Icom ID-52A Service Manual page 7

February 2022
The underlined parts have been updated from the addendum of the previous version, or from the original page.
■ SPARE PARTS INFORMATION (CONTINUED)
• For the CHASSIS unit (2/2)
Reference
Number
CONNECTOR J1
SCREW MP26
SCREW MP30
RUBBER MP22
SEAL MP7
SEAL MP12
SEAL MP23
SEAL MP24
M.OTHER MP300
3867 ANT CONNECTOR
MP300 (MAIN)
3322 CONTACT SPRING
3322 CONTACT RUBBER (TOT)
(Amended page)
Parts Name
3867 ANT CONNECTOR
VR NUT (AC)-2
PH BT B0 M2×8 SUS SSBC
3322 CONTACT RUBBER (TOT) 8930083140
3867 MAIN SEAL (SHJ)
O-RING(AS)
O-RING(CK)-1 (TOT)
O-RING(CL) (TOT)
3322 CONTACT SPRING
MP12
O-RING(AS)
O-RING(CL) (TOT)
J1
O-RING(CK)-1 (TOT)
MP22
NOTE: The parts that are not listed, see SECTION 6 MECHANICAL PARTS for details.
Order Applicable
Number
6510033430
8830003672
8810010850
8930102730
8930058550
8930083881
8930083670
8950007850
3867 MAIN SEAL (SHJ)
MP24
MP26
VR NUT(AC)-2
MP23
5-6a
Remarks
Versions
All –
MP7
MP30
PHBT B0 M2 × 8 SUS SSBC
