SECTION 2

• LOGIC UNIT (Top View)

BUFFER AMPLIFIER*

(IC393)

EEOROM*

(IC31 and IC32)

*Mounted under the LCD module.

INSIDE VIEWS

GPS UNIT

2-1

LCD MODULE

(DS12)

AUDIO AMPLIFIER/

TONE FILTER*

(IC350)

AUDIO AMPLIFIER/

TONE FILTER*

(IC40)

LOGIC UNIT
