  • Page 1 HULALA H O M E ITEM NO.NSHM1197D NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/22...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN 03/22...
  • Page 4: Parts List

    PARTS LIST 04/22...
  • Page 5: Hardware List

    HARDWARE LIST ∅ ∅ ∅ ∅ 8#*1-1/4" 3*16mm*6# 3*14mm 3*12mm ∅ 3.5*35mm*7# TOOL LIST HARDWARE SPARE LIST ∅ ∅ 8#*1-1/4" 05/22 3*14mm...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1. connect part (F) to part (E) with screw #1, tight screw with screwdriver #14. ∅ 8#*1-1/4" 06/22...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1. insert part (E/F) to part (D) , make sure all holes aligned and tight it with allen wrench #13. 07/22...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1. insert part (C) to part (E/F) , make sure all holes aligned and tight it with allen wrench #13. 08/22...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1. insert the unit pre-assembled at step 3 to part (B) , make sure all holes aligned and tight it with allen wrench #13. 09/22...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-5 1. insert part (A) to the unit pre-assembled at step 4, make sure all holes aligned and tight it with allen wrench #13. 10/22...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1. connect part(G) to the unit pre-assembled at step 5 with screw#2,tight screw with screwdriver #14. make sure the usb plug cross the back panel(G). ∅ 3*14mm 11/22...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-7 1. connect part(H) to the unit pre-assembled at step 6 with screw#1,tight screw with screwdriver #14. 2. connect part #3 to part(A) with screw #4, tight screw with screwdriver #14. ∅ ∅ 8#*1-1/4" 3*16mm*6# 12/22...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-8 1. connect part #6 to part (H) with screw #5, tight screw with screwdriver #14. ∅ 3*12mm 13/22...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-9 1. insert part #7 to the hole of part (C/D),make sure they are at the same level ,then attach part (I) to it. Shelf holder can be adjusted up or down 14/22...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-10 1. insert top drawer (J) to the body. Attention : When installing the drawer,slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 15/22...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-11 1. connect part (L/M) to part(N) with screw #1, tight screw with screwdriver #14. 2. slide part (O) to part (L/M), make sure it also in the groove of part (N). ∅ 8#*1-1/4" 16/22...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-12 1. connect part (L/M) to part(K) with screw #1, tight screw with screwdriver #14. 2. connect part #8 to part (K) with part #9, tight it with screwdriver #14. ∅ ∅ 32/5"*1" 8#*1-1/4" 17/22...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-13 1. insert big drawer to the body. Attention : When installing the drawer,slide the steel ball slide rail of side panel to the most front as picture show. Female slider Male slider Schematic diagram of slide rail disassembly 18/22...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-14 1. insert the light usb to the outlet, you can turn on/off by push the botton. 19/22...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-15 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part (#3) on the top panel (A); Drill and insert the expandable screw ( by hammer. #11) Assemble the part (#3) to the wall. Align the hole in the part (#3) with the expandable screw (#11) , use screw (10#) to attach it and tighten by screwdriver (14#) .
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-16 1. Let the plastic belt ( #12) pass through the both part ( #3) and pull tightly. 21/22...
  • Page 22: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
