Pylontech Optim US-L260-Omni User Manual page 27

Lithium iron phosphate battery energy storage system

3.5.2.3

Control Module

The appearance and the specifications of the control module are shown as follows.

Specifications

AC Supply for BMS

System Operation Voltage (VDC)

Dimension (mm)

Communication

Protection Class

Weight(kg)

Operation Life (Years)

OPS10M7A200E

230VAC/50Hz/1.3A

0~1000

460 (W) × 758 (D) × 160 (H)

RS485\CAN\LAN

IP20

21.25

15+
