- Page 1 IN241000672V01_UK 846-063V70GY Assembly video please scan the QR code . IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY INSTRUCTION MANUAL...
- Page 2 846-063V70GY ( H18002 ) 5.6kW Butane/Propane/LPG Gas Mixtures 408 g/h 400 g/h 408 g/h 408 g/h 0063-24 Warning: The storage compartment is not suitable for depositing liquid gas cylinders！...
- Page 3 Read the following instructions carefully and ensure that your barbecue is correctly installed, assembled and maintained. Failure to follow these instructions could cause serious injury and/or damage to property. Use outdoor only. WARNING : accessibile parts may be very hot . Keep young children away . Read the instructions before using the appliance.
- Page 4 M8x80 M6x45 M6x25 Hood Hinge Side Table Trolley Support M6x15 Body Support Trolley Side Support M6x10 M4x10 Side Table Bracket Handle Wheel Grease Box Support Front Farbic Burner Bracket Grease Box Regulator Kit Body Hinge Valve Assem Left Leg Hinge Axle Clip Control Panel Right Leg...
- Page 5 M6x45 M6x45 M6x45...
- Page 6 M8x80...
- Page 7 M6x25 Do not tighten the screws...
- Page 8 M6x10 Do not tighten the screws M6x15 After assemble the part 10 then tighten the screw in step 6 & step 8.
- Page 9 M6x25 M6x10...
- Page 10 M4x10 M4x10...
- Page 11 M4x10 M6x10 M4x10...
- Page 12 M6x10 Make sure the burner already insert into injector as below picture the tighten the screws. M6x15 M6x10...
- Page 13 Hinge Axle Clip...
- Page 16 Warning !!! Identify any leaks after assemble & before use ! ( Refer to Leak Test Instruction, Page 18 ) Below connection are the parts which must test the leakage.
- Page 19 first first first...
-
Page 20: Troubleshooting
Trouble Shooting Problem Possible cause Solution Burners will not light LP gas cylinder is empty. Replace with full cylinder using the ignition Faulty regulator. Have regulator checked or system replace Obstructions in the burner Clean burner Obstructions in gas jet and hose Clean jets and gas hose Electrode wire loose or disconnected Reconnect wire... - Page 21 IMPORTER ADDRESS: Importador/REP: MH STAR UK LTD Spanish Aosom, S.L. Unit 27, Perivale Park, C/ Roc Gros, nº 15. 08550, Els Hostalets de Balenyà, Horsenden lane South Spain. Perivale, UB6 7RH B66295775 MADE IN CHINA HECHO EN CHINA Importé par/REP : MH France 2, rue Maurice Hartmann 92130 Issy-les-Moulineaux...
