- Page 1 Classic Bay 1200 Insert Troubleshooting Manual (THIS MANUAL IS INTENDED FOR TRAINED & QUALIFIED DEALERS & TECHNICIANS USE ONLY) 250-7700B February 13, 2019...
-
Page 2: Table Of Contents
CB1200 INS Safety Alert Key: DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. -
Page 3: Normal Operation Sequence
CB1200 INS Normal Operation Sequence Heat Output Speed HIGH HIGH 1. Turn on thermostat a red call light will illuminates on the stove. Reset Button Call Light 2. The exhaust blower will turn on. 3. The igniter turns on. 4. The vacuum switch closes. 5. - Page 4 CB1200 INS 9. Heat from the fire turns on the red thermocouple light in the control box. 10. The igniter turns off 11. Heat from the fire closes the #1 snap disc. 12. The convection blower will turn on. 13. Room reaches temperature 14.
-
Page 5: Basic Troubleshooting & Repair
CB1200 INS Basic Troubleshooting & Repair A . Plug in stove with no response G . Feed system fails to start 1. Check the power supply for 115 volts 1. Check front door and make sure it is closed 2. Check the fuse in the junction box (7amps) 2. -
Page 6: Feed System
CB1200 INS Feed System TECH TIP: MAKE SURE THE FEED SYSTEM IS CLEAN AND FREE OF OBSTRUCTIONS BEFORE TROUBLESHOOTING TURN ON THE T-STAT & APPLIANCE IS THE HOPPER LID CLOSED? IS THE AUGER TURNING? CHECK VACUUM CLOSE THE LID SWITCH GOOD REPLACE THE VACUUM SWITCH... - Page 7 CB1200 INS FEED MOTOR CIRCUIT JUNCTION BOX CAPACITOR BLACK WHITE BLACK BLACK WHITE RECEPTACLE WHITE S / 15 R / 14 P / 13 N / 12 FEED MOTOR M / 11 L / 10 CONVECTION K / 9 BLOWER J / 8 H / 7 BLACK...
-
Page 8: Igniter
CB1200 INS Igniter TECH TIP: MAKE SURE THE FIRE POT AND SURROUNDING AREA IS CLEAN BEFORE TROUBLESHOOTING TURN ON THE T-STAT & APPLIANCE IS THERE POWER TO THE APPLIANCE? IS THE CALL LIGHT ILLUMINATED? CHECK POWER CONNECT A MULTIMETER IS THE IGNITER TO THE IGNITER GETTING HOT AFTER 60... - Page 9 CB1200 INS IGNITER CIRCUIT JUNCTION BOX S / 15 R / 14 P / 13 N / 12 M / 11 L / 10 HIGH-TEMP K / 9 J / 8 HIGH-TEMP H / 7 F / 6 E / 5 IGNITER D / 4 C / 3...
-
Page 10: Exhaust Blower
CB1200 INS Exhaust Blower TECH TIP: MAKE SURE THE AIR PATH IS FREE FROM RESTRICTIONS AND THE EXHAUST SYSTEM IS CLEAN BEFORE TROUBLESHOOTING PLUG STOVE IN CHECK WIRE CHECK FOR IS THE BLOWER CONNECTIONS AIR PATH RUNNING? BETWEEN THE RESTRICTIONS. BLOWER AND THE JUNCTION BOX REPAIR OR... - Page 11 CB1200 INS EXHAUST BLOWER CIRCUIT T .C . FUSE RECEPTACLE A / 1 B / 2 C / 3 D / 4 E / 5 F / 6 WHITE H / 7 J / 8 BLUE K / 9 L / 10 M / 11 N / 12 BLUE...
-
Page 12: Convection Blower
CB1200 INS Convection Blower TECH TIP INSTALLING A JUMPER WIRE ON THE #1 SNAP DISC PURPLE WIRES AND THEN PLUGGING IN THE APPLIANCE WILL TURN ON THE BLOWER PLUG IN STOVE ARE THE WIRE IS THE BLOWER SYSTEM IS CONNECTIONS RUNNING? REPAIRED GOOD? - Page 13 CB1200 INS CONVECTION BLOWER CIRCUIT JUNCTION BOX S / 15 R / 14 P / 13 N / 12 CONVECTION PURPLE M / 11 BLOWER L / 10 K / 9 J / 8 FEED #1 SNAP DISC H / 7 MOTOR F / 6 WHITE...
-
Page 14: Power Supply
CB1200 INS Power Supply TECH TIP: PLUG IN STOVE IS THERE POWER PRESENT IS THE CALL LIGHT SYSTEM IS AT THE BLACK ILLUMINATED? REPAIRED WIRE FROM THE POWER CORD? IS THERE POWER PRESENT AT THE GRAY WIRE ON THE 7 AMP FUSE REPLACE THE FUSE HOLDER? VERIFY OUTLET... - Page 15 CB1200 INS POWER SUPPLY CIRCUIT JUNCTION BOX GREY GREY COMBUSTON S / 15 R / 14 BLOWER / #3 SNAP DISC P / 13 FEED MOTOR N / 12 M / 11 L / 10 K / 9 J / 8 H / 7 F / 6 GREY...
-
Page 16: Thermostat
CB1200 INS Thermostat TECH TIP: SUGGEST USING A JUMPER WIRE TO CLOSE CIRCUITS WITH THE TESTS POINTS (JUNCTION BOX, THERMOSTAT BLOCK, #2 SNAP DISC, AND RESET BUTTON). UNPLUG APPLIANCE, REMOVE CONTROL BOX, TURN ON THERMOSTAT, AND INSTALL JUMPER WIRE AT THERMOSTAT IS THERE IS THE THERMOSTAT CONTINUITY AT... - Page 17 CB1200 INS THERMOSTAT CIRCUIT JUNCTION BOX #2 SNAP DISC YELLOW S / 15 R / 14 P / 13 N / 12 M / 11 RESET BUTTON L / 10 YELLOW K / 9 BLACK BLACK J / 8 BLACK H / 7 YELLOW CALL LIGHT...
-
Page 18: Thermocouple
CB1200 INS Thermocouple TECH TIP: SET VOLT METER TO MILLIVOLTS (DC) PLUG IN STOVE IS THERE IS THERE A IS THE CALL LIGHT 3mVDC AT THE FIRE IN THE FIRE ILLUMINATED? THERMOCOUPLE POT? WIRE CONNECTION POINTS AT THE JUNCTION BOX? REPLACE THE THERMOCOUPLE ARE THE... - Page 19 CB1200 INS THERMOCOUPLE CIRCUIT JUNCTION BOX S / 15 THERMOCOUPLE R / 14 P / 13 N / 12 M / 11 L / 10 K / 9 J / 8 H / 7 F / 6 E / 5 D / 4 C / 3 B / 2...
-
Page 20: Firebox Vacuum & Vacuum Switch
CB1200 INS Firebox Vacuum & Vacuum Switch TECH TIP: LOW VACUUM CAN BE THE RESULT OF A LEAKING DOOR GASKET, FIRE POT NOT CLOSING ALL OF THE WAY, DIRTY HEAT EXCHANGER, OR PLUGGED VENT SYSTEM. ALWAYS MAKE SURE THE UNIT IS CLEAN BEFORE MAKING ANY REPAIRS. - Page 21 CB1200 INS VACUUM SWITCH CIRCUIT JUNCTION BOX FEED MOTOR S / 15 R / 14 P / 13 N / 12 M / 11 L / 10 K / 9 J / 8 H / 7 BLACK F / 6 E / 5 D / 4 C / 3...
-
Page 22: Complete Wiring Diagram
CB1200 INS Complete Wiring Diagram 250-7700B February 13, 2019... -
Page 23: General Specifications
CB1200 INS General Specifications WATTS Feed motor Igniter Convection blower Exhaust Total AMPS Feed motor Igniter Convection blower Exhaust blower Total 4.35 VOLTS Open circuit on high, medium, & low VOLTS ON LOW FEED SETTING Convection blower 82 V ( ± 1 V ) Exhaust blower 75 V ( ±... -
Page 24: Exploded View & Service Parts
CB1200 INS Exploded View & Service Parts CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active Classic Bay Pellet Insert Part number list on following pages. 12/18 250-7700B February 13, 2019... - Page 25 CB1200 INS CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. .
- Page 26 CB1200 INS CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. .
- Page 27 CB1200 INS CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. .
- Page 28 CB1200 INS CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. .
- Page 29 CB1200 INS CB1200I-C Service Parts Beginning Manufacturing Date: May 2019 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. .
-
Page 30: Tech Check Sheet
CB1200 INS Tech Check Sheet Please answer all of the questions below if you need to contact the technical service department. This will help all of us to identify the problem faster and will save you time. What is wrong with the appliance? ________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ Model: _______________________________________... -
Page 31: Cleaning & Maintenance Tips
CB1200 INS Cleaning & Maintenance Tips CAUTION Shock and Smoke Hazard • Turn down thermostat, let appliance completely cool and exhaust blower must be off. Now you can unplug appliance before servicing. • Smoke spillage into room can occur if appliance is not cool before unplugging. -
Page 32: Service Repair Tools
CB1200 INS Service Repair Tools 1 . MULTIMETER Used for taking volt reading or doing continuity tests. 2 . MAGNEHELIC OR DIGITAL VACUUM GAUGE Used for taking firebox vacuum readings in inches of water column. Range of the gauge needs to be from zero to .50 inches of water column. -
Page 33: Notes
CB1200 INS Notes February 13,2019 250-7700B... - Page 34 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact a HHT Service Technician with any questions or concerns . For the number of a HHT Service Technician log onto www .myHHT .com . 250-7700B February 13, 2019...
Need help?
Do you have a question about the Quadra-Fire Classic Bay 1200 and is the answer not in the manual?
Questions and answers
Is the igniter supposed to stay on while the stove is on?
