- Page 1 V5290 - 72" COMMERCIAL BLADE SERIAL NO. 21300001 AND UP & & Estimated assembly time: 30 min. OM 0428B-A MANUAL PART NUMBER 77700-04887 09/13...
-
Page 3: Table Of Contents
TABLE OF CONTENT SPECIFICATION ..........................2 INTRODUCTION – To the Purchaser & Dealer ..................3 SAFETY PRECAUTIONS ........................4 Before Operation ..........................4 Notice ..............................5 The Blade ............................5 Before Operation ........................ 5 Blade Operation ......................... 6 The Vehicle ............................7 General Information ...................... -
Page 4: Specification
SPECIFICATION V5290 Features and Specifications Total lenght 72" Working height 20 3/8" center - 22 1/2" both ends Total height 24 3/16" 29 3/16" with deflector Width with attach 23 1/2" without deflector Blade thickness 10ga Side reinforcement thickness 3/16"... -
Page 5: T O The Dealer
INTRODUCTION O THE URCHASER O THE EALER All products are designed to give safe, Give this manual to the owner upon delivery of dependable service if they are operated and the equipment. maintained according to instructions. Read understand this manual before operation, and keep it in your files for &... -
Page 6: Before Operation
SAFETY PRECAUTIONS SAFETY FIRST This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use this unit. -
Page 7: Notice
SAFETY PRECAUTIONS - continued OTICE A safe operator is the best assurance against accidents. All operators, no matter how experienced they may be, should read this operator's manual and all other related manuals before attempting to operate the equipment. Please read the following section and pay particular attention to all safety recommendations contained in this manual and those labeled on the equipment and on the vehicle. -
Page 8: Blade Operation
SAFETY PRECAUTIONS - continued Blade Operation 1. Before leaving the vehicle unattended, take 11. Never operate machine at high transport all possible precautions. Park the vehicle/ speeds on a slippery surface. equipment on level ground, set the parking 12. Use extra caution when backing up. brake, lower the equipment to the ground, 13. -
Page 9: The Vehicle
SAFETY PRECAUTIONS - continued EHICLE General Information 11. Fill fuel tank outdoors with extreme care. Never fill fuel tank indoors. Replace fuel 1. Read the operator's manual carefully before cap securely and wipe up spilled fuel. using vehicle. Lack of operating knowledge can lead to accidents. -
Page 10: Maintenance
SAFETY PRECAUTIONS - continued AINTENANCE 12.Do not operate a unit that is defective or ALWAYS GENUINE PARTS WHEN has missing parts. Make sure that all REPLACEMENT PARTS ARE REQUIRED recommended maintenance procedures 1. Keep vehicle blade properly are completed before operating the unit. maintained. -
Page 11: Decals
DECALS Replace Immediately if Damaged 70060-02232 (2500484) V5290 70060-01448 77700-04894 (657524) (2500906) 77700-04230 (2500885) 70060-03033 (658710) OM 0428B-A... -
Page 12: Assembly
ASSEMBLY LADE SSEMBLY The blade is pre-assembled at the factory, however, parts contained in the bag and the box must be installed. Use the present manual and lay out all parts for assembly. Separate bolts and nuts into various sizes. After assembly, torque all the bolts according to the Torque Specification Table at the end of the manual. - Page 13 ASSEMBLY 4. Figure 3: Attach the two hoses on the hose support (item 2) with the hose clamp WARNING: To avoid serious (item 1) and secure with a 3/8" NC x 1 1/4" personal injury. Escaping hydraulic/ hex. bolt (item 3) and a 3/8" nylon nut as diesel fluid under pressure can penetrate shown.
-
Page 14: Mounting The Blade On The Vehicle
ASSEMBLY Mounting the Blade on the Vehicle Removing the Blade from the Vehicle (Figure 4) (Figure 4) 1. Insert the male quick hitch (item 1) into the 1. Set the vehicle parking brake, stop the female quick hitch (item 2), turn the engine engine and remove the ignition key. -
Page 15: Operation
OPERATION LADE PERATION This front blade has been designed to override its normal working position. When striking large rocks, tree stumps etc. the blade will tip forward to lessen the shock to the operator and vehicle. Once the blade clears the obstacle, it will spring back to its working position. Never operate the blade on high gear. -
Page 16: Spring Adjustment
MAINTENANCE Spring Adjustment (Figure 6) The spring tension is too low when the blade tips forward for no apparent reason. On the other hand, the tension is too high if the blade Figure 6 fails to tip forward when it strikes a heavy object. -
Page 17: Parts
PARTS NTRODUCTION All parts are illustrated in "exploded views" which show the individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Reference Number" (REF) column, and are followed by the description and quantity required. All reference to right and left, forward or rearward, is from the operator seat facing the steering wheel. -
Page 18: Blade Assembly
PARTS – V5290 LADE SSEMBLY OM 0428B-A... - Page 19 PARTS – V5290 LADE SSEMBLY ESCRIPTION Blade – 72" 77700-04878 670593 Skid shoe 77700-00972 668809 Spacer 77700-00973 668810 Cutting edge 70060-04062 661724 Adjustable hitch 77700-04877 670592 Blade pin 15/16" x 22 5/16” lg 77700-00981 668828 Female hitch 77700-04876 670590 Spring plate...
-
Page 20: Hydraulic Angling
PARTS YDRAULIC NGLING ESCRIPTION UMBER Cylinder 2" x 6 1/2" 70001-00636 664979 Seal kit 70001-00660 665017 Hose rubber 1/4" x 53" 1/4"NPT M x 3/8"NPT M 70060-02147 656130 Hose rubber 1/4" x 64" 1/4"NPT M x 3/8"NPT M 70001-00796 665236 Pin 7/8"... -
Page 21: Torque Specification Table
TORQUE SPECIFICATION TABLE GENERAL SPECIFICATION TABLE Use the following torques when special torques are not given. NOTE: These values apply to fasteners as received from supplier, dry, or when lubricated with normal engine oil. They do not apply if special graphited or moly sidulphide greases or other extreme pressure lubricants are used. - Page 24 Printed in Canada...
