open batteries, there are dangerous liquids inside. (091214_Sp) Integra EPRO 1K-3K... -
Page 3: Safety Standards
IEC 61000-4-4: 2004 Electrical fast transients/Burst immunity test IEC 61000-4-5: 2005 Surge immunity test IEC 61000-2-2: 2002 Compatibility levels for low frequency conducted disturbances and signaling in public low voltage power supply systems EN 61000-4-6: 2006 EN 61000-4-8: 2001 EN 61000-4-11: 2004 (091214_Sp) Integra EPRO 1K-3K... - Page 4 Protected LAN network jacks “EPO”: “Emergency Power Off”. USB port “Tower” 1K – 1.5KVA - SCHUKO “Rack” 1K - 1.5KVA - SCHUKO “Tower” 2KVA - SCHUKO “Rack” 2KVA –SCHUKO “Tower” 3KVA - SCHUKO “Rack” 3KVA –SCHUKO (091214_Sp) Integra EPRO 1K-3K...
- Page 5 Protected LAN network jacks “EPO”: “Emergency Power Off”. USB port “Tower” 1K – 1.5KVA - NEMA “Rack” 1K - 1.5KVA - NEMA “Tower” 2KVA - NEMA “Rack” 2KVA –NEMA “Tower” 3KVA - NEMA “Rack” 3KVA –NEMA (091214_Sp) Integra EPRO 1K-3K...
-
Page 6: Front Panel: Push Button Functions
TO ACTIVATE CONFIGURATION: Keep pushed for 5 seconds or longer “ON / MUTE” + “SELECT” TO ACTIVATE BY-PASS MODE: Under normal mode, by pushing these 2 keys at the same time during 5 seconds or longer UPS changes from normal mode to bypass mode. (091214_Sp) Integra EPRO 1K-3K... - Page 7 Special cables to connect EX-BATT to UPS are supplied inside the box of EX-BATT. INSTRUCTIONS TO CONNECT EXTERNAL BATTERIES Place EX-BATT case close to UPS. Only INTEGRA approved EX-BATT can be connected to UPS EX series. Check DC breakers are in OFF position (circuit OPEN) Connect UPS to first EX-BATT using INTEGRA approved DC cable.
-
Page 8: Configurable Parameters
Normal AC Mode: It is the default mode when AC input source is OK. Under this mode power output is generated by UPS inverter. Inverter takes power from AC/DC converter feed by AC input source. AC input source is only used under this mode to recharging batteries when necessary. (091214_Sp) Integra EPRO 1K-3K... - Page 9 Indicates number code for detected failure. Error or Failure codes are listed in this manual. “MUTE” Indicates MUTE function is active. Under this mode beeper is disabled. OUTPUT Information Indicates output values related to AC voltage, output frequency Vac: Volts AC, Vdc: Volts DC, Hz: frequency units (091214_Sp) Integra EPRO 1K-3K...
- Page 10 Indicates battery charge level: 0-25%, 26-50%, 51-75% y 76-100%. Indicates battery failure Indicates low battery level Input Information Indicates input voltage, input frequency and DC battery voltage Vac: Input voltage, Vdc: battery voltage, Hz: input frequency - 10 (091214_Sp) Integra EPRO 1K-3K...
-
Page 11: Acoustic Alarm
1 Beep every 10 seconds 7. LCD TEXT MESSAGES TEXT LCD TEXT Meaning Enable Disable Escape High Limit for By-pass Low Limit for By-pass Battery Frequency Conversion Function EPO (Emergency Power Off) Temperature Battery Charger - 11 (091214_Sp) Integra EPRO 1K-3K... -
Page 12: Ups Configuration
06: By Pass: To able or disable by-pass function 07: By Pass: To configure acceptable input voltage range. 08: Programmable Outlets: To able or disable programmable outlets function 09: Programmable: To configure timer value in minutes for programmable outlets. - 12 (091214_Sp) Integra EPRO 1K-3K... - Page 13 ENA: Bypass enable DIS: Bypass disable 07: By Pass: Input Range Configuration By Selecting UP/DOWN (“on/mute” y “select”) keys for selecting hi limit HLS and low limit LLS of input range in By-Pass mode. - 13 (091214_Sp) Integra EPRO 1K-3K...
-
Page 14: Battery Mode
* UPS output generated by inverter. CF function enabled to generate output FREQUENCY frequency as selected. CONVERTER FUNCTION When AC input source is out of range UPS goes to battery mode to supply BATTERY MODE output from batteries. - 14 (091214_Sp) Integra EPRO 1K-3K... - Page 15 Soft-start Inverter Failure Inverter: Hi Voltage Inverter: Low Voltage Inverter output short circuit Battery Very High Voltage Battery Very Low Voltage Over Temperature Overload: UPS power output capacity has been exceeded. Inverter cannot supply output. - 15 (091214_Sp) Integra EPRO 1K-3K...
-
Page 16: Troubleshooting Table
UPS cannot be powered on even AC EPO function is active. Re-establish emergency power input is OK. off switch and set UPS in normal Beep alarm is active (1 beep/s) & LCD mode. shows: - 16 (091214_Sp) Integra EPRO 1K-3K... - Page 17 Then power ON. * Active: * Continuous beep UPS has been automatically Check short circuit problem in * Active: on LCD. powered off because short devices connected to UPS * Continuous beep circuit detected at output. - 17 (091214_Sp) Integra EPRO 1K-3K...
-
Page 18: Control Software
Friendly human interface to UPS. Controlled files saving and OS shutdown when blackout is detected. Configurable scheduled shutdown and Auto-tests Some UPS models include software CD inside the box. Others allow software downloaded from our website: www.integra-ups.com. - 18 (091214_Sp) Integra EPRO 1K-3K... -
Page 19: Warranty And Support
THE PRODUCT OR THE COST OF REPAIR OR REPLACEMENT OF ANY HARDWARE COMPONENTS THAT MALFUNCTION IN CONDITIONS OF NORMAL USE. - IN NO EVENT WILL INTEGRA BE LIABLE FOR ANY DAMAGES CAUSED BY THE PRODUCT OR THE FAILURE OF THE PRODUCT TO PERFORM, INCLUDING ANY LOST PROFITS OR SAVINGS OR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. -
Page 20: Specifications Table
< 45dBA @ 1 m COMMUNICATION Windows 98 SE/ME/NT 4.x/2000/2003/XP/ Vista / 2008 / 7; Linux; Unix; Mac Smart RS-232 & USB, Supports: Intelligent Port, Supports Supports LAN SNMP Card and AS400 compatible Card (optional) - 20 (091214_Sp) Integra EPRO 1K-3K... - Page 21 (*N2): Backup time for programmable outlets is configurable (in minutes) from LCD to offer longer time to critical loads connected to standard outlets (*N3): Frequency Conversion Function allows setting output frequency at constant value: 50Hz or 60Hz when input Frequency is within 40 - 70 Hz - 21 (091214_Sp) Integra EPRO 1K-3K...
