OWNER'S MANUAL
MANUAL P/N: IM-BX4072
MANUAL P/N: 77700-08651
BX-80 SERIES FRONT WIPER
P/N BX4072
WIPER
MOTOR
For use with: BX4070 AND BX4090 CAB SYSTEMS FOR
KUBOTA BX1880, 2380, 2680 AND 23S TRACTORS
Rev. B, 02/21/2024
PLEASE READ THIS MANUAL CAREFULLY
KEEP READY AT ALL TIMES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX-80 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kubota BX-80 Series

Summary of Contents for Kubota BX-80 Series

  • Page 1 MANUAL P/N: 77700-08651 BX-80 SERIES FRONT WIPER P/N BX4072 WIPER MOTOR For use with: BX4070 AND BX4090 CAB SYSTEMS FOR KUBOTA BX1880, 2380, 2680 AND 23S TRACTORS Rev. B, 02/21/2024 PLEASE READ THIS MANUAL CAREFULLY KEEP READY AT ALL TIMES...

  • Page 2: Safety First

    Legal Disclaimer Kubota Corporation notes that specifications and technical information are subject to change without notice and Kubota does not represent or warrant that the information in this publication California Proposition 65 is completely accurate or current; however, Kubota used reasonable efforts to set forth and include accurate and up to date information in this publication.

  • Page 3: General Safety Information

    GENERAL SAFETY INFORMATION BEFORE YOU START SERVICE NO SMOKING OR OPEN FLAMES WHILE FUELING Read all instructions and safety instructions in this • Fuel is extremely flammable and dangerous. Never • manual and on your machine safety decals. smoke near fuel. If fuel is spilled on the machine, its Clean the work area and machine.
  • Page 4 GENERAL SAFETY INFORMATION LOADER AND BACKHOE SAFETY PREVENT A FIRE • Engage the loader control valve lock to prevent • Fuel is very flammable and explosive under some accidental actuation when the implement is not in conditions. Do not smoke or let flames or sparks in use or during transport.
  • Page 5 Your machine may be configured differently (e.g. SP1 vs. SP2, etc.), but the outline for the procedure should still be followed. For further support for any issues not covered within the pages of this manual, please contact your local Kubota representative. WARNING:...
  • Page 6 ASSEMBLY Steps 1-2 are only required if a cab has already been fully installed. If a cab is currently being installed for the first time, proceed to step 3. 1. Remove installed roof and set aside with mounting hardware. Tools: 3/16 Allen Wrench 1/2”...
  • Page 7 ASSEMBLY 4. Remove (1) dome plug on the underside of the windshield near the Rocker Switch hole plugs. Next, remove the larger dome plug above the previously removed hole plugs found in the windshield. 5. Install the wiper motor using the hardware provided on the wiper motor and in the wiper motor mounting kit.
  • Page 8 ASSEMBLY 7. Connect the supplied front wiper wire harness to the wiper motor and run the harness through the rubber grommet. Figure 7: Install Wiper Wire Harness 8. Connect the white power wire extending from the top of the sideframe to terminal “1” found on the circuit Red Jumper Wire to Additional breaker.
  • Page 9 ASSEMBLY 11. If cab has been previously installed, re-connect the weatherproof connector and processed to step 12. If not, connect the weatherproof connector from the main power harness previously installed to the connector on the harness protruding from the bottom of the right sideframe.
  • Page 10 ASSEMBLY 15. Next, tighten down the (2) set screws found on the wiper arm (180 degrees apart) to ensure that the arm does not work its way off the splined shaft of the motor. Tighten to 24 inch-pounds max. Tools: 2.5mm Allen Wrench Torque Wrench Screw If the cab assembly has not been completed yet, continue...

  • Page 11: Operation

    OPERATION WARNING REQUIRED BEFORE OPERATION 1. Read and understand this entire manual and any other publications for the equipment being operated. 2. Ensure that the surrounding area is clear and that personnel are positioned away from the area where engagement and disengagement of attachments will occur 3.

  • Page 12: Troubleshooting

    TROUBLESHOOTING FRONT WIPER TROUBLESHOOTING Possible Solution Condition • • Front Wiper Motor does not turn on Is the battery dead? • Check the following electrical connections in order: wiper motor to wiper harness, power harness to main harness found on the lower part of the right sideframe, power harness to battery, main harness to ground strip, main harness to circuit breaker, jumpers to circuit breaker(s), wiper harness to ground strip, wiper harness to circuit breaker.

  • Page 13: Parts Breakdown

    PARTS BREAKDOWN ITEM #: PART NUMBER: CODE NUMBER: QTY/KIT: DESCRIPTION: 70000-01056 9PWM852 WIPER MOTOR, 85 DEGREE 70000-01054 9PWA14-16 WIPER ARM, ADJUSTABLE LENGTH (11" - 16") 70000-01055 9PWB20-FB WIPER BLADE, 20", FLEX 77700-08630 9PWK-HBOEM GLASS MOUNTING KIT FOR WIPER SYSTEMS, O.E.M. 77700-08625 9SV-APBR ETA 5 AMP PUSH BUTTON RESET BREAKER W/ NUT...
