Hudson Click clack Sofa Bed
Box Dimensions:L181xW25xH111(cm)
F
M8X45MM
8 PCS
K
Hardware base frame
G
M8X25MM
4 PCS
2 PCS
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DUSK Hudson Click Clack CLK3VLG
Summary of Contents for DUSK Hudson Click Clack CLK3VLG
- Page 1 Hudson Click clack Sofa Bed Box Dimensions:L181xW25xH111(cm) Center Leg M8X25MM X70MM M8 Flat Washer M6 Allen Key M8X45MM 8 PCS 4 PCS 8 PCS 1 PCS 1 PCS 4 PCS 20 PCS+2 Extra Cushion Left armrest Right armrest Hardware base frame 2 PCS 1 PCS 1 PCS...
- Page 2 Page 2...
- Page 3 Step 1：Unzip the black fabric on the underside of the sofa bed to access the rest of the parts. Step 2：Fasten the arms (I & J) to the sofa frame using 8x screw (B) and 8x washer(C) on each side. Page 3...
- Page 4 Step 3：Use the 4 screws (G) and 4x washer(C) on each side to attach the base frame (A) to the bottom of the sofa. Step 4：Attach the legs (A, K& E) to the underside of the sofa using 8x screws (F) and 8x washer(C) on each side, being sure that leg (A) are at the front and (K) is at the back.
- Page 5 Step 5：To extend the legs, unzip the zipper on the back of the backrest, and pull the legs out until they lock into position. Step 6：To convert from the sofa position to the bed position, pull the backrest towards the front of the sofa until both the left and right side have clicked.
- Page 6 Step 7：To convert from the sofa bed to the sofa position, collapse the legs by pressing the latch at the top of the legs on the left hand side, being careful not to trap your fingers, fold the legs in and zip up the zipper.
