1. Canopy Mounts (Canopy Kit)
2. Windshield Assembly
3. Door Strikers & Hinge Mounts (Door Kit)
4. Rear Panel Assembly
5. Canopy Assembly
6. Door Assemblies
NOTE: Front Heavy Duty Springs (V5218) or Heavy Duty Spring Damper Assembly (V5219) is
required if complete cab is installed (RTV-X900, RTV-X1120D, and RTV-XG850).
BEFORE INSTALLING REAR PANEL
•
Read all instructions and safety instructions in this manual.
•
Refer to your machine's operator's manual and safety instructions on your
machine's safety decals.
•
Wear appropriate personal protective equipment (PPE) when performing work.
•
Hang a "DO NOT OPERATE" tag in operator station.
•
If installing a door kit, install the door strikers before installing the rear panel.
•
If installing 4-way flashers and/or rear work lights, it will ease assembly if they are
installed prior to installing rear panel on vehicle.
WARNING
To avoid personal injury or death:
•
Cabs, blades, and general accessories add additional weight to the base vehicle. Deduct the accessory's total weight
from the vehicle's rated capacity including passenger and driver. Never operate the vehicle outside of its rated weight
capacity.
•
Exposure to carbon Monoxide can cause illness, serious injury, or death. Never operate vehicle if suspicious of
Carbon Monoxide. Inspect exhaust system for leaks monthly. Leaks can result from loose connections, corrosion,
cracks, or other damage to the exhaust manifold. If leaks are found, repair or replace exhaust system. Do not use
vehicle until repair or replacement is complete.
•
This rear panel does not provide protection from: a rollover (or other accidents), from flying objects (including golf
balls), or from lightning. When lightning threatens, take cover and do not operate vehicle.
Estimated assembly time: 30 minutes
PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019
INSTALLATION MANUAL
REAR PANEL
(77700-VC5040, VC5040) (color: black)
KUBOTA RTV-X900, RTV-X1120D, RTV-XG850
CAB COMPONENT ORDER OF INSTALLATION:
IMPORTANT!
Code: 77700-05188 (Rev. F)
Advertisement
Table of Contents
Related Manuals for Kubota 77700-VC5040
Summary of Contents for Kubota 77700-VC5040
- Page 1 This rear panel does not provide protection from: a rollover (or other accidents), from flying objects (including golf balls), or from lightning. When lightning threatens, take cover and do not operate vehicle. Estimated assembly time: 30 minutes PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05188 (Rev. F)
- Page 2 2X — STEEL FENDER WASHER, 5/16” ID X 1.25” OD 2X — RUBBER FENDER WASHER, 5/16” ID X 1.25” OD 4X — NUT, HEX FLANGE, NYLOC, 5/16-18 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05188 (Rev. F)
- Page 3 A new ROPS warning label is provided with this accessory as the original one is covered by the rear panel. Once installa- tion is complete, adhere the label to the ROPS as shown below. Note: for best adhesion, apply to a clean, dry surface at room temperature. PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05188 (Rev. F)
- Page 4 ROPS and insert the (2) pre-installed “studs” in the top mount of the rear panel into the holes in the top flange of the cargo screen. (see fig. 3) Typical both sides Fig. 3 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05188 (Rev. F)
- Page 5 (see fig. 8). 9. Repeat on right side. 10. Tighten all hardware. 5/16-18 Screws Fig. 4 Fig. 8 PRINTED IN THE USA © KUBOTA TRACTOR CORPORATION 2019 Code: 77700-05188 (Rev. F)
