AFi G-11833X Assembly Instructions

please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
HEADBOARD PANEL
1
BOARDS
2 LEFT LEG
3 RIGHT LEG
4 HEADBOARD SUPPORT
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the legs (2) and (3) to headboard
panel boards (1) using JCB M6 X 35mm (A).
Tighten with the Allen wrench (G).
1
A
A
FOR BED FRAME ASSEMBLY follow assembly instructions included with your bed frame.
If you purchased a wood headboard to attach to metal bed frame, please refer to page 2.
PO:
HEADBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
instructions carefully and familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
4 PCS
A
1 PC
JCB M6 X 35mm - 16 pcs
1 PC
B
JCB M8 X 15mm
( 5/8") - 4 pcs
1 PC
Assembly headboard
to open bed frame
A
3
FULL > QUEEN
G
Allen wrench - 1pc
Spare - 1pc
Spare - 1 pc
Spare - 1 pc
C
Wood screw 1 1/4"-4 pcs
Spare - 1 pc
Step 2
C
2
CODE
HB-ISL-OXD G-11833X
HARDWARE
HARDWARE FOR METAL BED FRAME
D
JCB M6 X 25mm (1") - 4 pcs
E
Flat washer - 4 pcs
F
Split washer - 4 pcs
Attach headboard support (4) to
headboard panel boards using wood
screw 1 1/4" (C) Tighten with the
Phillips head screw driver.
(Customer supplied)
4
ITEM ITEM
G-11834X
READY
TO
ASSEMBLE
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
Adult assembly Adult assembly
A
JCB M6 X 35mm
C
Wood screw
Page 1 of 2
