Hexagon wrench
PO:
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
A
Flat washer - 8 pcs
Spare - 2 pcs
B
Hexagon nut - 8 pcs
Spare - 2 pcs
TOP PANEL
01
LEG
02
SIDE PANEL
03
LOWER SHELF
04
PRINTER STAND CHARGING STATION
ASSEMBLY INSTRUCTIONS
Before assembling your printer stand, please read through these
instructions carefully and familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
C
Hexagon wrench - 1 pc
D
Wooden dowel 1/4" X 1 1/4" - 4 pcs
PARTS LIST
1 PC
4 PCS
2 PCS
1 PC
01
CODE
TB-PR-LXI
E
Wooden dowel 3/8 X 1 1/4" - 4 pcs
Spare - 1 pc
02
02
04
READY
ASSEMBLE
Adult assembly
ITEM
H-7904X
Spare - 1 pc
F
Wood screw - 6 pcs
Spare - 1 pc
02
02
03
03
Page 1 of 3
