Icom ID-52A Service Manual page 52

4-5 RECEIVE ADJUSTMENTS (CONTINUED)
Select an adjustment item using [RX→CS]/[DR].
The output level of the standard signal generator (SSG) is measured at the load end (PD).
†
ADJUSTMENT
S-METER 1 For A band
- 230.0 MHz ~
375.0MHz-
2 For A band
- 375.0 MHz ~ 3 For A band
479.0MHz-
4 For B band
DUT'S CONDITION
• Adjustment item: S3
• Adjustment frequency:
302.520
• Mode: FM
• Adjustment item: S3
• Adjustment frequency:
302.520
• Mode: AM
• Adjustment item: S3
• Adjustment frequency:
Expect for [USA]:
435.020
For only [USA]: 445.020
• Mode: FM
• Adjustment item: S3
• Adjustment frequency:
Expect for [USA]:
435.020
For only [USA]: 445.020
• Mode: FM
OPERATION
• Connect the SSG to the antenna connector, and
set it to:
Frequency: "Adjustment frequency" is
displayed on the DUT's LCD.
Level: – 6 dBμ
Modulation: OFF
4-13
(–113 dBm)
†
Continued on the next page�
VALUE
Push [ENTER].
(Automatic
adjustment)
